- Page 1 LV4000U LCD Pole Display...
-
Page 2: Table Of Contents
Contents Warning ..................3 FCC Warning Statement ............3 Introduction ................4 Features ..................4 Unpacking the display ..............4 Installation ................5 Assembly ..................5 Control Buttons .................5 Driver Installation Guide ............6 Trouble Shooting............... 14 Mechanical Dimensions ............16 Specification ................17... -
Page 3: Warning
Warning It will cause malfunction if the monitor is operating with incorrect power voltage. Do not exposure this unit in the rain or moisture environment to reduce the risk of fire or electric shock. FCC Warning Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. -
Page 4: Introduction
Introduction Bematech LV4000U is a true flat LCD customer display with compact and ecological design. The power consumption is only 2.5W with LED backlight. It can be used for delivering multi-media messages and transaction information at the same time. 1. Features 8”... -
Page 5: Installation
Installation Assembly 1. Remove the four screws on base metal plate. 2. Pass the USB cable through the base from bottom. 3. Pass the USB cable through the pole from the bottom. 4. Reinstall the metal plate and attach the pole onto the stand base. 5. -
Page 6: Driver Installation Guide
Driver Installation Guide PC requirements USB Monitor software can be used on PCs, from Netbooks, Notebooks/Laptops to Desktops. The driver will run on processors ranging from Atom N270 based PCs, basic single Core CPUs, and the latest Dual, Quad Core and Core i3/i5/i7 CPUs. The performance of the software is dependent upon the processing power available, as well as the Operating system in use. - Page 7 a. 1.2GHz Single Core CPU b. 512MB memory 2. For 3 monitors where 1 could run DVD video while also targeting productivity and business apps. Will support only 1 video of DVD resolution at full screen: a. 1.6GHz CPU b. 1GB memory 3.
- Page 8 Graphics Card Support (Windows 2000/XP) All graphics cards are supported on Windows 2000/XP. Supported Languages Unsupported languages default to English. The following languages are supported in version 5.2, on all supported operating systems: Arabic Norwegian Bahasa Indonesian Polish Bulgarian Portuguese Chinese (Traditional) Russian Chinese (Simplified)
- Page 9 Installing the USB Monitor Software Make sure to connect the USB cable and begin the installation after your » PC has booted. The Setup program requires about one minute for the installation. If you » turn the power off or remove the USB cable while the Setup program is running, it may cause an error with the PC or the Windows operating system.
- Page 10 5. When the installation is completed, configure the following settings to use multiple monitors. a. Right-click on the “Windows Desktop” and select “Properties” from the displayed menu. The “Display Properties” window appears. b. Select the “Settings” tab. A list of connected USB monitors is displayed. c.
- Page 11 Configuring the 7" USB Monitor Display Information 1. When the driver setup for the USB monitor is finished, a monitor icon is created in the system tray at the bottom of the monitor screen. 2. Click the monitor icon to display a list of connected USB monitors. Select the monitor for which you want to configure the display settings.
- Page 12 3. A list of the installed device will be displayed, as shown in the figure below. The Initial Screen Settings after Installing the Program Applicable mode: Extend mode » Mode position: To the right of the primary screen » Mode rotation: 0° »...
- Page 13 Restrictions on the 8” USB Monitor Supported OS (Operating Systems) Windows XP » Service Pack 1 or earlier: Unsupported Service Pack 2 or later: Supported Windows 2000 » Service Pack 3 or earlier: Not Supported Service Pack 4 or later: Supported Windows Server 2003: Not Supported »...
-
Page 14: Troubleshooting
Troubleshooting 1. There is no image on the screen. I cannot turn on the monitor. Check whether the USB cable is connected correctly. Check whether the USB driver is installed. The USB monitor is recognized as a general USB device on a PC. If you turn the monitor on or off quickly and repeatedly, the USB device problem may occur. - Page 15 5. Q&A How I can clone or extend screen mode? Open the ”Display Properties” window and select the “Settings” tab, How can I remove the “USB Monitor Installation Program” completely? Click “Add/Remove Programs” in the “Control Panel”. A list of “currently installed programs”...
-
Page 16: Mechanical Dimensions
Mechanical dimensions 63,5 34,45 4-M4*0.7*6L... -
Page 17: Specification
Product General Specification Model LV4000U Color Black Display size 8" Display Area 162.0 * 121.5 mm Optimal Resolution 800 * 600 Brightness 250 cd/m² (typ) Contrast Ratio 500:1 (typ) Response Time 25 ms (typ) 140 degrees (H) LCD Viewing Angle... - Page 18 LV4000U LCD Pole Display...
