GS-2328KX

Gigabit Managed Switch

Installation and Getting Started Guide

Publication date: Feb, 2012

Revision A1

Table of Contents

Need help?

Do you have a question about the GS-2328KX and is the answer not in the manual?

Questions and answers

Summary of Contents for Data Controls GS-2328KX

Page 1: Installation And Getting Started Guide
GS-2328KX Gigabit Managed Switch Installation and Getting Started Guide Publication date: Feb, 2012 Revision A1...
Page 2 INSTALLATION and GETTING STARTE GUIDE GS-2328KX Series Gigabit Managed Switch Installation and Getting Started Guide © 2012, Datacontrols,Inc. All rights reserved. All brand and product names are trademarks or registered trademarks of their respective companies Publication date: Feb., 2012 Revision A1...
Page 3: About This Guide
ABOUT THIS GUIDE PURPOSE This guide gives specific information on how to operate and use the management functions of the switch. AUDIENCE The guide is intended for use by network administrators who are responsible for operating and maintaining network equipment; consequently, it assumes a basic working knowledge of general switch functions, the Internet Protocol (IP), and Simple Network Management Protocol (SNMP).
Page 4: Compliances And Safety Statements
COMPLIANCES AND SAFETY STATEMENTS FCC-CLASS A This equipment has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
Page 5 EMC: EN55022(2006)+A1:2007/CISPR Class A 22:2006+A1:2006 4K V CD, 8KV, AD IEC61000-4-2 (2001) 3V/m IEC61000-4-3( 2002) 1KV – (power line), 0.5KV – (signal line) IEC61000-4-4(2004) Line to Line: 1KV, Line to Earth: 2KV IEC61000-4-5 (2001) 130dBuV(3V) Level 2 IEC61000-4-6 (2003) 1A/m IEC61000-4-8 (2001) Voltage dips: >95%, 0.5period, 30%, 25periods...
Page 6 The switch is indoor device; if it will be used in outdoor environment or connects with some outdoor device, then it must use a lightning arrester to protect the switch ARNING Self-demolition on Product is strictly prohibited. Damage caused by self-demolition will be charged for repairing fees. Do not place product at outdoor or sandstorm.
Page 7: Table Of Contents
Contents ABOUT THIS GUIDE ............................. ii COMPLIANCES AND SAFETY STATEMENTS ................... iii INTRODUCTION ............................. 1 OVERVIEW ..............................1 DESCRIPTION OF HARDWARE ......................4 NETWORK PLANNING ..........................7 INTRODUCTION TO SWITCHING ....................7 APPLICATION EXAMPLES ........................7 INSTALLING THE SWITCH ........................10 SELECTING A SITE ..........................
Page 8 IN-BAND ACCESS ........................... 28 CABLES ................................29 TWISTED-PAIR CABLE AND PIN ASSIGNMENTS ..............29 STRAIGHT- THROUGH WIRING ..................... 30 1000BASE-T PIN ASSIGNMENTS ....................31 CABLE TESTING FOR EXISTING CATEGORY 5 CABLE ............31 FIBER STANDARDS ..........................32 SPECIFICATIONS ............................33 PHYSICAL CHARACTERISTICS .......................
Page 9: Introduction
Networking includes Small Business or enterprise application and helps you create a more efficient, better-connected workforce. The GS-2328KX Series 28-Ports Switch is broad portfolio of easy-implement managed Ethernet switches. Models include with 28 ports of Gigabit Ethernet connectivity, providing ideal flexibility to design suitable network infrastructure for business requirement.
Page 10: Front Of The Switches
Front of the Switches GS-2328KX Back of the Switches GS-2328KX Publication date: Feb., 2012 Revision A1...
Page 11 SWITCH The switch performs a wire-speed, non-blocking switching fabric. ARCHITECTURE This allows wire-speed transport of multiple packets at low latency on all ports simultaneously. The switch also features full-duplex capability on all ports, which effectively doubles the bandwidth of each connection. This switch uses store-and-forward technology to ensure maximum data integrity.
Page 12: Description Of Hardware
PORTS IEEE 802.3x auto-negotiation of flow control, so the optimum data rate and transmission can be selected automatically. GS-2328KX supports the Small Form Factor Pluggable (SFP) TRANSCEIVER transceiver slots are shared with RJ-45 port 21 to 24. In the SLOTS...
Page 13 The GS-2328KX Series switch includes a display panel for PORT AND system and port indications that simplify installation and SYSTEM STATUS network troubleshooting. The LEDs, which are located on left LEDS hand side of the front panel for easy viewing. Details are shown below and described in the following tables.
Page 14 can switch between Link/ACT mode and SPEED mode by pressing MODE button. When the switch is on Link/ACT mode, the LED of each port indicates the link or act status. The LED of each port shows the link speed status of the port using different colors when the switch is on SPEED mode.
Page 15: Network Planning
Gigabit Ethernet network to significantly increase bandwidth while using conventional cabling and network cards. APPLICATION The GS-2328KX-Port Series Switch implements 24 Gigabit EXAMPLES Ethernet TP ports with auto MDIX and 4 slots for the removable SFP module (GS-2328KX) which supports comprehensive types of fiber connection, such as LC and BiDi-LC modules.
Page 16 Figure 4: Network Connection between Remote Site and Central Site GS-2328KX Figure 5: Peer-to-peer Network Connection GS-2328KX Publication date: Feb., 2012 Revision A1...
Page 17 Figure 6: Office Network Connection GS-2328KX Publication date: Feb., 2012 Revision A1...
Page 18: Installing The Switch
Make sure the twisted-pair Ethernet cable is always routed ◆ away from power lines, radios, transmitters or any other electrical interference. Make sure that GS-2328KX Series Switch is connected to a ◆ separate grounded power outlet that provides 100 to 240 VAC, 50 to 60 Hz.
Page 19: Equipment Checklist
Then, before beginning the installation, be sure you have all other necessary installation equipment. PACKAGE GS-2328KX Port Series GbE Management Switch CONTENTS Four adhesive rubber feet Mounting Accessory (for 19” Rack Shelf, Optional) This Installation Guide User’s Manual CD...
Page 20 Circuit Overloading: Be sure that the supply circuit to the rack assembly is not overloaded. Grounding: Rack-mounted equipment should be properly grounded. TO Rack-mount Devices: Step1. Attach the brackets to the device using the screws provided in the Mounting Accessory. Figure 9: Attaching the Brackets Step2.
Page 21: Installing An Optional Sfp Transceiver
DESKTOP OR SHELF MOUNTING: Step1. Attach the four adhesive rubber feet to the bottom of the first switch. Figure 11: Attaching the Adhesive Rubber Feet Step2. Set the device on a flat surface near an AC power source, making sure there are at least two inches of space on all sides for proper air flow.
Page 22 Figure 12: Inserting an SFP Transceiver into a Slot The SFP slots support the following optional SFP transceivers: Model Name Description SFP.LC 1000Base-SX GE SFP Fiber Module, LC Multi-Mode 850nm SFP.LC.M2 1000Base-SX GE SFP Fiber Module, LC Multi-Mode 1310nm 2km SFP.LC.S10 1000Base-LX GE SFP Fiber Module, LC Single-Mode 10km SFP.LC.S30...
Page 23: Connecting To A Power Source
Step3. Slide the SFP transceiver into the slot until it clicks into place. SFP transceivers are not provided in the switch package. CONNECTING You can plug or remove power cord from AC power socket, to TO A POWER switch the power on and off. SOURCE Figure 13: Inserting the Power Cord to AC Power Socket Step1.
Page 24: Wiring Map For Serial Cable
Figure 14: Serial Port (DB-9 DTE) Pin-Out WIRING MAP FOR SERIAL CABLE The DB-9 cable is used for connecting a terminal or terminal emulator to the Managed Switch’s RS-232 port to access the command-line interface. The table below shows the pin assignments for the DB-9 cable. Table 4: Serial Cable Wiring Function Mnemonic...
Page 25 Figure 15: Plug in the Console The Terminal console port default values of the Port GS-2328KX are listed as below: The serial port’s configuration requirements are as follows: ◆ Default Baud rate—115,200 bps ◆ Character Size—8 Characters ◆ Parity—None ◆...
Page 26: Operation Of Web-Based Management
For the first time to use, please enter the default username and password, and then click the Enter button. The login process now is completed. GS-2328KX web user interface : GEL2-ESW28KX Publication date: Feb., 2012 Revision A1...
Page 27 User Guide. Or you could access to the Switch and click the "help" under the web GUI and the switch will pop-up the simple help content to teach you how to set the parameters. GS-2328KX web help function : Publication date: Feb., 2012 Revision A1...
Page 28 Publication date: Feb., 2012 Revision A1...
Page 29: Making Network Connections
MAKING NETWORK CONNECTIONS The switch is designed to be connected to 10, 100 or CONNECTING 1000Mbps network cards in PCs and servers, as well as NETWORK to other switches and hubs. It may also be connected to DEVICES remote devices using optional SFP transceivers. TWISTED-PAIR Each device requires an unshielded twisted-pair (UTP) cable with RJ-45 connectors at both ends.
Page 30: Network Wiring Connections
Step2. If the device is a network card and the switch is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet. (See the section “Network Wiring Connections.”) Otherwise, attach the other end to an available port on the switch.
Page 31: Fiber Optic Sfp Devices
An optional Gigabit SFP transceiver can be used for a FIBER OPTIC backbone connection between switches, SFP DEVICES connecting to a high-speed server. Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC connector at both ends. Each multimode fiber optic port requires 50/125 or 62.5/125 micron multimode fiber optic cabling with an LC connector at both ends.
Page 32: Connectivity Rules
CONNECTIVITY RULES When adding hubs to your network, please note that because switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices.
Page 33: Mbps Fast Ethernet Collision Domain
100 MBPS FAST ETHERNET COLLISION DOMAIN Table 9: Maximum Fast Ethernet Cable Lengths Cable Type Maximum Cable Length Connector Category 5, 5e or 6 100-ohm 100.m (328 ft) RJ-45 UTP or STP Publication date: Feb., 2012 Revision A1...
Page 34: Cable Labeling And Connection Records
CABLE LABELING AND CONNECTION RECORDS When planning a network installation, it is essential to label the opposing ends of cables and to record where each cable is connected. This will allow user to easily locate inter-connected devices, isolate faults and change your topology without need for unnecessary time consumption.
Page 35: Troubleshooting
Make sure all devices connected to the Series GS-2328KX 28 Switch devices are configured to auto negotiate, or are configured to connect at half duplex (all hubs are configured this way, for example).
Page 36 Check the port A port on your Switch may not be operating as you expect configuration. because it has been put into a “blocking” state by Spanning Tree, GVRP (automatic VLANs), or LACP (automatic trunking). (Note that the normal operation of the Spanning Tree, GVRP, and LACP features may put the port in a blocking state.) Or, the port just may have been configured as disabled through software.
Page 37: Power And Cooling Problems
POWER AND COOLING PROBLEMS If the System indicator does not turn on when the power Installation cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet.
Page 38: Cables
CABLES TWISTED-PAIR For 10/100BASE-TX connections, the twisted-pair cable must have two pairs of wires. For 1000BASE-T connections the CABLE AND PIN twisted-pair cable must have four pairs of wires. Each wire pair is ASSIGNMENTS identified by two different colors. For example, one wire might be green and the other, green with white stripes.
Page 39: Straight- Through Wiring
4, 5, 7, 8 Not used Not used The “+” and “-” signs represent the polarity of the wires that make up each wire pair. STRAIGHT- If the twisted-pair cable is to join two ports and only one of the ports has an internal crossover (MDI-X), the two pairs of wires THROUGH must be straight-through.
Page 40: 1000Base-T Pin Assignments
1000BASE-T PIN All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network ASSIGNMENTS connections to PCs or servers, or to other switches or hubs. The table below shows the 1000BASE-T MDI and MDI-X port pinouts.
Page 41: Fiber Standards
FIBER The International Telecommunication Union (ITU-T) has standardized various fiber types for data networks. These are STANDARDS summarized in the following table. Table 13: Fiber Standards ITU-T Standard Description Application Multimode Fiber Short-reach connections in the 1300- nm G.651 or 850-nm band 50/125-micron core Non-Dispersion-Shifted Fiber Longer spans and extended reach.
Page 42: Specifications
SFP Port: status (LINK/ACT/SPD), 1G/10G WEIGHT 3.9 kg SIZE 44(H) x 442(W) x 300(D)mm TEMPERATURE Operating: 0°C to 40°C (32°F to 104°F) HUMIDITY Operating: 5% to 90% (non-condensing) POWER INPUT For GS-2328KX series: 100~240VAC, 50~60Hz Publication date: Feb., 2012 Revision A1...
Page 43: Switch Features
POWER SUPPLY For GS-2328KX series: Internal: 100 to 240 VAC , 50 to 60 Hz POWER 60 Watts maximum CONSUMPTION SWITCH FEATURES FORWARDING Store-and-forward MODE THROUGHPUT 95.23Mpps FLOW CONTROL Full Duplex: IEEE 802.3x Half Duplex: Back pressure MANAGEMENT FEATURES IN-BAND...
Page 44: Compliances
COMPLIANCES EMISSIONS EN55022 (CISPR 22) Class A EN 61000-3 FCC Class A CE Mark IMMUNITY EN 61000-4-2/3/4/5/6/8/11 EN 55024 Publication date: Feb., 2012 Revision A1...
Page 45: Compliances
COMPLIANCES 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable 100BASE-TX IEEE 802.3u specification for 100 Mbps Ethernet over two pairs of Category 5 UTP cable 1000BASE-LH Specification for long-haul Gigabit Ethernet over two strands of 9/125 micron core fiber cable 1000BASE-LX IEEE 802.3z specification for Gigabit Ethernet over two strands...
Page 46 FULL DUPLEX Transmission method that allows two network devices to transmit and receive concurrently, effectively doubling the bandwidth of that link GIGABIT ETHERNET A 1000 Mbps network communication system based on Ethernet and the CSMA/ CD access method. IEEE Institute of Electrical and Electronic Engineers. IEEE 802.3 Define carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications.
Page 47 SWITCHED PORTS Ports that are on separate collision domains or LAN segments. Telecommunications Industry Association. TRANSMISSION Protocol suite that includes TCP as the primary transport CONTROL protocol, and IP as the network layer protocol. PROTOCOL/INTERNE T PROTOCOL (TCP/IP) USER DATAGRAM UDP provides a datagram mode for the packet-switched PROTOCOL (UDP) communications.
