Summary of Contents for Harmonic NSG 9000-3G

  • Page 1 NSG 9000 Universal EdgeQAM HW and Installation User’s Guide VERSION 1.5 & UP NSG 9000-3G & bNSG 9000 Rev D...
  • Page 2 Harmonic assumes no responsibility or liability arising from the use of the products described herein, except as expressly agreed to in writing by Harmonic. The use and purchase of this product do not convey a license under any patent rights, copyrights, trademark rights, or any intellectual property rights of Harmonic.
  • Page 3: Revision History

    Revision Date Description May 2009 Creating document Tova October 2009 Corrections to table 1-1 Tova November 2009 Correction to table 1-1 2 Tova July 201 1 Support of additional power supply Tova © 201 1 Harmonic Inc. All rights reserved.
  • Page 4: Table Of Contents

    Cabling the GbE Ports........29 © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 5 Hot Swapping Power Supply Unit ......34 © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 6: Main Features And Specifications

    Two independent Ethernet ports, typically used module 100Base-T for management (ETH1) and scrambling Ethernet ports (ETH2). Processing 2xDTI ports Two DTI ports, typically used for M-CMTS module (optional) applications. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 7 Power Supply Current and load When operating with two Power Supplies, load sharing is shared and balanced between the two modules. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 8: Nsg 9000 Physical And Power Specifications

    26.6 (chassis + 1xPS + 9xQRF) 1.3.3 Power Supply Specifications Harmonic sells power supply units that have been thoroughly qualified to operate with the NSG 9000-3G device. Table 1–4 lists power specifications of a fully populated unit toghether with the Harmonic part numbers for the qualified power supply modules. Use these part numbers for ordering your power supply modules.
  • Page 9: Power Consumption From Grid

    Max Power Consumption from Grid(Watts) Input Fully Populated Single QAM-RF Voltage Chassis Module 1 10V AC 220V AC 48V DC For more details, see 2.2.5.2 Overcurrent protection on page 21. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 10: Environmental Specifications

    QAM-RF signal. The following diagram shows the flow of data through the GbE channel. NOTE: The diagram shows the flow of data via a single Quadruple QAM-RF module. NSG 9000 may include up to 9 Quadruple QAM modules. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 11: Nsg 9000 Front Panel

    1.2.1 and NSG9000-3G firmware version 1.6.6 support two types of front panel: NSG-FP-01-02F  NSG-FP-02-01F  The following figure illustrates front panel with part number NSG-FP-01-02F: © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 12: Front Bezel

    The LEDs function the same in both standalone and NMX control modes. The following table describes the front panel LEDs, from left to right and from top down. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 13: Control Panel

    This section describes the back panel of the NSG 9000 platform. The back panel of the NSG 9000 platform includes the following: Processing module  9 x Module Slots  2 x Power supply  © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 14: Processing Module

    NOTE: In case of processing module malfunction, replace the module as instructed in 2.3 Inserting the Modules on page 22 and send the faulty module to Harmonic. 1.6.1.1 Ethernet Ports Ethernet ports - allow connection to separate networks. The Ethernet ports are labeled ETH1 and ETH2.
  • Page 15 Table 1-9: GbE Port Specifications Parameter Specification Connector Three receptacles for SFP connectors RJ-45 connector Maximum input bitrate n Line rate up to 1000 Mbps n Processing up to Maintenance Swappable © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 16 Harmonic, or from other sources. Table 1-1 1 on page 1 7 lists the Harmonic part numbers for the qualified SFP modules, as well as the matching Finisar part numbers for the same modules. Use these part numbers for ordering your SFP modules.
  • Page 17: Module Slots

    Chapter 1 Main Features and Specifications Back Panel NOTE: To be eligible for support by Harmonic, use qualified SFPs only. Table 1-11: SFP Modules Harmonic Part Connector Wave Max. Cable/ Qualified Finisar SFP Fiber/Cable Type Num. Type Length Fiber Length Model Part Num.
  • Page 18: Power Supply

    1.6.4 What’s Next... The next step is to unpack and cable the NSG 9000 platform, as described in the following chapter. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 19: Installation

    For example, the combined air flow of fans mounted at the top of a rack mounted with ten NSG 9000 devices is at least 22.7 M /min (780 CFM). © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 20: Rack Positioning And Device Mounting

    Block the spaces between units as explained in this table “Open space”. Mounting Method Mount each device on supporting rails provided by Harmonic in a separate kit (P/N RM-4-30). Install the rack-mounting rails before mounting the device on the rack. Open space...
  • Page 21: Power Source And Wiring Specifications

    1 5 Amp GMT, 60 VDC/1 25 VAC rating, Fast-acting  1 5 Amp, 250 VAC rating, Slow-blow.  For additional details on AC/DC power source requirements, see “ Wiring the –48 VDC Power Supply on page © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 22: Facility Cooling Requirements

    Required Tools for Installation Four screws to secure the unit to the rack  A screwdriver for fastening the screws  Supporting rails provided by Harmonic in a separate kit  (P/N RM-4-30).  To install the NSG 9000 platform in a rack: NOTE: It is recommended to install the NSG 9000 platform before mounting any cards or modules.
  • Page 23: Tools For Mounting/Replacing A Module

    When replacing the Processing module - Unscrew the screws that attach the module to the chassis in a synchronized manner. 2. When replacing - Hold the module by its knob-holders and pull it out of the slot. Module knob-handle © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 24: Installing A Dti Card (Optional)

    3. Pull out the processing module and handle it according to the ESD guidelines. See, 2.3 Inserting the Modules on page 22. 4. Place the processing module on its side and unscrew the fillers of the DTI connectors. See following picture: © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 25 6. Hold the DTI card by its edges, raise its back up while pushing the DTI receptacles into the DTI connectors of the processing module. Screw holes should be on the spacers © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 26 8. Insert screws and fasten them to secure the DTI card to the processing module. 9. Mount the processing module into its slot and fasten the processing module screws. For DTI cabling instructions, see © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 27: Cabling

    31 3.7.1 Grounding the Mounted Devices on page 31 “3.7.2 Connecting the AC Power Cable on page 31 3.7.3 Connecting the –48 VDC Power Supply on page 31 © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 28: Device Dimensions

    Dimensions are provided in Inches and millimeters as follows: [inch] 17.37 441.3 22.88 581.2 22.66 22.86 575.4 580.5 20.79 1.09 27.8 3.47 88.1 19.00 482.6 3.1.1 Back Panel Measurements © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 29: Cabling The Gbe Ports

    The first figure refers to a connection with optic fibers and the second with copper cables: Alm Act Alm Act Alm Act Gb1 Gb2 Gb3 Switch NSG 9000 Back panel © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 30: Mirroring A Gbe Input Port

     To connect the Ethernet cables: Connect an Ethernet cable with RJ-45 connectors from the ETH1 port on the NSG 9000  to your management network hub or switch. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 31: Cabling The Dti Card

    Once boot up is complete the Power Up screen appears in the control panel display and you may start configuring the device. The Power Up screen shows the company’s name, type of current application (NSG 9000 or bNSG 9000 and a default IP address © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 32: Establishing Ethernet Connection

    The next step is to set preliminary configuration to the NSG 9000/bNSG 9000, as described in the NSG 9000 Software User’s Guide and in the bNSG 9000 Firmware User’s Guide, respectively. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 33: Maintenance

    If it exceeds two minutes, the device may be damaged. 4.1.1.1 Preparation For removing and replacing the fans, you need the following: Phillips screwdriver A new front panel © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 34: Hot Swapping Power Supply Unit

    Locking knob Power Supply unit Handle Warning: You must disconnect the power cord before removing the power supply. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 35 18. NOTE: In case only one power supply unit is mounted, install a filler panel in the slot of the unoccupied power supply unit to allow proper air flow. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 36 The NSG 9000 is connected to the DC power source using three wires: –Vin   +Vin  Although Harmonic provides the power input connector with the NSG 9000, you must supply the wires. The wires to be used must comply with the following specifications: Parameter Specification Suitable conductor material Copper only –Vin and +Vin wires...
  • Page 37 Use only the original connector for connecting the NSG 9000 to the DC power source. Contact Harmonic Technical Support if you want to use any other type of connector. The following figure shows the connector and its strain relief housing: A.3 Assembling the DC Input Power Cable...
  • Page 38 1. Ensure the NSG 9000 is securely installed in a rack and in a Restricted Access Location only. 2. Verify that the NSG chassis is properly grounded, as explained in 3.7.1 Grounding the on page 31. Mounted Devices © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 39 5. Attach the Safety bracket to the chassis by fastening the Safety bracket screw. Your NSG 9000 is now connected to power. 6. Complete any other cabling that may still be needed, and engage the disconnect device to start using the device. © 2011 Harmonic Inc. bNSG 9000 & NSG 9000-3G, Rev D...
  • Page 40 Harmonic Inc. 4300 North First Street San Jose, CA 95134 U.S.A. T +1 408 542 2500 F +1 408 542.2511 www.harmonicinc.com © Copyright 2007 Harmonic Inc. All rights reserved. Manual Part No. 700-000XXXX...
