Summary of Contents for SecurityMan SM-140SD
- Page 1 SecurityMan ® SM-140SD 14" CCTV digital color monitor (CRT) User Manual...
- Page 2 SecurityMan will repair or replace the product. This warranty is exclusive and is limited to SM-140SD. This warranty shall not apply to products that have been subjected to abuse, misuse, abnormal electrical or environmental conditions, or any condition other than what can be considered normal use.
-
Page 3: Explanation Of Graphical Symbols
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Explanation of Graphical Symbols The exclamation point within an equilateral trian- gle is intended to alert the user to the presence of important operating and maintenance (servic- ing) instructions in the literature accompanying... -
Page 4: Table Of Contents
Contents Important Safeguards .......5 General ......... .6 Features . -
Page 5: Important Safeguards
Important Safeguards Caution Power source is dedicated on the back of the set. It contains high voltage parts, if the cover is removed, it may cause fire or electric shock. Do not remove the cover by yourself. 1) Read instructions: All the safety and operating instructions should be read before the appliance is operated. -
Page 6: General
7) Object and Liquid Entry: Never push objects of any kind into this monitor through openings as they may touch dangerous voltage points or short-circuit parts that would result in a fire or electric shock. Never spill liquid of any kind on the monitor. 8) Repair (Servicing): Do not attempt to repair this monitor yourself as opening or removing covers may expose you to dangerous voltage or other hazards. -
Page 7: Features
Features • 14" High Quality Pictures • High Resolution NTSC 450 lines / PAL 520 lines • 1 Channel Video Input/Output • 1 Channel Audio Input/Output • Worldwide Multiple System (NTSC/PAL) • On screen digital (OSD) control buttons Specifications 14" CRT Video Input /Output 1 Channel (BNC interface) input/output. -
Page 8: Front Panel Components And Control
Front panel components and controls MENU ADJUST SELECT POWER (LED) Power Switch POWER On/Off Switch. If you press this switch, the monitor will turn on and a green LED will show. Menu Selection Buttons MENU Press this button to access the PICTURE settings menu. - Page 9 Settings range in each Menu Settings range Explanation Menu To select a specific Contrast level Contrast 0 ~ 100 within the setting range To select a specific Brightness level Bright 0 ~ 100 within the setting range To select a specific Color level 0 ~ 100 Color within the setting range...
-
Page 10: Back Panel Components And Control
Back panel components and controls VIDEO LINE AUDIO LINE VIDEO VIDEO LINE Video input/output AUDIO LINE Audio input/output... -
Page 11: Connection
Connection VIDEO LINE AUDIO LINE VIDEO CCD CAMERA Maintenance If the quality of the picture on the COLOR MONITOR is poor and cannot be improved, inspect all system connections and cable runs. Repair should be performed by a qualified technician with adequate test equip- ment and facilities. - Page 12 www.securitymaninc.com...
