Summary of Contents for Digimobo FG880
- Page 1 DVB-T Mobile Receiver Manual...
- Page 2 KEY FEATURES __Fan-less design & Aluminum casing --- High performance thermal solution for stable working. __Enhanced antenna design ---Signal amplifying circuit for better receiving quality __More input for multiple connecting--- DVD, GPS, Car-radar… __User friendly OSD---easy to set your preference and find information. CONTENT 2-1.
-
Page 3: Input/Output Ports
HARDWARE INSTALLATION 3-1. EASY INSTALLATION GUIDE 3-2. INPUT/OUTPUT PORTS 3-2-1. Back Panel 3-2-2. Front Panel... -
Page 4: Remote Controller Key Function
3-3. POWER PORT DESCRIPTION Power Connect Description 1--GREEN--hands breaks device----connect to the hands break device or ”ground”. 2--BLUE--12V/150mA switch power output switched by the power button on remote controller. When the TV power is on (the light of IR cable is on), 12V output is on 1 2 3 When the TV power is off (the light of IR cable is off), 12V output is off. - Page 5 BUTTON FUNCTION DESCRIPTION -1-- 1) Program List 1) When there’s no OSD frame, press to enter “Program List”. 2) Select/ OK 2) When there’s a OSD frame, press to select and execute the function. Menu Press to enter “system setup”, “system info”, “EPG” System Toggle key to switch NTSC/PAL system.
-
Page 6: Osd Structure
3-5. OSD STRUCTURE Menu System Setup OSD Language, Time Zone, TV Shape Video Conversion, Subtitle Language Brightness Contrast, Saturation System Info. H/W, S/W Version Service Name, Program Name, Start Time, Brief Introduction, Mini Frame Channel Search Bandwidth, Search (Auto/ Single/ Range) Channel List Channel No, Frequency, Quality, Strength, Mini Frame, Program Name, Edit programs. - Page 7 CHANNEL SEARCH Firstly, please make sure there is digital TV program signal broadcasted, and then press Channel Search , to enter “channel search mode”. The programs searched would be listed in the channel list. The new programs searched in the later scan actions would be added in the channel list, and the old ones would NOT be deleted.
- Page 8 4-1-1. Bandwidth: Usually 8M in Europe/ China/ Russia…, 7M in Australia. 4-1-2. Search Type: 3 search methods including “Range/ Single/ Auto “search. ITEM SEARCH DESCRIPTION Range search The channel numbers need to input (maximum range VHF-H to UHF ) from 8M---“5 to 69”, 7M---“6 to 69”, 6M---“7 to 83”...
- Page 9 4-2.. EUROPE & CHINA CHANNEL / FREQUENCY TABLE 4-2-1 8M Europe Channel Frequency...
- Page 10 4-2-1 7M Australia Channel Frequency...
- Page 11 CHANNEL LIST After program scanning, you’ll see the first frequency TV program shown on the screen. When there’s no OSD frame, press Select/OK to enter “Channel List”. 5-1.. CHANNEL LIST CONTENT 5-1-1. The info. in Channel List Content including (as OSD frame above) ITEM CONTENT DESCRIPTION Quality of Signal...
- Page 12 5-2.. PROGRAM DELETE 5-2-1. Delete current service: move the icon to the program, and press number key 1 , and press Select/OK to execute; or press Return to cancel. 5-2-2. Delete all channels: In the “program list ” frame, press number key 0 , and press Select/OK to execute ;...
- Page 13 OTHER FUNCTION FRAMESDESCRIPTION 6-1.. FUNCTION KEYS 6-1-1. Digital Radio Broadcast--- 6-1-2. Mute---...
- Page 14 6-1-3. Audio System-- 6-2.. NUMBER & DIRECTION KEYS 6-2-1. When there’s no OSD frame, press or enter channel No. to change the channel and see the program’s info.
- Page 15 6-2-2. When there’s no OSD frame, press to adjust the volume. MENU Press Menu to enter ”System Setup”, “System Info”, “EPG”...
- Page 16 7-1.. SYSTEM SETUP ITEM CONTENT DESCRIPTION Menu Language setup the OSD language according to customers’ need. setup the Time Zone from +12 ~ -12 (25 items). Time Zone setup the Television display ratio for 4:3 or 16:9 . TV Shape Video Conversion setup for IRD video output frame size.(This item will auto change according to TV Shape setup and downlink bit stream shape)
- Page 17 7-2.. SYSTEM INFO 7-2-1. Software Version. 7-2-2. Hardware Version.
- Page 18 7-3.. To see preview frames, TV station, program names, program info, and playbill. 7- 5 5 5 5 .. Box to Box software transfer To use the “Box to Box software transfer” we can only transfer the software from Master receiver to Slave receive...
- Page 19 MESSAGES AND FAQ. 8-1.. MESSAGES ITEM MESSAGE DESCRIPTION No Signal TV signals are not locked by tuners. No Service TV signals are locked but no video can be decoded for output. Searching 6 seconds after no TV signal is locked by tuners. 8-2..
