MyTek SS-900 Owner's Manual

Remote starter & alarm system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REMOTE STARTER & ALARM SYSTEM
MODEL SS-900
OWNER'S
MANUAL
Mytek America
8334 Foothill Blvd.
Sunland, CA 91040
Tel: (818)352-4994
Fax: (818)352-9794

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS-900 and is the answer not in the manual?

Questions and answers

Summary of Contents for MyTek SS-900

  • Page 1 REMOTE STARTER & ALARM SYSTEM MODEL SS-900 OWNER’S MANUAL Mytek America 8334 Foothill Blvd. Sunland, CA 91040 Tel: (818)352-4994 Fax: (818)352-9794...

  • Page 2: Table Of Contents

    SS-900 Rev. A OWNER’S MANUAL TABLE OF CONTENTS SECTION 1: GENERAL DESCRIPTION........................3 SECTION 2: SYSTEM MODE & OPERATION ......................3 SECTION 3: SYSTEM OPERATION......................... 4 3.1 R )..........................4 EMOTE YSTEM 3.2 R )......................... 4 EMOTE YSTEM ISARM 3.3 E ) ..

  • Page 3: Section 1: General Description

    OWNER’S MANUAL SECTION 1: GENERAL DESCRIPTION Congratulations on your purchase of the SS-900, one of the best security starter systems using the most advanced CMOS IC, EEPROM and SMT technology. SS-900 is the latest version of security starter system designed to provide all essential preventative security measures with ease of operation.

  • Page 4: Section 3: System Operation

    SECTION 3: SYSTEM OPERATION The SS-900 is very sophisticated, but the operation is simple. Your three button RF the transmitter is easy to use for arm, disarm, personal protection, keyless locking and unlocking, trunk release, remote engine start and stop.

  • Page 5: Emergency Disarm With Secrete Key (I F You Lost A Remote And Can Not Shut Off The Alarm System )

    SS-900 Rev. A OWNER’S MANUAL Note: If you hear three chirp sounds, the system has been triggered and the alarm was activated while you were away from the vehicle. Please refer to following chart. This diagnostic report will turn off when ignition switch is turned on.

  • Page 6: Engine Run Verification (If Remote Start Is Installed.)

    SS-900 Rev. A OWNER’S MANUAL Doors will unlock and the system will disarm. Two chirps and two light flashes will verify the operation. Press and release the transmitter button #1 again with antenna extended. Engine stops running and the system will arm. One chirp and one light flash will verify the operation.

  • Page 7: Trunk Release (Option)

    SS-900 Rev. A OWNER’S MANUAL Engine will shut off in 2.5 minutes for Turbo Cool Down Mode and in between 2.5 minutes – 30 minutes for Stop and Go Mode. In Stop and Go Mode, you can use optional entry method listed on section 3.1 to drive without shutting the engine off.

  • Page 8: Permanent Reprogrammable Factory Code (Code Pre-Programmed By Factory)

    SS-900 Rev. A OWNER’S MANUAL Programming Function Programming Method Chirp Light Code Program (4.1) Turn Ignition On. Within 10 seconds, press program switch button 4 times then press and hold down program switch button (1 chirp, 1 light). Press the button #1 of the new transmitter (1 chirp, 1 light).

  • Page 9: 4.3 One Time Soft Chirp

    SS-900 Rev. A OWNER’S MANUAL For PERMANENT SIREN CHIRP ENABLE: With your vehicle key in the key cylinder, turn it to ignition on position (Driving Position). Within five (5) seconds, PRESS AND HOLD THE TRANSMITTER BUTTON #2 for a five (5) seconds.

  • Page 10: Time Start Mode (If Remote Start Is Installed)

    SS-900 Rev. A OWNER’S MANUAL Press PRS Turn Ignition 1 Chirp (on) 1 Light Flash (on) Press #1 2 Times for 5 Sec. 2 Chirps (off) 2 Light Flashes (off) 4.6 Time Start Mode (If remote start is installed) Time start mode means that the system automatically starts your car vehicle once every day at the programmed time.

  • Page 11: Section 5: Dealer Programmable Features

    SS-900 Rev. A OWNER’S MANUAL SECTION 5: DEALER PROGRAMMABLE FEATURES 5.1 Passive/Active/Passive with Passive Lock Mode(Factory Default Setting: Active Mode) Passive mode means that the system automatically interrupts the starter and arm the system thirty seconds after the ignition key is turned off and the last door of the vehicle is closed. Passive mode is sometimes referred to as Automatic System Activation.

  • Page 12: Section 6: The Transmitter Battery Replacement Insturctions

    SS-900 Rev. A OWNER’S MANUAL SECTION 6: THE TRANSMITTER BATTERY REPLACEMENT INSTURCTIONS Recommended Battery: +12V GP23A Remove the screw from the back of the transmitter. Remove front cover, remove old battery carefully. Replace with fresh new battery and close front cover.
