Bush Baby TV DVD Player
BBTVDVDPlayer with Night Vision
User Manual
Please read this manual before operating the BBTV Camera and keep
it handy.
The BBTVDVDPlayer
Your purchase should include:
1 x BBTVDVDPlayer
1 x Remote Control for camera (pictured right)
1 x AV-3.5mm RCA connection cable
1 x RCA cable for dvd player
1 x 1 DVD player remote (not pictured)
Bush Baby TV Remote control
The BBTV remote is required to operate the
camera portion of the DVD player. The
functioning of the camera is separate from
the standard DVD player and features. All
options and settings for the BBTV are set
using an on screen menu system controlled
with this remote.
OPERATION OF THE BBTVDVDPlayer
Before operating the device, please
familiarize yourself with the location of
important components.
SD card Slot – found on the back of the unit
towards the left side. It is between the
AC Adapter
Power cable and the standard RCA inputs.
Camera TV Output – Can be found directly
to the right of the RCA and Component
Video connections. It is a black 3.5mm connection that fits the 3.5mm
"headphone" connection found on the 3.5mm to RCA cable included
with your device.
Indicator Light – When recording, a red indicator light will appear on
the front right of the DVD player, directly next to the power button.
This red light will only be illuminated when video is recording.
Basic Operation
1. Insert an SD card in to the SD card slot. There will be some
spring resistance and it will click in to place.
2. Plug in the power cable to a wall outlet
Advertisement
Table of Contents
Summary of Contents for Bush Baby BBTVDVDPlayer
-
Page 1: User Manual
Bush Baby TV DVD Player Bush Baby TV Remote control BBTVDVDPlayer with Night Vision The BBTV remote is required to operate the camera portion of the DVD player. The functioning of the camera is separate from the standard DVD player and features. All... - Page 2 3. Once plugged in, the BBTV will power on, and after booting is Menu Navigation finished, the camera will automatically being recording in To select a menu option, press the “Menu/OK” button motion detection mode. To move up and down between selections, press the “Up” and 4.
- Page 3 o Stop – When the SD card is full, video will stop being 4. Open the Removable Disk drive recorded. 5. Open the “dvr” folder System – Give you basic system information as well as settings 6. Double click the file you want to view to start playing the saving, restoring, or system defaults.
