Drive Recorder SZ-1000
User's Manual
Version 1.001
[The information contained in this manual was correct at the time of publication. However, as our engineers are always
updating and improving our products & software, your device's hardware & software may have a slightly different
appearance or modified functionality than presented in this manual.]
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-Corder SZ-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Corksport X-Corder SZ-1000

  • Page 1 Drive Recorder SZ-1000 User's Manual Version 1.001 [The information contained in this manual was correct at the time of publication. However, as our engineers are always updating and improving our products & software, your device’s hardware & software may have a slightly different...

  • Page 2: Table Of Contents

    - TABLE OF CONTENTS - • What’s in the Box · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3 •...

  • Page 3: What's In The Box

    What’s in the Box • ※ Before getting started, please check to see that your X-Corder package includes the following items. • X-Corder Unit • SD Card • 12 Volt Vehicle Power Cable • Adhesive Tape • Mount Clip • User's Manual If you are missing any parts, please contact your dealer immediately.

  • Page 4: Description & Function

    • Description & Function 1) Camera Lens: Capture video image. Note: Please clean the camera lens before using to avoid foreign materials blocking the lens. 2) GPS Receiver: Built in GPS receiver receives real-time GPS satellite data. 3) Hinge button: Control viewing angle of the unit. 4) SD Memory Card Slot: Insert SD memory card into the slot before power on.

  • Page 5: Key Features

    • Key Features ※ Recording accident video image When an accident occurs while driving, the device detects the shock automatically by way of a 3-axis accelerometer, and records the video 15 seconds before and 15 seconds after the event took place.

  • Page 6: Installation Precautions

    • Installation Precautions ※ Please read the following content thoroughly before installation. 1. Be sure that all components were included in the packaging. 2. Make sure to power off the vehicle before proceeding with installation. 3. Do not break or damage power cable. 4.

  • Page 7: Installation Procedure

    • Installation Procedure ※ The basic mounting location of the product is top or bottom of front windshield of vehicle. Attach the product on the position where safe driving is not obstructed. 1. Locate the area in which you choose to install the device. Remove one side of the tape and stick to device.

  • Page 8: Installation Warnings

    • Installation Warnings ※ Please read the following carefully to ensure proper installation and use. • Do not disassemble, repair or alter the device. This will void the warranty. • When cleaning the inside of a vehicle, do not spray water directly onto the device. It may cause damage, fire or electric shock.

  • Page 9: Led Indicator And Button

    • LED Indicator & Button 1. LED Indicator Content Status Description Power off or failure POWER Working by power supply or battery Blink slowly Indicates Parking Surveillance Mode, synchronized with SD CARD LED Empty SD Card or recognition error Blink slowly Indicates Parking Surveillance Mode, synchronized with POWER LED SD CARD Blink...

  • Page 10: Product Upgrade

    • Product Upgrade ※ The product may be changed or improved for content without obligation to notify any person or organization of such changes or improvements. Visit website or call the service center of dealer or manufacturer for current updates and supplemental information concerning the use and operation of this device.

  • Page 11: Pc Viewer Setup

    • PC Viewer Setup ※ Follow these instructions to install PC Viewer program 1. Insert SD Card into the SD Card slot of the device. (The PC Viewer Program and Manual will be copied to SD Card.) 2. Connect SD Card to computer by SD Card reader. 3.

  • Page 12: Pc Viewer: Main Screen

    • PC Viewer Screen 1. Main screen: Displays video playback. 2. Speed & Acceleration: Displays speed and acceleration information. 3. Map: Displays the location of current playback video image. 4. GPS Information: Displays location information by text. 5. File list screen: Displays the file list being played back. •...

  • Page 13: Pc Viewer: Add File List

     PC Viewer: Add File List ※ Adding file list by open file 1. Execute “PC Viewer” after connecting SD Card to computer. 2. Click file open button ( ) and Select files to playback from the SD Card 3. The selected files are listed in the file list screen 4.

  • Page 14: Pc Viewer: Delete File List

    • PC Viewer: Delete File List 1. Execute “PC Viewer” after connecting SD Card to computer. 2. Select the file to delete and Click the delete ( ) button. 3. To delete all file lists, Click the delete all ( ) button.

  • Page 15: Pc Viewer: Display Video Image

    • PC Viewer: Playback Video Image 1. Double click the file to playback or Click the “Play”( ) button after selecting file 2. Click PAUSE ( ) button for pause 3. Click STOP ( ) button to end playback 4. Click the scroll bar to playback specific time. 5.

  • Page 16: Pc Viewer: Driving History Mode

    • PC Viewer: Driving History Mode 1. Click Driving History Mode button ( ), then the main screen shows you the driving history. 2. Click the open file button ( ) and select the driving history file (*.dat) 3. To see driving route, select the specific area that you want to see, and click the “driving route” ) button.

  • Page 17: Pc Viewer: Password Setup And Release

    • PC Viewer: Password Setup and Release 1. Click the password setup ( ) button to create a password to protect from unauthorized use. 2. Select a folder on the SD Card to setup a password. 3. Type in your password and retype in the Confirm Password box. Click Save. 4.

  • Page 18: Pc Viewer: Setup Directly Folder

    • PC Viewer Setting 1. Click the Setting ( ) button. 2. Select the folder to download the SD Card Data. 3. Select the folder to capture screen image. 4. Select the folder to save decrypted video image. 5. Select desired language (Korean / English / Japanese) 6.

  • Page 19: Pc Viewer: Setup User's Information & Option

    • PC Viewer: Setup User’s Information & Option 1. Click the settings ( ) button. 2. Type in the driver name 3. Enter the license plate number 4. Setup the impulse level with quick setting or manual setting. 5. Setup the frame rate of video image to be saved. ★...

  • Page 20: Pc Viewer: Event Log

    • PC Viewer: Event Log 1. Click the Event Log ( ) button 2. Click the "Search" button and Select the folder where the event file is stored. 3. Veiw the event log. 4. To save event log, click "Save File As" button, then it will be saved as a text file in the designated folder.

  • Page 21: Product Specification

    • Product Specification • Camera: Color CMOS Digital Camera • Pixel: 320K pixel • Video resolutions: 640x480 (VGA) • GPS: Internal GPS Module • G-Sensor: Internal 3D G-Sensor (Collision, Q-brake, Q-acceleration) • Data Storage: SD Memory Card (Min. 512MB, Max. SDHC 16GB) •...

  • Page 22: Troubleshooting

    • Troubleshooting ※ Please look at the following points when the device is not working properly. 1. Please check the vehicle power cable if you do not see the POWER LED turned on. 2. Please make sure the provided SD Card in loaded in the device. 3.

  • Page 23: Limited Warranty

    • Limited Warranty 1. The company will repair or replace any defective part or parts which prove to be defective in workmanship and/or materials and not due to abnormal or improper usage, at its sole discretion within the warranty period (one (1) year from the date of original purchase). 2.
