DRY PRECISION 100

Humidistat

User´s manual

Table of Contents

Need help?

Do you have a question about the Dry Precision 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for MICROWELL Dry Precision 100

Page 1 DRY PRECISION 100 Humidistat User´s manual...
Page 2: Table Of Contents
CONTENTS Product specification ..........3 Technical parameters ..........3 Product control by the user........4 Settings..............5 Service part: Product functions........ 6 Parameters´ configuration........6 Description of configuration screens....... 7 Switching unit............13 Power supply ............14...
Page 3: Product Specification
P roduct specification This device provides a remote control of the dehumidifier. It has got the following functions: Relative humidity measuring − Air temperature measuring − Requested humidity setting and the product´s switching on − Requested temperature setting and heating´s switching on −...
Page 4: Product Control By The User
P roduct control by the user PRODUCT CONTROL BY THE USER The control unit has got the following control elements − Rotary wheels with confirmation function (when pressing) − Display unit In a basic status the unit displays: − Air temperature −...
Page 5: Settings
Settings DATE AND TIME SETTING Press the wheel in the requested temperature display mode – the lighting will switch on. During a time period of the lighting press the wheel one more time. (In case the lighting function is not permitted on your device, press the wheel only once.) The accurate time will be shown on the display by big numerals.
Page 6: Service Part: Product Functions
Service part PRODUCT FUNCTIONS After inserting the batteries the welcome logo is displayed with a software version and the equipment´s initialisation starts running. The first measuring and evaluation are performed. Afterwards the equipment tries to make a radio connection with the switching unit. The time is set on 12:00, date on 1.1.2009 and in case the connection is made, the first record with these time details is registered.
Page 7: Description Of Configuration Screens
Service part Description of configuration screens: 1. Service menu language Service settings 1. Service menu language Slovak language The menu´s language is chosen here. By wheel revolution choose the requested language and then by pressing it confirm your setting. In case have not chosen any other languages, by pressing the wheel you get into the next configuarion side.
Page 8 Service part 4. Hysteresis of dehumidification Service settings 4. Hysteresis of dehumidification control In this window it is possible to set the hysteresis of dehumidification switching, as this is a two position regulation. The hysteresis field is always located right above the requested value.
Page 9 Service part 7. Date recording period Service settings 7. Time interval of data recording This window provides a time interval setting between the records. The less often setting saves battery energy but also prolongs the regulation cycle. 8. Time of display lighting Service settings 8.
Page 10 Service part 10. Period of life signs Service settings 10. Period of life signs In case of active screen saver there is an arrow icon with wheel shown on the display or the LED diode blinks under it. The display/blinking period is set in this window. 11.
Page 11 Service part 13. Receiving (switching) unit Service settings 13.Receiving unit 00 07 B1 01 00 07 B1 A2 SEEK -> FINISHED In this window it is possible to allocate one or more switching units to the unit of measure. The function is chosen by wheel revolution and arrow moving in up and down directions and by pressing the wheel the function gets activated.
Page 12 14.Transmission minimizing Service settings 14. Transission minimizing SWITCH ON In here you can choose the mode in which the switching unit transmits only in case the dehumidification is needed. By switching this mode on, the batteries´ longevity is prolonged, however the data are periodically recorded only during the dehumidification being on. 12 |...
Page 13: Switching Unit
Sw itching unit SWITCHING UNIT The switching unit status is directly displayed by LED diodes on the switching unit´s cover in a following way. green: power supply status and status of radio communication between the equipments − constant shining: equipment under pressure, unsuccessful radio communication, control unit out of operation or out of impact −...
Page 14: Power Supply
P ow er supply POWER SUPPLY The switching unit must be connected in accordance with the following description: Clamper name Function Supply phase of the equipment and the connected devices. Working zero Fan connection. COMP Connection of compressor´s contactor. HEAT Connection of electro valve for heating control.
Page 15 Tel./fax: 055/625 25 45 tel.: 031/702 0540-1 Mobile: 0911-454 010 fax: 031/702 0542 e-mail: kosice@microwell.sk mobile: 0903-413 764, 0902-422 422 e-mail: microwell@microwell.sk Please keep this user´s manual in a safe place so you will find it in case of need.
