Universal wireless monitoring system

Advertisement

User Manual UWMS-01 Version 2.3

Table of Contents

I.
A. What is the UWMS-01?.............................................................................................
B. What is in the Box?....................................................................................................
C. UWMS-01 at a Glance........................................................................................................... 4
II. Installation Overview.................................................................................................................. 5
A. Network Status.....................................................................................................................
B. Network Connection............................................................................................................. 10
C. Dry Contact Set-up................................................................................................................ 13
D. UWMS-01 Set-up................................................................................................................... 17
E. Firmware Update................................................................................................................... 20
F. Administrator......................................................................................................................... 21
G. UWMS-01 Information......................................................................................................... 22
H. Logout..................................................................................................................................... 22
IV. Troubleshooting........................................................................................................................... 23
A. Electrical Specifications......................................................................................................... 24
B. Environmental Specifications.............................................................................................. 24
C. Mechanical Specifications.................................................................................................... 24
A. General Precaution............................................................................................................... 25
B. Radio Frequency (RF) Energy..............................................................................................
C. Specific Absorption Rates (SAR).........................................................................................
D. FCC Notice............................................................................................................................... 25
E. Manufacturer's Limited Warranty ...................................................................................... 26
VII. Glossary ......................................................................................................................................
2
3
9
25
25
27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the uwms-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sym uwms-01

  • Page 1: Table Of Contents

    Table of Contents Introduction A. What is the UWMS-01?..................... B. What is in the Box?....................C. UWMS-01 at a Glance…………………………………………………………………………………………….. 4 II. Installation Overview…………………………………………………………………………………………………… 5 III. Setting up the UWMS-1 Using Graphic User Interface A. Network Status……………………………………………………………………………………………………… B. Network Connection………………………………………………………………………………………………. 10 C.
  • Page 2: Introduction

    HTTP-based devices with standard Ethernet interface can be connected to the UWMS-01. Using the UWMS-01 Sprint will be able to access the Devices connected to the UWMS-01 to monitor them or change their parameters without visiting the physical site. This wireless monitoring and control capability enables Sprint to proactively diagnose and troubleshoot problems remotely even before a customer complaint is received.
  • Page 3: What Is In The Box

    User Manual UWMS-01 Version 2.3 B. What is in the Box? Item Part Number UWMS-01 Main Body UWMS01 Ethernet Cable UWMS01ET Mounting Screws UWMS01SC Dipole Antenna UWMS01AT N to SMA Connector Adaptor UWMS01NS DC Power Cord UWMS01DC AC Power Cord...
  • Page 4: Uwms-01 At A Glance

    User Manual UWMS-01 Version 2.3 C. UWMS-01 at a Glance © 2008~2010 SYM. All rights reserved. Page 4...
  • Page 5: Installation Overview

    User Manual UWMS-01 Version 2.3 II. Installation Overview Drawing 1 shows a typical installation when the UWMS-01 is set up with its supplied dipole antenna. -85 dBm Make sure the received signal strength is greater than at the installation site.
  • Page 6 UWMS-01 and the Device does not exceed approximately 328 feet (100 meters); or (3) You can place the UWMS-01 near the Device but place the supplied dipole antenna where there is -85 dBm a Sprint signal greater than using an extension coaxial cable.
  • Page 7 User Manual UWMS-01 Version 2.3 b. The UWMS-01 can be powered by the supplied AC adapter (UWMS01AC) or by DC power cord (UWMS01DC) if Device has a 12VDC outlet. Using AC power is recommended. c. Using the supplied Ethernet cable, connect your laptop to the UWMS-01’s Ethernet port.
  • Page 8 User Manual UWMS-01 Version 2.3 Power LED is lit in solid green Status LED blinks periodically when in normal operation PPP LED is lit in solid green when PPP session is on Data LED blinks in green only when data is being transmitted...
  • Page 9: Setting Up The Uwms-1 Using Graphic User Interface

    The Network Device Status displays the information of the Devices connected to the UWMS-01. A total of 32 Devices can be displayed in the table. When the UWMS-01 receives heartbeats from the Devices periodically, the Device information is in black. If more than 24 hours pass without receiving a single heartbeat from a Device, the Device is indicated in red, indicating inactivity.
  • Page 10: Network Connection

    You can add Devices to the UWMS-01 either automatically or manually. When you connect a Device, simply wait until the Device starts sending out a heartbeat to the UWMS-01. If the Device’s Site ID and Static IP are set up correctly, and the Device is sending out a heartbeat, the UWMS-01 will receive the Device’s heartbeat information and register the Device automatically.
  • Page 11 User Manual UWMS-01 Version 2.3 You can add up to 32 different Devices to the UWMS-01. If you attempt to add more than 32 Devices, the following dialogue box will appear: Picture 4. Devices Maxed Out Dialogue Box Site ID: Device’s unique Cascade code provided by Sprint. The Site ID can be up to 35 digits. The Site ID can be any combination of ASCII characters except the following 9 characters.
  • Page 12 Type: Alpha-numeric up to 20 characters indicating Device type, e.g., RF Repeater, DAS, Router, UPS, etc. (2) Network Device Status: The table displays all the Devices connected to the UWMS-01. A maximum of 32 Devices can be displayed in the table. If you want to remove a Device, simply click the red button in the Delete column.
  • Page 13: Dry Contact Set-Up

    UWMS-01 through the UWMS-01’s dry contact port. The UWMS-01 can receive up to four (4) dry contact alarms and convert these to one of the five (5) SNMP alarms defined in the Sprint MIB.
  • Page 14 Device with dry contact alarm. The supplied DE-15 male to male cable only works with the MA 410. You may need a customized cable to have your Device work with the UWMS-01. Please contact our technical support if you need further assistance.
  • Page 15 2. Connect top light and side Marker alarm (N.O. and C) to Port 1 ~4 of UWMS-01. Top Light Alarm : When you use Port 2, C is connected to pin #12 and N.O. goes to pin #7.
  • Page 16 User Manual UWMS-01 Version 2.3 3. Go to Dry Contact Setup Menu: Select the port to be used. (In this case Port 2 for top light and Port 3 for side marker); Enter Site ID (or Cascade code); Select “RF Power” alarm from Alarm Name to be associated with the top light alarm and “Over Temperature”...
  • Page 17: Uwms-01 Set-Up

    (1) Site ID & Manager IP: i. Site ID (Cascade Code): Type in the unique Site ID (Cascade Code) assigned by Sprint. “SYM” as a prefix will be automatically added to Site ID you entered. No need for you to enter the prefix.
  • Page 18 IP Address:8888/device_setup.asp (New) Picture 10. UWMS-01 IP Address Change Dialogue Box The Member is not allowed to change the UWMS-01’s IP address. Only the Administrator can change the IP address. ii. Subnet Mask: The default Subnet Mask is 255.255.255.0.
  • Page 19 The UWMS-01 automatically reboots itself every 12 hour to protect itself from an unexpected interruption of operation and memory shortage. (8) View Log: By clicking View Log, you can see some vitals of the UWMS-01 in text format. (9) Load Configuration: By clicking Load Configuration, you can download the configurations that you had previously saved.
  • Page 20: Firmware Update

    (1) File Name: Click Browse and locate the firmware on your laptop. Then click the Update button. (2) Update: When the firmware is downloaded and updated successfully, the following dialogue box will appear. When you click OK, the UWMS-01 will restart. Picture 14. Update Successful Dialogue Box © 2008~2010 SYM. All rights reserved.
  • Page 21: Administrator

    User Manual UWMS-01 Version 2.3 F. Administrator You can manage user accounts that can access the UWMS-01 by assigning different levels of access rights. Picture 15. Administrator Menu Screenshot The Administrator Menu is only available when you are logged in as the Administrator (Super User).
  • Page 22: Uwms-01 Information

    User Manual UWMS-01 Version 2.3 G. UWMS-01 Information Picture 16. UWMS-01 Information Menu Screenshot (1) UWMS-01 Information: Displays the UWMS-01’s system information, including its firmware version and serial number. Please have the information handy, when you contact SYM’s technical support.
  • Page 23: Troubleshooting

    Make sure the Power LED is lit. Turn off the UWMS-01 and turn it back Can’t access UWMS-01’s GUI Make sure the Ethernet cable is connected securely both to the UWMS- 01 and your laptop. The small green status light next to the Ethernet port should be lit.
  • Page 24: Technical Specifications

    User Manual UWMS-01 Version 2.3 V. Technical Specifications A. Electrical Specifications Power Supply AC Power Supply  Input: AC 100 ~ 240V 50/60Hz DC Power Supply (Direct DC Supply)  Input: 12V±1V, 2A Power Consumption  12[W] Max Ethernet Standard Compatibility: IEEE802.3 CSMA/CD ...
  • Page 25: Safety And Warranty Information

    B. Radio Frequency (RF) Energy The UWMS-01 is a radio transmitter and receiver, just like your mobile phone. When it is turned on, it receives and transmits radio frequency (RF) signals. The RF power level can range from 0.006 watt to 0.25 watt.
  • Page 26: Manufacturer's Limited Warranty

    FIVE (5) YEAR LIMITED WARRANTY: For a period of five (5) years from the date of original purchase, SYM will, at its option, either repair or replace a defective Product (with new or rebuilt parts/replacement).
  • Page 27: Glossary

    User Manual UWMS-01 Version 2.3 ORAL, WITH RESPECT TO THE PRODUCTS. THE DURATION OF IMPLIED WARRANTIES, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO THE DURATION OF THIS EXPRESS WARRANTY. SYM Technology, Inc. Attention: Customer Service Phone: (626) 394-6630 Email: support@symtehcnology.com...
