INSTA
P
r
o
p
P
r
o
This manual must be read and the requirements carried out
SIG MARINE RESERVES THE RIGHT TO MAKE CHANGES TO PRODUCTS
QUALITY INSPECTED BY-
L LATION AND OPERATING MANUAL
L
D
i
r
e
c
t
D
i
r
e
c
t
a
n
e
F
p
a
n
e
F
to ensure satisfactory performance.
OR DOCUMENTS AT ANY TIME
Doug & Don
V
e
n
t
P
V
e
n
t
P
i
r
e
p
l
a
c
i
r
e
p
l
a
c
Sig Marine Products
# 407-204 Cayer St. Coquitlam
B.C. Canada V3K 5B1
www.sigmarine.com
info@sigmarine.com
T: 800 659 9768
9
0
0
0
9
0
0
0
e
/
H
e
a
e
/
H
e
a
Nov 5/2008
DATE-
t
e
r
t
e
r
Advertisement
Table of Contents
Summary of Contents for Sig Marine DVP9000
- Page 1 INSTA L LATION AND OPERATING MANUAL This manual must be read and the requirements carried out to ensure satisfactory performance. SIG MARINE RESERVES THE RIGHT TO MAKE CHANGES TO PRODUCTS OR DOCUMENTS AT ANY TIME Doug & Don Nov 5/2008...
-
Page 2: Table Of Contents
Important Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. Improper use of this gas appliance can cause serious injury or death from burns, fire, explosion, carbon monoxide poisoning and oxygen depletion. Save this manual for future reference Contents Warnings and Disclosures pg-2... -
Page 3: Warnings And Disclosures
Warnings and Disclosures - Follow all installation and operating procedures. - The propane heater requires an installed flue for correct operation. Do not attempt to operate the heater without the flue chimney installed correctly as required in this manual. - If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. -
Page 4: Safety Features
General This direct vent heater / fireplace is a clean burning gas appliance for use on board small vessels. The heater is furnished with a double walled vent pipe and cap. Fresh air is pulled from outside, through the outer pipe into the combustion chamber. Exhaust gas leaves the vessel through the inner pipe, while exchanging heat through the wall of the outer pipe to the cabin. - Page 5 This increases heating efficiency and provides good circulation of hot air. Mounting the heater lower will allow for more efficient circulation of heat in the cabin. The flue pipe of this heater is 28” long (71cm). Extensions are available in 10” (25.4cm) and 28”.
- Page 6 Avoid low-points in vent pipe Clearance to surrounding surfaces Bending and installation of the vent pipe...
- Page 7 Installing the Flexible Pipe Four springs are installed between the inside and outside pipe to ensure that an even air space is provided. It is important that two springs be located at any bend in order to prevent the pipes from touching. The length of pipe supplied is approximately 28" (71cm). The pipe can be stretched to provide 1-2 additional inches.
- Page 8 WARNING: Do not install the external flue cap within 20 inches (500mm) of a refueling fitting or fuel tank vent.
-
Page 9: Gas Supply
Gas Supply and Connection low pressure The heater operates only on LPG gas (11"w/c / 0.5psi / 27.4 mB). If there is a propane fuel system installed a separate supply line must be supplied for the heater. This line must be equipped with a low-pressure regulator ( Part No. 15203). Connect to the 3/8"... -
Page 10: Electrical
- The diagram is to illustrate a typical installation only and should not be used to illustrate any particular regulatory code, insurance requirement or to override manufacturer’s instructions on any fittings or components. - Install your propane system in accordance to local, national or industry specific regulations. - Retain the installation and owner’s manual for your gas components such as the solenoid and regulator. - Page 11 -10- 1) Open heater door 2) Turn GAS knob to LOW ( only) 3) Depress knob and light burner manually ( It may be necessary to keep clicking the lighter in order to keep the flame going to overcome the strong draft). 4) Keep knob depressed for 20/25 seconds (once the flames will stay on).
-
Page 12: Troubleshooting
-11- Troubleshooting WARNING: WHAT TO DO IF YOU SMELL GAS • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your vessel. • Leave the boat and ventilate with the appropriate equipment. •... - Page 13 -12- Additional Accessories S19-000 inch (70cm) Direct Vent Pipe Extension S19-005 (approx.)including coupling inch (25.4cm) Direct Vent Pipe Extension (approx.)including coupling 15203 Low pressure regulator only 15204 Low pressure regulator and mounting kit (For use when there is no onboard propane system - for use with propane bottles) 15205 10ft (3 m) CGA/AGA propane hose...
-
Page 14: Limited Warranty
If any part of your new product fails because of a manufacturing defect within the warranty period Sig Marine offers to replace said parts free of charge provided, however, that such parts have not been improperly repaired, altered or tampered with or subjected to misuse, abuse or exposed to corrosive conditions. -
Page 15: Warranty Form
WARRANTY FORM I have read and understand the Limited Warranty and the Instruction Manual and agree to the terms and conditions (please print) Date…………………………………………………………………………… Purchaser’s Name……………………………………………………………. Address……………………………………………………………………….. ………………………………………..……………………………………….. Model Name……..SIG…DVP9000…Propane…Fireplace/Heater..…… Serial Number……………………………………………………………….. Date Of Purchase…………………………………………………………….. Signature………………………………………………………………………. Name of Seller……………………………………………………………..Seller Location…………………………………………………………………...
