Integral Solutions EPS-100 Option Manual

Esd/com pulse system esd hardware option
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ESD Hardware Option Manual
Phone: (408) 653-0300
Fax: (408) 653-0309
While every effort has been made to verify the accuracy of the information contained in this publication, this publication may contain
technical and/or typographical errors. Please contact Integral Solutions Int'l to report any errors in this publication.
– EPS-100 –
August 22, 2013
Copyright ©2003-2013 Integral Solutions Int'l
All rights reserved
Integral Solutions Int'l
3000 Olcott St
Santa Clara, CA 95054
Integral Solutions Int'l
Web:
http://www.us-isi.com/
E-mail:
isi@us-isi.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPS-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Integral Solutions EPS-100

  • Page 1 Fax: (408) 653-0309 E-mail: isi@us-isi.com While every effort has been made to verify the accuracy of the information contained in this publication, this publication may contain technical and/or typographical errors. Please contact Integral Solutions Int’l to report any errors in this publication.

  • Page 2: Table Of Contents

    Contents HARDWARE DESCRIPTION INSTALLATION MAINTENANCE CHARGE DEVICE MODEL (CDM) ECHANICAL LIGNMENT ONITORING AVEFORM ESD S TANDARD ALIBRATION CDM O PERATION MACHINE MODEL (MM) ECHANICAL LIGNMENT ONITORING AVEFORM ESD S TANDARD ALIBRATION MM O PERATION HUMAN BODY MODEL (HBM) ONITORING AVEFORM ESD S TANDARD ALIBRATION...

  • Page 3: Hardware Description

    QST test. ESD option consists of EPS-100 and waveform module. EPS-100 is a power supply, capable of producing +/- 100V with 0.003V resolution. It is universal for all waveform modules. Due to calibration for more precise HBM and MM amplitude, the waveform module may require voltages slightly higher than 100, which is not supported by EPS-100.

  • Page 4: Installation

    ESD option is ready. You can fire single pulses from File HardwareConfig EPS100Lib User menu, or run an ESD Sweep test. If you are installing the EPS-100 option on the new PC, you need to install the NIDAQmx 9.7 software. The NIDaqmx Core link is available on www.us-isi.com...

  • Page 5: Maintenance

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 4) The new PCI-6503 card should appear on the list. Click on the PCI-6503 card, then "Properties" - the software will verify the card. 5) After than close Measurement and Automation Explorer and Start Quasi97.

  • Page 6: Charge Device Model (Cdm)

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 4. Charge Device Model (CDM) 4.1 Mechanical Alignment According to CDM standard, the head’s suspension must be grounded. In most cases suspension holder serves that purpose, while in other, the suspension is pressed against CDM chassis by flex clamp.

  • Page 7: Monitoring Waveform

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 4.2 Monitoring Waveform CDM waveform module charges the head to desired voltage and then grounds it, which creates a very fast current transient from the charge accumulated on the head. The pulse is very fast with the rise time up to 500pS and pulse width up to 1nS.

  • Page 8: Esd Standard

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 4.3 ESD Standard The standard shown here applies to pulses produced by ISI DCDM waveform modules and should treated as such. The values should be used for verification of the CDM waveform module device with 5pF and 12pF calibration capacitors.
  • Page 9 EPS-100 Manual Integral Solutions Int’l August 22, 2013 The following plot shows real 20V CDM discharge on 5pF calibration capacitor. Page 9...

  • Page 10: Calibration

    August 22, 2013 4.4 Calibration Use one of the calibration capacitors to verify the CDM waveform. Turn on the EPS-100. If running Quasi97 software then exit from it and run EPS-100 application. Also remove the CDM cartridge from the 2xHGA tooling.
  • Page 11 EPS-100 Manual Integral Solutions Int’l August 22, 2013 BlazerX5 version of the CDM waveform module has pogopins on the other side of the board. For verification of the waveform, the module has to be mounted on the support plate and the calibration disk should be mounted on a shim, as shown on the picture below.

  • Page 12: Cdm Operation

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 4.5 CDM Operation The following block diagram is provided for better understanding of the operation of the waveform module. It is created to show the charge device model ESD standard. The actual waveform module circuit may be slightly different.

  • Page 13: Machine Model (Mm)

    To switch from MM to HBM, simply remove the two screws on the topside of the waveform module and disconnect three cables from it (EPS-100 cable, QST and pogo-pin board connection). The waveform module should come off and you can install another one (HBM or MM) in its place.

  • Page 14: Monitoring Waveform

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 5.2 Monitoring Waveform To monitor current going through the head install a CT-1 probe on the wire going from J4 Pin2 on the cartridge- style waveform module to the FIC board. For the box-style modules mount CT-1 on the wire going from pin2 of “HEAD”...

  • Page 15: Esd Standard

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 5.3 ESD Standard Machine Model charges a 200pF capacitor and fires the accumulated charge into the head. The standard shown here applies to pulses produced by ISI MM waveform modules and should treated as such.

  • Page 16: Calibration

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 5.4 Calibration To verify calibration of the machine module, mount a CT-1 probe to monitor the ESD pulse. Connect a 0Ω resistor instead of the head and fire a 10V pulse. Verify the peak amplitude and ringing frequency against that in the MM spec.

  • Page 17: Mm Operation

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 5.5 MM Operation The following block diagram is provided for better understanding of the operation of the waveform module. It is created to show the machine model ESD standard. The actual waveform module circuit may be slightly different.

  • Page 18: Human Body Model (Hbm)

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 6. Human Body Model (HBM) 6.1 Monitoring Waveform Capturing the waveform of HBM pulse requires the same setup as on Machine Model. To monitor current going through the head install a CT-1 probe on the wire going from J4 Pin2 on the cartridge-style waveform module to the FIC board.

  • Page 19: Esd Standard

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 6.2 ESD Standard Human Body Model charges 100pF capacitor and fires accumulated charge through the 1500Ω resistor into the head. The standard shown here applies to pulses produced by ISI HBM waveform modules and should treated as such.

  • Page 20: Calibration

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 6.3 Calibration To verify calibration of the human body module, mount a CT-1 probe to monitor the ESD pulse. Connect a 0Ω resistor instead of the head and fire a 7V and 50V pulse. Verify the peak amplitude, rise and decay times against the HBM spec.

  • Page 21: Hbm Operation

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 6.4 HBM Operation The following block diagram is provided for better understanding of the operation of the waveform module. It is created to show the human body model ESD standard. The actual waveform module circuit may be slightly different.

  • Page 22: Esd Sweep Test

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 7. ESD Sweep Test ESD option allows you to fire a sequence of pulses and monitor head performance during the sweep. To enable it run Quasi97, go to Add-Ins Modules and enable ESDApp.application. ESDApp is a test that will use your ESD option to fire pulses into the head and will run transfer curve (or any other test) to see how the head had degraded.

  • Page 23: Bar Esd Stress Option

    Install PCI-6503 card in one of the available PCI slots in the comuter Install the shelf for EPS-100 on the right side of the tester (leaving the 50pin ribbon cable between the shelf then the right panel of the Blazer).
  • Page 24 EPS-100 Manual Integral Solutions Int’l August 22, 2013 Mount the EPS-100 on the shelf and connect all cables to it. Remove one from bar magnet assembly and install the waveform module holder. Page 24...

  • Page 25: Monitoring The Waveform On Bar Hbm/Mm

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 8.2 Monitoring the waveform on Bar HBM/MM Unlike the standard HBM/MM cartridges, the BlazerX5 HBM/MM don’t have connectors for the flex guide cables. Instead the have pogo-pins which connect to the probe card PCB. BlazerX5 HBM/MM waveform modules have a special slot in the enclosure specifically for the CT-6 installation.
  • Page 26 To monitor the waveform on a real head, you need to load a bar in Barcont, then select “Stress” location, move to a slider on the bar and click “Probe”. You can open the EPS-100 main menu from the ESD Sweep Test option, and then fire single pulses using EPS-100.

  • Page 27: Changing The Waveform Module

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 8.3 Changing the Waveform Module To change the waveform module, first remove the waveform module assembly from stress probe card base and then unscrew the two screws holding the waveform module to the assembly (as shown on the picture below).

  • Page 28: Software Control Diagram

    (instead of QST2002). You also need to enable ESDApp.Application module in the Quasi97 selected modules menu. When running, the ESD Sweep test will tell barcont to move to stress location, then tell EPS-100 to apply ESD voltage, then tell barcont to move to test location and run tests in Quasi97.

  • Page 29: High Field Esd Stress Option

    EPS-100 Manual Integral Solutions Int’l August 22, 2013 9. High Field ESD Stress Option HBM and MM ESD modules are fully compatible with High Field tester, CDM module requires a rework. For more information and operation specifications please refer to QST-2002-HF User’s Manual.

  • Page 30: Table Of Figures
