Internet through wireless network at a high speed. Note: This manual briefs the profile of the MIK820 data card, and the preparation, installation and uninstallation process. For the operation of the management program, see User Manual.
One Quick Start One ExpressCard/34-to-PCMCIA adapter Getting to Know Your Data Card This is the sketch for KPN MIK820 data card. The actual product may differ. External Antenna You can adjust the external antenna according to the actual signal reception situation so as to reach a most favorable.
When the data card is removed, the indicator is off. Preparation Requirements for the Laptop To use the KPN MIK820 data card, the following configurations for the laptop are required. Equipped with ExpressCard slot. CPU: 133 MHz Pentium or above. 500 MHz Pentium or above is recommended.
Page 5
Follow the direction on the back of the data card. You can insert the data card into the PCMCIA slot by using an ExpressCard/34-to-PCMCIA adapter. MIK820 Quick Start Manual, V1.0 Page 5 of 14...
The OS auto detects and recognizes new hardware and starts the installation wizard. Follow the prompts of the installation wizard. After the program is installed, a shortcut icon for KPN MIK820 data card management program is displayed on the desktop. Starting the Management Program Double-click the shortcut icon on the desktop to start the management program of the data card.
Page 7
Select and stop the hardware related to the data card. When the OS displays "It is safe to remove the device", remove the data card. Note: Before removing the KPN MIK820, exit the Management Program. Uninstalling the Management Program Click Start Menu.
Obey all local laws, regulations, rules, orders, signs and notices while using the wireless device. Signs about the use of mobile phones should also be obeyed as referring to other wireless equipment including wireless devices provided by KPN. MIK820 Quick Start Manual, V1.0 Page 8 of 14...
Page 9
Your wireless device contains small parts with sharp edges that may cause an injury or a choking hazard. Deactivate While Driving Do not use the wireless device while driving. MIK820 Quick Start Manual, V1.0 Page 9 of 14...
Page 10
The wireless device is approved for use in many regions of the world. In these regions, the device meets all radio frequency exposure requirements. The following approvals and notices apply in specific regions as noted. MIK820 Quick Start Manual, V1.0 Page 10 of 14...
Page 11
CE Approval (European Union) The wireless device is approved to be used in the member states of the EU. KPN declares that the wireless device is in compliance with the essential requirements and other relevant provisions of the Radio and Telecommunications Terminal Equipment Directive 1999/5/EC (R&TTE...
Page 12
This is because the wireless device is designed to use the minimum power required to reach the network. All models of KPN's wireless device are designed to meet radio frequency exposure guidelines such as European Council Recommendation and Federal Communications Commission Notice (United States).
Page 13
Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this equipment not expressly approved by KPN may void the FCC authorization to operate this equipment. HSUPA Statement This device does not support high speed uplink packet access (HSUPA) at...
Personal Computer Memory Card International PCMCIA Association Personal Identification Number Specific Absorption Rate Subscriber Identity Module UMTS Universal Mobile Telecommunications System USIM UMTS Subscriber Identity Module WCDMA Wideband Code Division Multiple Access MIK820 Quick Start Manual, V1.0 Page 14 of 14...
