1 Instruction
1.1 Summary
While you are out, the USB Skype Diverter will divert all
incoming Skype calls to your mobile phone, and it'll divert your
PSTN calls to Skype, you can make calls to Skype contacts and
make calls to any phone all over the world via SkypeOut by your
mobile phone. You can take advantage of Skype and SkypeOut
anywhere and anytime.
1.2 Features
1. Support "Call divert" function (Skype divert to PSTN and
PSTN divert to Skype)
2. PSTN Voice Mail function
3. Send/Receive both Skype calls and regular PSTN calls
4. Phone rings for all incoming Skype and PSTN calls
5. Sound card not needed, echo cancellation, noise reduction
1.3 System Requirements
1. Windows 2000 or XP
2. 400MHz processor and free USB1.1 or USB2.0 port
3. 128MB RAM and 15MB free disk space
4. Any broadband connection or minimum 33.6 Kbps dialup
1
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Sedna USB Skype Diverter
- Page 1 1 Instruction 1.1 Summary While you are out, the USB Skype Diverter will divert all incoming Skype calls to your mobile phone, and it’ll divert your PSTN calls to Skype, you can make calls to Skype contacts and make calls to any phone all over the world via SkypeOut by your mobile phone.
-
Page 2: Physical Features
Connect to PC 3 USB Skype Diverter Installation 3.1 Install the Skype Software (1) Connect the USB Skype Diverter to an available USB port on Note: your computer with the USB Cable If you have previously installed the Skype software, proceed to 3.2... -
Page 3: Basic Function
(1) Insert your Installation CD-ROM into the CD-ROM drive of your computer. (2) Click Install SkypeMate software. Follow the on-screen instructions to install the USB Skype Diverter software. (3) After installing the software, you will be prompted that another program wants to use Skype. Select Allow this program to use Skype and click OK. - Page 4 (6) Call in from Skype, the phone rings (3) Select Phone to Skype to enable this function (7) After 3 rings, all 3 indicators are activated and forward the (4) Set password (Optional) in the Phone password box. e.g,: 123 call to diverted number (minimum 1 maximum 6) 4.2 PSTN Divert to Skype...
- Page 5 Windows. To change the default audio device please do following 4.5 Answer a call steps: The phone connected to the USB Skype Diverter will ring for all (1) Click Windows Start, Control Panel, double-click Sounds incoming Skype and PSTN calls. The corresponding indicator will and Audio Devices.
-
Page 6: Advanced Setting
5 Advanced setting (4) Select Contacts: Click Select Contacts button to open the 5.1 Set Skype to Phone Divert features window, see below: Open the Divert window, there are 4 relative features, see below: There are two boxes: the right one and the left one. The left (1) Skype to Phone: Select to enables the Skype to Phone one displays all your contacts. - Page 7 5.3 Normally Setup Right-click the SkypeMate icon and click Advanced. This will open Advanced window. In this window you can configure the following options: (1) Select or cancel the option Run when Windows starts feature. If you select this feature, the software will be launched automatically when your computer startup.
- Page 8 The voice is played from the PC’s sound card instead of the USB Skype Diverter when I make/answer a call? Solution Problem 2 Execute “Tools->Options->Sound Devices” to open the I can’t play music through the USB Skype Diverter? window as below:...
- Page 9 Set “Audio In” and “Audio Out” to “USB Audio Device”. Problem 4 Skype is running, but the icon of SkypeMate still show as (the phone is green and the outside is grey)? Solution You have selected the wrong option, go to Skype, execute choose “Tools->...
