Summary of Contents for Storage Options baby cam
-
Page 2: Method
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER. NO USER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of non- insulated “dangerous voltage”... -
Page 3: Table Of Contents
3.2 – Monitor POWERING ON 4.1 – Camera 4.2 – Monitor MENU FUNCTIONS 5.1 – Main Menu 5.2 – Baby Cam Setup 5.3 – Monitor Setup 5.4 – System Setup PAIRING THE UNITS 6.1 – Method 1 6.2 – Method 2 ON-SCREEN INDICATORS 7.1 –... -
Page 4: Overview
OVERVIEW babyCam nursery offers a simple, easy to use method of seeing, hearing and talking to your baby from anywhere in the home. It includes a compact and versatile wireless camera to provide clear footage of your baby. From the camera, a clear, full colour video picture and sound are then transmitted wirelessly to the large 7”... -
Page 5: Features
FEATURES 3.1 – CAMERA The camera has various features you should be familiar with for correct operation. The PAIR button is located on the back of the camera: The power socket and on / off switch are on opposite sides of the camera:... -
Page 6: Monitor
3.2 – MONITOR The monitor has various features you should be familiar with for correct operation. Various options can be changed in the menus. Use the front panel buttons to control these functions: The AV output socket can be used to connect the monitor to a television: NOTE You can talk to your child by holding the “TALK”... -
Page 7: Powering On
Press ← and → keys to switch between 4 video channels. 5.1 – MAIN MENU Press the “M” button to display the main menu on screen. You will be presented with the following options: Baby Cam Setup Monitor Setup ... -
Page 8: Baby Cam Setup
To adjust the Baby Cam speaker volume: 1. Press “M” to display the menu. 2. “Baby Cam Vol” will be the first option highlighted. Press “M” to select this option. 3. Press + / – to adjust the volume from 0 (minimum) to 9 (maximum). -
Page 9: System Setup
5.4 – SYSTEM SETUP Here you can adjust various system-wide options. MENU ITEM ADJUSTMENT DESCRIPTION The monitor will remain on all the time, unless disconnected from the mains supply. Power Save After a period of inactivity, the monitor will go into sleep mode. If the camera’s microphone picks up any noise from the baby, the monitor will immediately turn back on. -
Page 10: On-Screen Indicators
ON-SCREEN INDICATORS The monitor unit features on-screen indicators for device status. Refer to the following descriptions for more information. 7.1 – SIGNAL CONDITION INDICATOR DESCRIPTION Good signal Weak signal No signal 7.2 – CHANNEL INDICATOR INDICATOR DESCRIPTION CH: 1 / CH: 2 / CH: 3 / CH: 4 Indicates current video channel number TV OUTPUT MODE The monitor unit can be connected directly to a suitable television through the use of the included AV cable. -
Page 11: Appendix - Product Specification
APPENDIX – PRODUCT SPECIFICATION Nursery Cam Kit GENERAL Transmission Frequency: 2400 – 2480MHz Modulation Mode: FHSS Transmission Power: 17dBm Operating Temperature: C – 60 Operating Frequency: 2450MHz Operating Humidity: 20% – 80% RH Unobstructed Effective Range: 100m MONITOR Screen Type: 7”...
