  • Page 1 HW 90400 Version 1.02 User Guide...
  • Page 2 This document and its contents shall not be reproduced or transferred in any form without express permission. Compensation will be claimed for any infringement. All rights reserved in the event of patenting or registration of utility models. © Höft & Wessel AG 2012 Subject to amendment, errors excepted BHB_skeye-emotion_HW90400_1-02_EN.doc...

  • Page 3: Table Of Contents

    Suspend Mode (Standby Mode) ............22 3.4.2.2 Automatic Standby – Power Supply ..........24 3.4.2.3 Complete Power Off by Removing the Battery........25 Initial Steps ....................26 Operating the skeye.e-motion with the Stylus ..........26 Microsoft Windows CE – Basics ..............27 4.2.1 Start Screen..................27 4.2.2 Start Menu..................27 4.2.3...
  • Page 4 GPS Module .....................50 USB Cradle/Car Cradle HW 51400 .............. 51 Technical Data..................52 Placing the skeye.e-motion into the Cradle ..........53 Connecting the USB Cradle to the Desktop PC ..........53 Communication skeye.e-motion ⇔ PC ............54 Connection of the Cradle in the Vehicle............54 Technische Daten ..................

  • Page 5: Introduction

    INTRODUCTION Document Information Introduction The shock- and dirt resistant skeye.e-motion supports all applications in field services and logistics. Due to protection class IP45 (dust and humidity) and the fall protection (1.20 m) the skeye.e-motion can also be used in demanding environments.

  • Page 6: Readership

    Readership The documentation is intended for people operating the skeye.e-motion. Intended Use The skeye.e-motion has been designed for use in the commercial sector and for acquiring and transferring data within buildings or vehicles or outside under moderate climate conditions. The skeye.e-motion is not intended for distribution to private households.

  • Page 7: Safety Notes For The Lithium-Ion Battery

    – lifetime maintenance-free and does not need special care. ♦ Do not try to open, repair or modify your skeye.e-motion. The manufacturer will not be liable for any damage caused in that way. Apart from other things, the function for correctly charging the battery may be influenced.
  • Page 8 INTRODUCTION Safety Notes subsequently discharged. Otherwise, its performance will be degenerate and its service life will be decreased. ♦ The storage temperature must not be below –20 or above +50°C. Ambient conditions: ♦ The temperature may not be outside the admissible operating and storage temperature range of -20 to +50 degrees centigrade.
  • Page 9 INTRODUCTION Safety Notes ♦ Do not use the battery in any device other than those specified in this manual. Depending on the device being used, doing so may cause abnormal current flow, leakage of battery fluid, heat generation, bursting or fire. ♦...

  • Page 10: Safety Notes On The Usb Cradle / Car Cradle

    INTRODUCTION Safety Notes Old batteries as well as device storage batteries must not be disposed of with your household waste. Consumers are obliged to return batteries to a suitable collection point (trade, municipality). Device batteries can be returned to Höft & Wessel after use at no cost as well.

  • Page 11: Safety Notes On The Power Supply

    1.6.5 Safety Notes on the Imager with LED Aimer (optional) If your skeye.e-motion is equipped with an imager module with integrated LED aimer, please observe the following notes: The LED light source is classified as a class 1 LED according to the following standard: IEC60825-1 ED 1.2:2001.

  • Page 12: Safety Notes On Wireless Lan/Bluetooth

    ♦ Switch off your skeye.e-motion in hospitals or similar places to prevent an interference with medical devices. ♦ Switch off your skeye.e-motion (see chapter 3.4.2) at places where you are advised to switch off your mobile phone. ♦ The unit may affect heart pacemakers.

  • Page 13: Disposal

    For disposal, return the device to the Höft & Wessel AG. Explanations on this Manual The User Manual is designed to enable you to get your skeye.e-motion up and running quickly and is structured as follows: ♦...

  • Page 14: Registered Trademark

    INTRODUCTION Explanations on this Manual 1.8.2 Registered Trademark The following terms and names used in this manual are registered trademarks and products of the corresponding companies: • Microsoft®, Windows®, Windows NT®, Windows , Windows CE®, Windows CE.NET®, Windows® Embedded CE 6.0 and ActiveSync® are registered trademarks of the Microsoft Corporation, USA.

  • Page 15: Skeye.e-Motion

    SKEYE.E-MOTION Views skeye.e-motion Views 2.1.1 Front View Display Light sensor Navigation On/Off button Freely Loud speaker allocable function keys Fig. 1: Front view and key assignment 2.1.2 Side View Fig. 2: Upper side Belt suspension Stylus device Belt suspension device Battery unlocking Fig.

  • Page 16: Rear View

    SKEYE.E-MOTION Accessories 2.1.3 Rear View Stylus Reset push button System interface Battery Imager/Camera Fig. 4: Rear view Accessories • Battery • Power supply unit • Cigarette lighter adapter Cradle • USB cradle HW 51400 (incl. desktop holder, power supply unit and USB cable) •...

  • Page 17: Taking Into Operation

    TAKING INTO OPERATION Inserting the Micro SD Card Taking into Operation Inserting the Micro SD Card A Micro SD card as well as a MicroSDHC card can be used as storage medium. • Loosen the 2 Torx screws (O) of the card lid (TX 6).

  • Page 18: Insertions Of The Sim Card

    TAKING INTO OPERATION Insertions of the SIM card Insertions of the SIM card The SIM card necessary for the /GPRS/EDGE/UMTS/HSDPA function is inserted into the designated slot under the battery. • Loosen the Torx screws (O) of the card lid (TX •...

  • Page 19: Battery

    TAKING INTO OPERATION Battery Battery The mobile terminal comes with a separate battery. 3.3.1 Inserting the Battery There is only one way to insert the battery. Place the battery onto the device near the unlocking button. Now, push the battery along the guide support towards the contacts until it audibly engages.
  • Page 20 TAKING INTO OPERATION Battery This figure shows a correctly inserted battery. Fig. 7: inserting the battery Prior to initial operation the battery should be charged completely. To do so, insert the mobile terminal including battery into the USB cradle (connected to power) or car cradle.

  • Page 21: Replacing The Battery

    Fig. 9: Changing the battery 3.3.3 Charging the Battery The battery is automatically charged inside the skeye.e-motion if your mobile terminal is placed into an USB or car cradle supplied with power. The Systray displays one of the following symbols: Battery is charging The battery is below the first voltage level.

  • Page 22: Switching-On/Switching-Off The Skeye.e-Motion

    Suspending a device means that it is inactive and thus consumes less power. A suspended skeye.e-motion can be activated any time. While suspending information in the RAM of the skeye.e-motion is maintained. If the power supply is interrupted e.g. due to a discharged battery, information in the RAM gets lost.
  • Page 23 Task bar Fig. 11: Start menu 2. Tap Suspend. The skeye.e-motion will be suspended in its current state. All open windows, documents, workbooks etc. are not closed but maintained in the working memory. The skeye.e-motion is suspended (Standby Mode). When you switch on the device via the round scan key in the middle again, the system returns to the last status as long as the power supply has not been interrupted e.g.

  • Page 24: 3.4.2.2 Automatic Standby - Power Supply

    TAKING INTO OPERATION Switching-on/Switching-off the skeye.e-motion 3.4.2.2 Automatic Standby – Power Supply Use the Power Supply function to save battery life. If you do not operate the unit for a certain time e.g. the display will be dimmed or the unit is set to suspend mode.

  • Page 25: 3.4.2.3 Complete Power Off By Removing The Battery

    If the buffer is not completely charged, the time decreases correspondingly. We recommend before removing the battery: 1. Save data first. 2. Suspend the skeye.e-motion. Then wait for about 10 sec. Only then the RAM is sustained. 3. At last, remove the battery.

  • Page 26: Initial Steps

    Operating the skeye.e-motion with the Stylus Initial Steps 1. Insert the battery (see chapter 3.3.2). 2. Switch on the skeye.e-motion by pressing the On button (top left). 3. Take out the stylus (see next figure). Operating the skeye.e-motion with the Stylus The stylus functions as a computer mouse.

  • Page 27: Microsoft Windows Ce - Basics

    INITIAL STEPS Microsoft Windows CE – Basics Microsoft Windows CE – Basics This mobile terminal supports the following Windows CE version: Windows Embedded CE 6.0 (copy deadline, subject to changes). 4.2.1 Start Screen Apart from the application program the Mobile Terminal features the Windows CE surface.

  • Page 28: Workspace Symbols

    INITIAL STEPS Microsoft Windows CE – Basics 4.2.3 Workspace Symbols The following list contains an explanation of the symbols which can usually be found on a Windows CE surface: Symbol Program Description Displays the storage locations available on the mobile terminal e.g.

  • Page 29: Right Mouse Button Function

    INITIAL STEPS Microsoft Windows CE – Basics 4.2.5 Right Mouse Button Function The right mouse button is used to open popup menus that support functions like Copying, Deleting, and Sending. To call the functions of the right mouse button tap the element for which you want to perform the action and keep the stylus pressed.

  • Page 30: 4.2.7.1 Calibrating The Touch Screen

    INITIAL STEPS Microsoft Windows CE – Basics 4.2.7.1 Calibrating the Touch Screen This function is required to fine-tune the touch screen; the better the touch screen is calibrated the more precisely it will react. When calibrating the touch screen note the following: •...
  • Page 31 INITIAL STEPS Microsoft Windows CE – Basics 7. Close the Stylus Properties menu. 8. Please answer the question with [Yes] if the settings should be stored persistently. Over time, the touch screen, and thus its calibration, may reset somewhat. Should you notice that the touch screen does not respond as precisely as before, repeat the calibration procedure.

  • Page 32: 4.2.7.2 Setting The Brightness

    INITIAL STEPS Microsoft Windows CE – Basics 4.2.7.2 Setting the Brightness 1. Launch: Start ⇒ Settings ⇒ Control Panel The "Control Panel" menu appears. 2. In the Control Panel window double tap the following symbol: The “Backlight” window appears. Fig. 17: Backlight 3.

  • Page 33: Further Functions And Settings

    HWImagerTool can be used to scan into any text field (e.g. WordPad). Calmly and angularly hold the skeye.e-motion in the direction of the barcode to be scanned. A peep indicates that the entry of the barcode has been successful. The gap should amount to about 5-10 cm.

  • Page 34: Calling Sysbackup

    FURTHER FUNCTIONS AND SETTINGS SysBackup 5.2.1 Calling SysBackup Start SysBackup via • Start ⇒ ⇒ ⇒ ⇒ Run ⇒ ⇒ ⇒ ⇒ SysBackup (enter SysBackup) or • Start ⇒ ⇒ ⇒ ⇒ Programs ⇒ ⇒ ⇒ ⇒ System ⇒ ⇒ ⇒ ⇒ SysBackup The "SysBackup"...

  • Page 35: Creating A Backup

    FURTHER FUNCTIONS AND SETTINGS SysBackup 5.2.2 Creating a Backup Copy all important data to the "\FlashStorage" folder or its subfolders. Everything must be backed up to ensure system settings are not lost after a battery has fully discharged or there has been a total shutdown. 1.

  • Page 36: Restoring The Backup

    FURTHER FUNCTIONS AND SETTINGS SysBackup 5.2.3 Restoring the Backup Backup data saved with SysBackup should only be restored in one image and on the same hardware under which they were created, as otherwise problems may occur. 1. Open the SysBackup program (see chapter 5.2.1). 2.

  • Page 37: Deleting A Backup

    FURTHER FUNCTIONS AND SETTINGS SysBackup 5.2.4 Deleting a Backup 1. Open the SysBackup program (see chapter 5.2.1). 2. Tap [delete]. The message "Erase backup files?" appears. Fig. 23: Erase backup files 3. Click [Yes] to confirm the message. The content of the \FlashStorage\SYSBAK directory will be deleted. 20.04.2012 •...

  • Page 38: System Info

    FURTHER FUNCTIONS AND SETTINGS System Info System Info Launch: Start ⇒ Programs ⇒ Utilities ⇒ System Info Fig. 24: SysInfo ♦ The Versions tab displays information on operating system, serial number, and battery parameters. ♦ The Memory tab displays information on physical memories, drives and data memories.
  • Page 39 FURTHER FUNCTIONS AND SETTINGS System Info SysInfo Report File When calling the system information a report file is automatically created containing the same information as SysInfo. When you tap [OK], the "Save as" dialog box opens up and you can save the file as "SysInfoReport.txt"...

  • Page 40: Radio

    1. Set up a Wireless LAN access point that provides access to a LAN or the Internet. Follow the instructions of your Wireless LAN access point documentation. 2. Launch on the skeye.e-motion: Start ⇒ Settings ⇒ Control Panel ⇒ Network and Dial-up Connections Start ⇒ Settings ⇒ Network and Dial-up Connections 3.
  • Page 41 RADIO Wireless LAN 4. Activate Obtain an IP address via DHCP. DHCP is activated by default. Fig. 26: Wireless LAN | IP address 5. To manually set the IP addresses enter the addresses under “IP address”, “Subnet mask”, “Gateway” and tab “Nameservers”. 6.

  • Page 42: Wlan Configuration

    RADIO Wireless LAN 6.2.2 WLAN Configuration 1. Double-tap the network symbol in the Systray. The following window appears. The header displays the name of the module used. Fig. 27: Internet protocol (TCP/IP) 2. Tap the Wireless Information tab. The following tab appears: Fig.
  • Page 43 RADIO Wireless LAN Symbol Meaning Network not available Available network connected Network available Fig. 29: Network symbols 3. On the Wireless Information tab select a network and double-tap the corresponding selection for further options. The following window appears: Fig. 30: Wireless – Properties 4.

  • Page 44: Entering The Network Id

    RADIO Wireless LAN • The encryption type is set under Encryption. Under Authentication, set the method used by a Wireless LAN client to logon to an access point (e.g. WPA). • The network key and the network name (SSID) must be the same as used for the configuration of the access point.

  • Page 45: Gsm Control

    RADIO GSM Control GSM Control If you wish to dial into the internet, for example via GSM/GPRS/EDGE/UMTS/HSDPA, further settings are necessary. First, please check if the GSM module is switched on. 1. Select: Start ⇒ Settings ⇒ Control Panel 2. Double tap GsmControl. The check mark at "Enable GSM module"...
  • Page 46 RADIO GSM Control 6. Double tap the active GSM symbol at the bottom of the Systray. The following menu is displayed: 7. Select "Connect" to establish a connection via GPRS. The GPRS connection is established. Further comment: With "Connect" or "Disconnect" an Internet connection is activated or deactivated. The following symbols in the Systray explain the status: = not connected = connected...

  • Page 47: Further Settings

    RADIO GSM Control 6.3.2 Further Settings 6.3.2.1 Persistent Setting of the PIN Number With every new registration and after a suspend mode the PIN number is asked. In order to avoid its entry each time, please proceed as follows: 1. Call: Start ⇒ Settings ⇒ Control Panel ⇒ GsmControl 2.

  • Page 48: 6.3.2.2 General Settings

    RADIO GSM Control 6.3.2.2 General Settings 1. Call: Start ⇒ Settings ⇒ Control Panel ⇒ GsmControl 2. Select index card General. The following settings are available: Enable GSM module Enable the GSM module Show GSM tray icon Show the GSM symbol in the systray Keep powered at suspend* Power supply of the GSM module also during suspend mode (battery life time).

  • Page 49: 6.3.2.3 Apn

    RADIO GSM Control 6.3.2.3 APN 1. Call: Start ⇒ Settings ⇒ Control Panel ⇒ GsmControl 2. Select index card APN. Here you can change the APN afterwards, e.g. in case of wrong entries or a new provider 6.3.2.4 GSM Info Call: Start ⇒...

  • Page 50: Gps Module

    RADIO GPS Module Data rates: = 2G GPRS = 2.5G EDGE = 2.75G UMTS = 3G HSDPA = 3.5G Depend on provider and net capacity. GPS Module You can start GPS with a terminal program of your own choice by activating the GPS module via COM4 with 4800 Baud.

  • Page 51: Usb Cradle/Car Cradle Hw 51400

    USB CRADLE/CAR CRADLE HW 51400 GPS Module USB Cradle/Car Cradle HW 51400 The USB or car cradle has a modular design. The base unit is the same for both functions. Depending on the place of action, the following is available: a desktop cradle (incl.

  • Page 52: Technical Data

    USB CRADLE/CAR CRADLE HW 51400 Technical Data Technical Data Casing: Shock resistant plastic, self-extinguishing according to UL94V-0 Slots: One slot for the mobile terminal including battery. • Interfaces: Connection for HW 1430 power supply, DC voltage input Mini DC Power Jack ∅ 1,3 mm, 12 V / 2,5 A •...

  • Page 53: Placing The Skeye.e-Motion Into The Cradle

    USB or car cradle. Then, press the left edge of the terminal into the cradle until it audible engages. Fig. 34: Placing the skeye.e-motion into the cradle Connecting the USB Cradle to the Desktop PC Power supply USB cable...

  • Page 54: Communication Skeye.e-Motion ⇔ Pc

    The input signal of the connection cable for the power connection is "Ignition Sense". This way you can - when the vehicle is at a standstill - activate the automatic switch to the energy-saving mode of the skeye.e-motion or switch on the skeye.e-motion at the begin of the journey.
  • Page 55 Power consumption typical values Cradle only About 13 mA at 12 V About 19 mA at 24 V Holder with skeye.e-motion in suspend, About 19 mA at 12 V battery charged, UMTS module off About 23 mA at 24 V Skeye.e-motion in operation, battery...

  • Page 56: Technische Daten

    TECHNISCHE DATEN Connection of the Cradle in the Vehicle Technische Daten Casing: Rugged case, protection level IP54, drop spec 1,2 m Processor: CPU Marvell PXA 320, 806 MHz Memory: up to 256 MB DDR-RAM, up to 512 MB Flash Display: 5,7 "...

  • Page 57: Troubleshooting

    Start ⇒ ⇒ ⇒ ⇒ Programs ⇒ ⇒ ⇒ ⇒ System ⇒ ⇒ ⇒ ⇒ Reset The system restarts. Unsaved data will be lost. After a software reset, all data and settings stored on your skeye.e-motion are still available. Reset via Hardware Use the Reset key, when the touch screen does no longer react or when you cannot switch on the skeye.e-motion.
  • Page 58 TROUBLESHOOTING Reset via Hardware Manufacturer's Address Höft & Wessel AG Rotenburger Str. 20 D-30659 Hannover Phone +49 511 6102-0 Fax.+49 511 6102-411 Web: www.hoeft-wessel.com Mail: skeye@hoeft-wessel.com Serviceline. Tel. +49 511 6102-600 Fax. +49 511 6102-601 Mail. service-line@hoeft-wessel.de 1.02 • 20.04.2012...
