Force CMG Router Quick Start Manual

Cmg router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CMG Router
Q
S
G
UICK
TART
UIDE
Part Number: 002-0142-0210
Product Release: 2.97
August 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMG Router and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Force CMG Router

  • Page 1 CMG Router UICK TART UIDE Part Number: 002-0142-0210 Product Release: 2.97 August 2009...
  • Page 2 Technical Assistance Center: Force10 Networks, Inc. E-mail: access-support@Force10Networks.com 350 Holger Way Phone: (US) 866-887-4638 San Jose, CA 95134-1362 Phone (International/Direct): 1-707-665-4355 Phone: +1 (866) 571-2600 or +1 (408) 571-3500 www.Force10Networks.com Supporting Software Versions: CMG Router Release 2.97 Adit 600 Controller Release 10.1.1...

  • Page 3: In This Guide

    UICK TART UIDE In this Guide Installation Basic Setup Basic VoIP Setup Fax and Modem Setup PPP Internet Connection and Public IP Address Routing Frame Relay Internet Connection and Public IP Address Routing Internet Connection using PPP, NAT/PAT and Firewall Filters Internet Connection using NAT and Static NAT Addresses Back-to-Back with PPP...

  • Page 4: Installation

    Unit can be on or off CMG Router card will work in any slot Slide card into slot until fully seated CMG Router has completed its boot cycle when CRD light is solid NOTE: Configuration can be done with CLI commands from the Adit 600 controller or with the Router Menu-Driven Software.

  • Page 5: Basic Voip Setup

    This example is with an Adit 600 with the following cards installed: Controller Card (4.0 or higher) CMG Router Card, 1.0 or higher (example - slot 6) 3 FXS Cards, 1.03 or higher (example - slots 1, 2 and 3). Cards are configured for Loop Start POTS lines.
  • Page 6 Connect CMG voice ports to FXS ports connect 6:1:1:1-8 1:1-8 Connect CMG voice ports to FXS ports connect 6:1:1:9-16 2:1-8 Connect CMG voice ports to FXS ports connect 6:1:1:17-24 3:1-8 Disable verification prompts set verification off CMG Router - Release 2.97...
  • Page 7 Set the address value to be used for the origin set 6 voip sdpaddress 11.168.1.1 and connection lines in the SDP. (May be required depending on how the LAN and WAN are configured.) Reset the CMG card to apply all configurations reset 6 CMG Router - Release 2.97...

  • Page 8: Fax And Modem Setup

    Fax and Modem Setup To configure the fax and modem bypass, the following is required. Adit 600, release 8.0 CMG Router, release 2.3 with G.729 feature enabled (software keyed) The following will configure the Fax and Modem 1. Telnet into the Router >...
  • Page 9 Quick Start Guide Fax and Modem Setup 2. Select Configuration: <Profile Directory> from the Main Menu, and select NTER Main Menu 3. Select Router CARD <Setup -> and select [E NTER Profile Directory Window CMG Router - Release 2.97...
  • Page 10 Quick Start Guide Fax and Modem Setup 4. Select VOIP Configure -> and select [E NTER CMG Router - Release 2.97...
  • Page 11 Quick Start Guide Fax and Modem Setup 5. Tab to Voice Algorithm Settings - > and select [E NTER CMG Router - Release 2.97...
  • Page 12 6. Verify that the RTP Payload type for nse events is set to a value that other gateways are using. For most applications this is 100, which is the default setting. Select [E ] to exit this window, select <YES> and [E ] to save NTER any changes. CMG Router - Release 2.97...
  • Page 13 Quick Start Guide Fax and Modem Setup 7. Select Voice Channels Configure -> and select [Enter]. CMG Router - Release 2.97...
  • Page 14 <none> - a modem call would be treated as a normal voice call. Default. <bypass> - upon detection of a modem tone, the line will switch to G.711 mode, with echo cancellation and silence suppression disabled. CMG Router - Release 2.97...
  • Page 15 In the status field, the following can be displayed, regarding Fax and Modem settings: Display Setting Channel is set to T.38 Data Channel is set to Modem Bypass Active Channel is set for a Voice call CMG Router - Release 2.97...

  • Page 16: Ppp Internet Connection And Public Ip Address Routing

    1 "wan1" static ip network interface 0.0.0.0 0.0.0.0 Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...

  • Page 17: Frame Relay Internet Connection And Public Ip Address Routing

    Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Set the DLCI number set 1 "wan1" dlci 101 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...

  • Page 18: Internet Connection Using Ppp, Nat/Pat And Firewall Filters

    IP address at the far end incoming log telnet that will be able to ping or telnet to the router. 0.0.0.0/0 192.168.21.14/32 will allow any other host at the far end to ping and/or xxx.xxx.xxx.xxx/32 telnet to the router. CMG Router - Release 2.97...
  • Page 19 Set WAN interface "wan1" to be mapped to trunk 1 set 1 "wan1" trunk 1 Set the encapsulation on trunk 1 to PPP set 1:1:1 encapsulation ppp Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...
  • Page 20 Set the WAN interface named "wan1" NAT set 1 "wan1" nat address address 216.174.44.2 1 Adds a static IP network (route) to the WAN add 1 "wan1" static ip network interface 0.0.0.0 0.0.0.0 1 CMG Router - Release 2.97...
  • Page 21 *In the private network that can be reached from the outside world. There can be up to 16 static NAT addresses, therefore the actual range can be 216.174.44.232 to 216.174.44.247. Only 4 were used in this example. CMG Router - Release 2.97...

  • Page 22: Back-To-Back With Ppp

    1 "wan1" static ip network interface 2.2.2.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...

  • Page 23: Denver Router In Slot 1

    1 "wan1" static ip network interface 1.1.1.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...

  • Page 24: Back-To-Back With Multi-Link Ppp

    2.2.2.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk multilink mapped to trunk multilink group 1 group 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...
  • Page 25 1.1.1.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk multilink mapped to trunk multilink group 1 group 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...

  • Page 26: Back-To-Back With Frame Relay

    Set the WAN interface named "wan1" to be mapped to set 1 "wan1" trunk 1 trunk 1 Set the DLCI number set 1 "wan1" dlci 101 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.97...

  • Page 27: Denver Router In Slot 3

    Set the WAN interface named "wan1" to be set 3 "wan1" trunk 1 mapped to trunk 1 Set the DLCI number set 3 "wan1" dlci 101 Reboot the router, to enable all configurations set reset 3 CMG Router - Release 2.97...
  • Page 28 Quick Start Guide Back-to-Back with Frame Relay CMG Router - Release 2.97...
