Summary of Contents for Skyview CMS
- Page 1 MC-636 A-2...
-
Page 2: Table Of Contents
Contents 1.0 CMS FUNCTIONS ..................3 2.0 INSTALL CMS....................3 3.0 START CMS....................5 3.1. Top Toolbar....................7 3.2 Top Menu Bar....................7 3.3 Toolbar on Right Side...................7 3.4 Video Area ....................8 3.5 Bottom Toolbar.....................9 4.0 MENU AND MOUSE OPERATION..............9 4.1 File ......................10 4.2 Tools......................10 4.3 Help...................... -
Page 3: Cms Functions
Remote Video Recording: video file can be stored in build-in hard disk of DVRs by setting recording time.. Local video recording: Videos can be record in CMS at any time you start up local recording. Real-time video image capture: it is auxiliary function for real-time monitoring. It will save the single frame from dynamic images in BMP format, and it can capture images during monitoring or playback. - Page 4 Network Card; 100/1000M Graphics Card: It should support hard ware zoom (such as: ATI, TNT2 PRO). We recommend you use graphic card above ATI9800 and video memory above 128M ★ Installation Guide: ★ Open folders of management software and run (double click left button of the mouse) “ViewCms.exe”, and then the following dialogue box will appear as first Fig shows and click “Next”...
-
Page 5: Start Cms
Next, select the destination folder to save the install file and follow the prompt of installation tool until the appearance of the step displayed as following. Click [Finish] to complete the installation. 3.0 Start CMS Choose the software in [Start] menu----program groups-----ViewCMS-----ViewCMS----- ViewCMS, which is showed as following:... - Page 6 Run CMS by clicking the left button of the mouse, and interface as following will appear: When you open this screen, it will show this dialog box,choose “yes” or “no”depends on your need..
-
Page 7: Top Toolbar
3.1. Top Toolbar You can manually choose different icons as following picture: 【DEV MANAGE】: After clicking this icon, you can add project, area and device. When you add device, you should set device name, fill in IP address, port, username and password. -
Page 8: Video Area
The second tab is Pan/tilt control button. You can control high speed dome. 3.4 Video Area Choose the real-time video of one channel in video display area, and click right button on selected video screen. System pops up a menu as follows:... -
Page 9: Bottom Toolbar
The path of save can be modified in ‘Tools’ menu—‘local setup’. 【Mute On/Off】: Turn on or turn off sound. 【Version】: Version information. 4.0 Menu and Mouse Operation CMS is composed of three parts: File, Tools and Help. -
Page 10: File
4.1 File By “File” menu of CMS operations like “Exit system” can be carried out. Picture showed as following: Exit System: exit CMS program. 4.2 Tools “Tools” menu is mainly used to manage device, playback files, setup local setting and remote setting. - Page 11 Between device name and IP or domain there is a navigation bar,you can switch between IP/Auto ID mode by moving it.You need manually input all the settings under IP MODE except DEVICE-ID,while PORT configurations are set to default under Auto mode.
- Page 12 The highlighted date indicates that video was recorded on that day. Click on a date to search the recording file list of that day. For example, the above fig shows that June, 12th, 13th have recorded video when it shows on bold, and current search date is June 12th. Select channel and type at the bottom of the calendar.
- Page 13 button “ ” to setup save path. It is equal with the function of ‘LOCAL SETUP’ button on top Toolbar. Remote setup: It is used to setup remote settings, includes record, alarm, PTZ, network, advanced and system information six menus. It is equal with the function of ‘REMOTE SETUP’...
- Page 14 A. Encode Setting Click [Encode] tab to enter into setup interface. User can adjust recording parameters (resolution, quality and frame rate) for each channel remotely via CMS. B. Record Setting Click [Record] tab to enter into the menu interface, user can select “on/off” for each...
- Page 15 CMS. C. Device Alarm Setting Click [DEV Alarm Setting] tab to enter into setup interface. You can set disk not work alarm, low HD spare alarm and video lost alarm.
- Page 16 D. Channel Alarm Setting Click [Channel Alarm Setting] tab to enter into setup interface. User can set up alarm event types; also can set I/O alarm for each channel, motion detection alarm, motion area, motion sensitivity, alarm out time, buzzer time, pre REC time and post REC time. E.
- Page 17 Click [Network Setting] tab to enter setup interface. The menu allows user to set a lower bandwidth for Internet video transmission. User can setup network parameters using the same methods as in the local DVR setup. G. Mobile Setting Click [Mobile Setting] tab to enter setup interface. User can setup mobile parameters using the same methods as in the local DVR setup.
- Page 18 the same methods as in the local DVR setup. I. User Setting Click [User Setting] tab to enter setup interface. User can enable password, change password, set DVR permission and remote permission using the same methods as in the local DVR setup.
- Page 19 J. System Setting Click [System Setting] tab to enter setup interface. The menu allows user to set daylight saving time. K. HDD Click [HDD] to enter below interface. Here user can check HDD state, total size of HDD and free size of HDD. L.
-
Page 20: Help
4.3 Help Version and copyright information of CMS displayed by ‘help’ menu 4.4 Mouse Operation Click left button of mouse on one video frame to choose the video. Double click left button of mouse on one video frame, then the video will be displayed in full screen mode;... -
Page 21: Real-Time Video Display And Control
5.0 Real-Time Video Display and Control Real-time video controlling function of CMS can realize the control of displaying images, PTZ and carry out some practical processing on video images. 5.1 Real-Time Video Frame Control Real-time Video Frame Control contains multi-frame switching, full screen display, local record, image capture and mute on/off. -
Page 22: Display Control
Version: Click this icon to show version. 5.2 Pan/Tilt/Zoom Controlling The CMS can control the pan/tilt and lens of the device at front-end only when users group of this CMS is authorized with “PTZ Controlling”. Authority limits of this client-side will be set in local DVR user management. -
Page 23: Device Information
CMS and indicates this channel connect to CMS normally. If you want to connect a channel to CMS, you can left-click it with your mouse and drag it to video display area.
