Summary of Contents for Twisty Ride MOTORCYCLE & SCOOTER IPHONE 5 CHARGER
- Page 1 MOTORCYCLE & SCOOTER IPHONE 5 CHARGER www.twistyride.com...
-
Page 2: Table Of Contents
CONTENTS Introduction ................3 What’s in the Box?............... 4 Fitting the iPhone Charger ........... 5 Caution ................5 Charger Cable ..............5 Fitting Instructions ............6 Safety Notices and Warnings ..........8 Safety ................8 Maintenance and Security ..........8 Technical Specifications ............ -
Page 3: Introduction
This document provides details over the Motorcycle iPhone Charger only. The other components of the Twisty Ride iPhone case system are not discussed in this user guide. If you have purchased other items such as the case or the mount please refer to their associated documentations. -
Page 4: What's In The Box
WHAT’S IN THE BOX? The following items are included with the motorcycle iPhone charger: 6 mm battery ring clips 2 amp standard automotive blade fuse in its waterproof lodging An on / off switch A power converter with LED operating indicator A waterproof “quick release”... -
Page 5: Fitting The Iphone Charger
FITTING THE IPHONE CHARGER CAUTION Extreme care must be taken when mounting the iPhone charger on a motorcycle or scooter. Read this document carefully before fitting the charger. The charger shall be mounted in compliance with the relevant legislation and the vehicle manufacturer's rules. -
Page 6: Fitting Instructions
excess cable into a 10 cm bundle and securing it to a fixed part of the motorcycle using zip ties or electrician tape. FITTING INSTRUCTIONS In order to fit the charger, first pass the cable of the charger through the fairing / body of the vehicle such that the following is validated in order: The quick release connector has enough leeway to allow the rider to plug / unplug it easily from the... - Page 7 Once the cable is positioned correctly, it is time to connect the battery connectors to the battery terminals. The steps below must be followed in order: Disconnect the negative terminal (black / -) of the battery first. The negative terminal is the main power link, so disconnecting it cuts off power to the motorcycle.
-
Page 8: Safety Notices And Warnings
SAFETY NOTICES AND W ARNINGS SAFETY Use of the iPhone case, RAM mount and charger for navigation or other still means that you need to drive with due care and attention. MAINTENANCE AND SECURITY Do not leave your iPhone device on view when you leave your motorbike. -
Page 9: Technical Specifications
TECHNICAL SPECIFICAT IONS Water resistant at IP54 level Working temperature: -10°C to +55°C Input voltage: DC 6-12V Output voltage: DC 5V Output charging current: 1A Reverse Voltage Protection Short-Circuit Protection Overload Protection 6 mm battery ring clips 2 amp standard automotive blade fuse www.twistyride.com... -
Page 10: Warranty And Support
WARRANTY AND SUPPORT W ARRANTY COVER Twisty Ride Ltd (“Twisty Ride”) warrants to you that the Hardware will be free from defects in workmanship and materials under normal use (“Defects”) for a period of one (1) year from the date that the Hardware was first purchased by you (“Warranty Period”). -
Page 11: Your Legal Rights
Except for the Limited Warranty and to the maximum extent permitted by applicable law, Twisty Ride and its suppliers provide the Hardware “AS IS AND WITH ALL FAULTS”, and hereby disclaim all other warranties and conditions,... -
Page 12: Limitation Of Liability
Hardware even if Twisty Ride Ltd has been advised of the possibility of such damages. Notwithstanding any damages that you might incur... -
Page 13: Ce Marking
Hardware. Twisty Ride Ltd shall not be liable for (i) any fraud on the part of its employees and/or agents; or (ii) any fraudulent misrepresentation on the part of its employees and/or agents. -
Page 14: Copyright Notice
COPYRIGHT NOTICE © 2013 Twisty Ride Ltd Any reproduction of the Twisty Ride logo or name is governed by the laws standardized through the international copyright agreements. www.twistyride.com...
