Page 4: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Mazda product. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Mazda and its products visit the following website: •...
Page 5 Introduction Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment.
Page 6 Introduction Do not add friction modifier compounds or special break-in oils since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage. SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper to Bumper Coverage, Safety Restraint Coverage and Corrosion Coverage.
Page 7 Introduction Using your vehicle as an ambulance WARNING: Do not use this vehicle as an ambulance. Your vehicle is not equipped with an ambulance preparation package. DATA RECORDING Service Data Recording Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle.
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Manual Protecting the Fasten Seat Belt Environment Airbag - Front Airbag - Side Child Seat Lower Passenger Airbag Off Anchor Child Seat Tether Brake System Anchor...
Page 9 Introduction Vehicle Symbol Glossary Personal Alarm System Power Window Lockout Feature Engine Oil Engine Coolant Engine Coolant Do Not Open When Hot Temperature Avoid Smoking, Flames, Battery or Sparks Battery Acid Explosive Gas Fan Warning Power Steering Fluid Maintain Correct Fluid Service Engine Soon Level Engine Air Filter...
Page 10 Instrument Cluster Instrument cluster (pg. 12) Multi-function lever (pg. 51) Hazard flasher control (pg. 220) Headlamp control (pg. 40) Speed controls* Steering wheel controls* (pg. 59) (pg. 62) Hood release Parking brake release (pg. 275) (pg. 195) * if equipped...
Page 11 Instrument Cluster Climate controls Audio system (pg. 36) (pg. 19) Auxiliary input jack (pg. 27) Electronic stability Auxiliary power point control (pg. 55) (pg. 196) * if equipped...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
Page 13 Instrument Cluster WARNING: Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Check fuel cap fill inlet: Illuminates when the fuel cap fill inlet may not be properly closed.
Page 14 Instrument Cluster WARNING: If the light remains on, continues to flash or fails to illuminate, have the system serviced immediately by an authorized Mazda dealer. With the ABS light on, the anti-lock brake system is disabled but normal braking is still effective unless the brake warning light also remains illuminated with the parking brake released.
Page 15 Instrument Cluster Low tire pressure warning: Illuminates when your tire pressure is low. If the light remains on at start up or while driving, the tire pressure should be checked. Refer to Inflating your tires in the Tires, Wheels and Loading chapter. When the ignition is first turned to on, the light will illuminate for three seconds to ensure the bulb is working.
Page 16: Gauges
Instrument Cluster Door ajar: Illuminates when the ignition is in the on position and any door is open. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on.
Page 17 Instrument Cluster Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 18 Instrument Cluster Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the on position).
Page 19: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS AM/FM/single CD or in-dash CD6/MP3 satellite compatible sound system WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Mazda strongly recommends that drivers use extreme caution when using any device that may take their focus off the road.
Page 20 Entertainment Systems AM/FM Radio / VOL (Power/Volume): Press to turn the radio on/off. Turn the knob to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a nominal listening level when the ignition is turned back on.
Page 21 Entertainment Systems To activate the autoset feature: Press MENU repeatedly until AUTO PRESET ON/OFF appears in the display. Use SEEK/TRACK turn AUTO PRESET ON, and either wait five seconds for the search to initiate or press OK to immediately initiate the search. If you press another control within those five seconds, the search will not initiate;...
Page 22 Entertainment Systems To auto load up to six discs– Press and hold LOAD until the display reads AUTOLOAD #. Load the desired disc, label side up. The system will prompt you to load discs for the remaining available slots. Insert the discs, one at a time, label side up, when prompted.
Page 23 Entertainment Systems In MP3 folder mode– Press DIRECT and the memory preset buttons (0–9) of the desired folder. The system will advance to that specific folder. TEXT: In MP3 mode only– Press TEXT repeatedly to view Album (AL), Folder (FL), Song (SO) and Artist (AR) in the display, if available. In TEXT MODE–...
Page 24 Entertainment Systems SEEK/TRACK: Press SEEK/TRACK to seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK/TRACK to seek to the previous/next channel in the selected category. Press and hold SEEK/TRACK to fast seek through the previous/next channels. SCAN: Press SCAN for a brief sampling of all available SIRIUS satellite channels.
Page 25 Entertainment Systems SATELLITE RADIO MENU: Press MENU when satellite radio mode is active to access. Press OK to enter into the satellite radio menu. Press to cycle through the following options: • CATEGORY MENU- Press OK to enter category mode. Press to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.) Press OK when the desired category appears in the display.
Page 26 Entertainment Systems d. DISABLE ALERTS/ENABLE ALERTS: Press OK to enable/disable the satellite alert status which alerts you when your selected songs are playing on a satellite radio channel. (The system default is disabled.) SONG ALERTS ENABLED/DISABLED will appear in the display. The menu listing will display the opposite state. For example, if you have chosen to enable the song alerts, the menu listing will read DISABLE as the alerts are currently on, so your other option is to turn them off.
Page 27: Auxiliary Input Jack (Line In)
Entertainment Systems FADE: Press SEEK/TRACK to adjust the audio between the back (B) and front (F) speakers. SPEED COMPENSATED VOLUME (if equipped): With this feature on, radio volume automatically gets louder with increasing vehicle speed to compensate for road and wind noise. The default setting is off.
Page 28 Entertainment Systems Your vehicle is equipped with an Auxiliary Input Jack (AIJ). The Auxiliary Input Jack provides a way to connect your portable music player to the in-vehicle audio system. This allows the audio from a portable music player to be played through the vehicle speakers with high fidelity.
Page 29 Entertainment Systems 7. Adjust the sound on your portable music player until it reaches the level of the FM station or CD by switching back and forth between the AUX and FM or CD controls. Troubleshooting: 1. Do not connect the audio input jack to a line level output. Line level outputs are intended for connection to a home stereo and are not compatible with the AIJ.
Page 30 Entertainment Systems • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception. • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.
Page 31 Entertainment Systems CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels.
Page 32: Satellite Radio Information
Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
Page 33 Entertainment Systems • Terrain: Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and thunderstorms can interfere with your reception. • Station overload: When you pass a ground based broadcast repeating tower, a stronger signal may overtake a weaker one and result in an audio mute.
Page 34 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. than two seconds to This message should produce audio for the disappear shortly. selected channel. SAT FAULT Internal module or If this message does system failure not clear within a short present.
Page 35 Entertainment Systems Radio Display Condition Action Required NO TEXT Song title information Song title information not available. not available at this time on this channel. The system is working properly. NO TEXT Category information Category information not available. not available at this time on this channel.
Page 36: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM Fan speed adjustment: Turn to select fan speed. Rear defroster: Press to activate/deactivate the rear window defroster. Refer to Rear window defroster later in this chapter for more information. Defrost: Distributes outside air through the windshield defroster vents and demister vents.
Page 37 Climate Controls Passenger heated seat control (if equipped): Press to activate/deactivate the passenger heated seat. See Heated seats in the Seating and Safety Restraints chapter. Recirculated air: Press to activate/deactivate air recirculation in the vehicle. Recirculated air may reduce the amount of time needed to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle.
Page 38 Climate Controls Operating tips • To reduce fog build up on the windshield during humid weather, select (defrost) or (floor/defrost). • To reduce humidity build up inside the vehicle, do not drive with the system off or with (recirculated air) engaged and A/C off. •...
Page 39: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice. The engine must be running to operate the rear window defroster. Press to turn the rear window defroster on.
Page 40: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position turn on the headlamps. Rotate back to to turn the headlamps off. Autolamp control The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 41 Lights Autolamp delay system With autolamps, you can set the delay time to keep the headlights on for up to three minutes after the key is turned off. The delay time is set to 20 seconds at the factory, but the delay time may be changed by following the steps below (Steps 1 through 6 must be done within 10 seconds).
Page 42 Lights Flash to pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the lowbeam headlamps on with a reduced output. To activate: • the ignition must be in the on position. •...
Page 43 Lights Note: If the battery is disconnected, discharged, or a new battery is installed, the dimmer switch requires re-calibration. Rotate the dimmer switch from the full dim position to the full dome/on position to reset. This will ensure that your displays are visible under all lighting conditions. AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant.
Page 44: Turn Signal Control
Lights 5. Locate the vertical adjuster on the headlamp, then use a 4 mm socket to turn the adjuster either counterclockwise (to adjust up) or clockwise (to adjust down) aligning the upper edge of the light pattern to the horizontal line. 6.
Page 45 Lights The map lamp controls (without moon roof) are located on the dome lamp. Press the button on either side of each map lamp to illuminate the lamps. Press the button again to turn off the lamps. For models equipped with a moon roof, the map lamps are located on the moon roof control panel.
Page 46: Bulb Replacement
Lights BULB REPLACEMENT Lamp assembly condensation Exterior lamps are vented to accommodate normal changes in pressure. Condensation can be a natural by-product of this design. When moist air enters the lamp assembly through the vents, there is a possibility that condensation can occur when the temperature is cold.
Page 47 Lights Function Number of bulbs Trade number Center High-mount stop lamp W5WL Rear license plate lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your authorized dealer Replacing interior bulbs Check the operation of the interior bulbs frequently.
Page 48 Lights 5. Disconnect the electrical connector from the bulb. WARNING: Children and Halogen Bulbs: Playing with a halogen bulb is dangerous. Serious injuries could be caused by dropping a halogen bulb or breaking in some other way. Always keep halogen bulbs out of the reach of children.
Page 49 Lights Replacing license plate lamp bulbs 1. Make sure the headlamp switch is in the off position. 2. Press the tab and carefully pry the license plate lamp assembly (located above the license plate) from the liftgate. 3. Rotate the bulb socket counterclockwise and remove from lamp assembly.
Page 50 Lights 3. Pull the bulb straight out of the socket and push in the new bulb. To complete installation, follow the removal procedure in reverse order. Replacing fog lamp bulbs (if equipped) 1. Make sure the fog lamp switch is in the off position. 2.
Page 51: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Note: Heavy ice and snow can jam the wiper blades and overheat the wiper motor.
Page 52: Steering Wheel Adjustment
Driver Controls Rear window wiper/washer controls For rear wiper operation, rotate the rear window wiper and washer control to the desired position. Select: 2 — Normal speed operation of rear wiper. 1 — Intermittent operation of rear wiper. O (off) — Rear wiper and washer off. For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position.
Page 53 Driver Controls WARNING: Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very easily cause the driver to abruptly turn to the left or right. This can lead to loss of control or an accident. Never adjust the steering wheel while the vehicle is moving.
Page 54 Driver Controls OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Storage compartment (if equipped) Press the release on the door to open the storage compartment. The storage compartment may be used to secure sunglasses or a similar object.
Page 55 Driver Controls The tray and inside bin can be removed to open up space to fit a laptop computer, MP3 players, CDs or handbags. To remove, open the console lid and pull the bin straight up and out from the console housing.
Page 56: Power Windows
Driver Controls To have full capacity usage of your power point, the engine is required to be running to avoid unintentional discharge of the battery. To prevent the battery from being discharged: • do not use the power point longer than necessary when the engine is not running, •...
Page 57 Driver Controls One-touch down (AUTO) Allows the driver’s window to open fully without holding the control down. Press the switch completely down to the second detent and release quickly. The window will open fully. Momentarily press the switch to any position to stop the window operation.
Page 58: Mirrors
Driver Controls Automatic dimming interior rear view mirror (if equipped) Your vehicle may be equipped with an interior rear view mirror that has an auto-dimming function. The electronic day/night mirror will change from the normal (high reflective) state to the non-glare (darkened) state when bright lights (glare) reach the interior mirror.
Page 59: Cruise Control
Driver Controls Fold-away mirrors Fold the side mirrors in carefully when driving through a narrow space, like an automatic car wash. Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.
Page 60 Driver Controls Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release it. 2. Accelerate to the desired speed. 3. Press the SET + control and release it.
Page 61 Driver Controls Resuming a set speed Press the RES control and release it. This will automatically return the vehicle to the previously set speed. Increasing speed while using speed control There are three ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control.
Page 62 Driver Controls Turning off speed control There are two ways to turn off the speed control: • Press the OFF control. • Turn off the ignition. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some audio control features.
Page 63: Moon Roof
Driver Controls In any mode: • Press VOL + or VOL - to adjust the volume. MOON ROOF (IF EQUIPPED) You can move the glass panel of the moon roof back to open or tilt up (from the closed position) to ventilate the vehicle. WARNING: Do not let children play with the moon roof or leave children unattended in the vehicle.
Page 64 Driver Controls Bounce-back: When an obstacle has been detected in the moon roof opening as the moon roof is closing, the moon roof will automatically open and stop at a prescribed position. This is known as “bounce-back”. If the ignition is turned off (without accessory delay being active) during bounce-back, the moon roof will move until the bounce-back position is reached.
Page 65 Driver Controls UNIVERSAL GARAGE DOOR OPENER (IF EQUIPPED) Your vehicle may be equipped with a universal garage door opener which can be used to replace the common hand-held transmitter. Car2U Home Automation System (if equipped) The Car2U Home Automation System is a universal transmitter located in the driver’s visor that includes two primary features –...
Page 66 Driver Controls Types of garage door openers (rolling code and fixed code) The Car2U Home Automation System may be programmed to operate rolling code and fixed code garage door openers. • Rolling code garage door openers were produced after 1996 and are code protected.
Page 67 Driver Controls 1. Firmly press the two outer Car2U system buttons for 1–2 seconds, then release. 2. Go to the garage to locate the garage door opener motor and its “learn” button. You may need a ladder to reach the unit and you may need to remove the unit’s cover or light lens to locate the “learn”...
Page 68 Driver Controls The indicator light above the selected button will turn on to confirm that the Car2U system is responding to the button command. To program another rolling code device such as an additional garage door opener, a security device or home lighting, repeat Steps 1 through 4 substituting a different function button in Step 3 than what you used for the garage door opener.
Page 69 Driver Controls Switch position Up, on or + Middle, neutral or 0 Down, off or – L=left; M=middle; R=right 3. To input these positions into the Car2U system, simultaneously press all three Car2U system buttons for a few seconds and then release to put the device into programming mode.
Page 70 Driver Controls Erasing the Car2U Home Automation System buttons Note: The system allows for three devices to be programmed. If you need to change or replace any of the three devices after it has been initially programmed, it will be necessary to erase the current settings using the procedure below and then reprogramming all of the devices being used.
Page 71 Driver Controls LIFTGATE • To open the liftgate window, unlock the liftgate (with the power door locks or the remote entry) and press the right side control button located under the license plate lamp shield. • To open the liftgate, unlock the liftgate (with the power door locks or the remote entry) and press the middle control button...
Page 72 Driver Controls To install the shade: • Insert the ends of the cargo shade into the mounting features located behind the rear seat on the rear trim panels. To operate the shade: 1. Grasp the handle at the rear edge of the shade and pull rearward.
Page 73 Driver Controls ROOF RACK SYSTEM (IF EQUIPPED) Loads should never be placed directly on the roof panel. For proper function of the roof rack system, loads must be placed directly on crossbars affixed to the roof rack side rails. Your vehicle may be equipped with factory-installed crossbars.
Page 74 Driver Controls To remove the cross-bar assembly (if equipped) from the roof rack side rails: 1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable). 2. Slide the cross-bar to the end of the rail. 3. Use a long, flat object to depress the tongue in the endcaps on both sides of the cross-bar.
Page 75 Driver Controls To reinstall the cross-bar assembly (if equipped) to the roof rack side rails: 1. Ensure that both cross-bar assemblies are installed with the F (front) arrow facing towards the front of the vehicle. 2. Use a long, flat object to depress the tongue in the endcaps on both sides of the cross-bar.
Page 76: Locks And Security
Locks and Security KEYS Your vehicle is equipped with two Integrated Keyhead Transmitters (IKTs). The key blade functions as a programmed key which starts the vehicle and unlocks/locks all the doors. The transmitter portion functions as the remote entry transmitter. Your IKTs are programmed to your vehicle;...
Page 77: Locks
Locks and Security POWER DOOR LOCKS • Press the control to unlock all doors. • Press the control to lock all doors. Door key unlocking/locking Unlocking the doors Turn the key in the door cylinder to unlock the driver’s door only. All other doors will remain locked.
Page 78 Locks and Security Power door unlock/lock procedure You must complete Steps 1-5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait 30 seconds. Note: All doors must be closed and remain closed throughout the configuration process.
Page 79 Locks and Security Deactivating/activating autounlock Your vehicle comes with the autounlock feature activated. There are two methods to enable/disable this feature: • Through your authorized dealer, or • by using the power door unlock/lock sequence. Note: The autounlock feature can be activated/deactivated independently of the autolock feature.
Page 80 Locks and Security CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 81 Locks and Security The IKT allows you to: • remotely unlock the vehicle doors. • remotely lock all the vehicle doors. • remotely open the power liftgate glass. • activate the personal alarm. • operate the illuminated entry feature. The remote entry lock/unlock feature operates in any ignition position except while the key is held in the start position.
Page 82 Locks and Security Locking the doors 1. Press and release to lock all the doors. Assuming all vehicle doors and the liftgate are properly closed, the parking lamps will illuminate. 2. Press and release again within three seconds to confirm that all the doors and liftgate are closed and locked.
Page 83: Illuminated Entry
Locks and Security To replace the battery: 1. Twist a thin coin in the slot of the IKT near the key ring in order to remove the battery cover. Note: Do not wipe off any grease on the battery terminals on the back surface of the circuit board.
Page 84: Anti-Theft System
Locks and Security The illuminated entry system will turn off the lights if: • the ignition is turned to the on position, or • the Integrated Keyhead Transmitter lock control is pressed, or • the vehicle is locked using the keyless entry keypad (if equipped), or •...
Page 85 Locks and Security Note: Do not leave a duplicate coded key in the vehicle. Always take your keys and lock all doors when leaving the vehicle. Anti-theft indicator The anti-theft indicator is located in the instrument panel cluster. • When the ignition is in the off position, the indicator will flash once every two seconds to indicate the SecuriLock system...
Page 86 Locks and Security Replacement Integrated Keyhead Transmitters (IKT) and coded keys Note: Your vehicle comes equipped with two Integrated Keyhead Transmitters (IKTs). The IKT functions as both a programmed ignition key that operates all the locks and starts the vehicle, as well as a remote keyless entry transmitter.
Page 87 Locks and Security Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition. 2. Turn the ignition from the 1 (off) position to the 3 (on) position. Keep the ignition in the 3 (on) position for at least three seconds, but no more than 10 seconds.
Page 88: Seating And Safety Restraints
Seating and Safety Restraints FRONT SEATS WARNING: Reclining the seatback can cause an occupant to slide under the seat’s seat belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 89 Seating and Safety Restraints To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint.
Page 90 Seating and Safety Restraints To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint.
Page 91 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Adjusting the front manual seat (if equipped) Lift handle to move seat forward or backward. Pull lever up to adjust seatback. Using the manual lumbar support (if equipped) The lumbar support control is located on the inboard side of the...
Page 92 Seating and Safety Restraints Adjusting the front power seat (if equipped) WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving. You could move out of position to control the vehicle. Then a serious accident could occur. Sudden braking or a collision could cause serious injury.
Page 93 Seating and Safety Restraints The control is located on the outboard side of the seat cushion. Move the front of the control up or down to raise or lower the front portion of the seat cushion. Move the rear of the control up or down to raise or lower the rear portion of the seat cushion.
Page 94 Seating and Safety Restraints Note: Do not do the following: • Place heavy objects on the seat • Operate the seat heater if water or any other liquid is spilled on the seat. Allow the seat to dry thoroughly. To operate the heated seats: •...
Page 95 Seating and Safety Restraints To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 3. Lower the head restraint by pressing and holding the guide sleeve adjust/remove button and pushing down on the head restraint.
Page 96 Seating and Safety Restraints To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Press and hold the adjust/remove button, then pull up on the head restraint. To reinstall the adjustable head restraint, do the following: 1.
Page 97 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Folding down second row seats 1. Remove the second row head restraint. See Second row adjustable head restraints in this chapter.
Page 98 Seating and Safety Restraints Attach the seat belt web snap button to the quarter trim panel snap button. This will ensure that seat belt does not get caught by staying out of the seat back folding path. 4. To release seatback, pull the seatback release lever (on top of seat) toward the front seat.
Page 99 Seating and Safety Restraints Returning the second row seats to upright position 1. Pull seatback up and into upright position making sure seatback locks into place and the red seat unlatched indicator on release paddle is not visible. 2. Rotate seat cushion down into the seating position making sure that the seat cushion is locked into place and that the seat belt...
Page 100: Safety Restraints
Seating and Safety Restraints 4. Remove the second row head restraint from underneath the front seat and reinstall. See Second row adjustable head restraints in this chapter. To remove the second row cushion 1. Lift the yellow tab to release the hinges.
Page 101 Seating and Safety Restraints • Front passenger sensing system • “Passenger airbag off” or “pass airbag off” indicator lamp • Front crash severity sensor. • Restraints Control Module (RCM) with impact and safing sensors. • Restraint system warning light and back-up tone. •...
Page 102 Seating and Safety Restraints Driver’s seat position sensor The driver’s seat position sensor allows your Personal Safety System™ to tailor the deployment level of the driver dual-stage airbag based on seat position. The system is designed to help protect smaller drivers sitting close to the driver airbag by providing a lower airbag output level.
Page 103 Seating and Safety Restraints Front seat belt usage sensors The front seat belt usage sensors detect whether or not the driver and front outboard passenger seat belts are fastened. This information allows your Personal Safety System™ to tailor the airbag deployment and seat belt pretensioner activation depending upon seat belt usage.
Page 104 Seating and Safety Restraints If any of these things happen, even intermittently, have the Personal Safety System™ serviced at an authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision. Safety restraints precautions WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips and the shoulder belt snug across the chest.
Page 105 Seating and Safety Restraints WARNING: Placing a child, 12 years or younger, in the front seat is dangerous. The child could be hit by a deploying airbag and be seriously injured or even killed. A sleeping child is more likely to lean against the door and be hit by the side airbag (if equipped) in a moderate collision.
Page 106 Seating and Safety Restraints • This seat belt system has a retractor assembly that is designed to pay out webbing in a controlled manner. This feature is designed to help reduce the belt force acting on the occupant’s chest. All seat belts in the vehicle are combination lap and shoulder belts. The passenger seat belts have two types of locking modes described below: Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length...
Page 107 Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the seat belt is now in the automatic locking mode.
Page 108 Seating and Safety Restraints Seat belt height adjustment Your vehicle has seat belt height adjustments at the front outboard seating positions. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To adjust the shoulder belt height, squeeze and hold the buttons on the side and slide the height adjuster up or down.
Page 109 Seating and Safety Restraints WARNING: Failure to replace both front restraints under the above conditions could result in severe personal injuries in the event of a collision. The seat belt pretensioners will only function once. After they are deployed, they will not work again and must be replaced immediately, even if there was no front seat occupant seated at the time.
Page 110 Seating and Safety Restraints Conditions of operation If... Then... The driver’s seat belt is not The seat belt warning light illuminates buckled before the ignition 1 minute and the warning chime switch is turned to the on sounds 6 seconds. position...
Page 111 Seating and Safety Restraints If... Then... The driver’s and front The Belt-Minder feature will not passenger’s seat belts are activate. buckled before the ignition switch is turned to the on position or less than 1-2 minutes have elapsed since the ignition switch has been turned to on...
Page 112 Seating and Safety Restraints The following are reasons most often given for not wearing seat belts (All statistics based on U.S. data): Reasons given... Consider... Crashes are rare events 36,700 crashes occur every day. The more we drive, the more we are exposed to rare events, even for good drivers.
Page 113 Seating and Safety Restraints Reasons given... Consider... I have an airbag Airbags offer greater protection when used with seat belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. I’d rather be thrown clear Not a good idea. People who are ejected are 40 times more likely to DIE.
Page 114: Airbags
Seating and Safety Restraints 1. Turn the ignition switch to the on position. DO NOT START THE ENGINE. 2. Wait until the seat belt warning light turns off (Approximately one minute). • Step 3 must be completed within 30 seconds after the seat belt warning light turns off.
Page 115 Seating and Safety Restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the seat belt to help protect the driver and right front passenger from certain upper body injuries. WARNING: Airbags DO NOT inflate slowly or gently and the risk of injury from a deploying airbag is greatest close to the trim covering the airbag...
Page 116 Seating and Safety Restraints WARNING: Do not put anything on or over the airbag module including hands or feet. Placing objects on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury. WARNING: Do not attempt to service, repair, or modify the Airbag Supplemental Restraint Systems or its fuses.
Page 117 Seating and Safety Restraints WARNING: Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 118 Seating and Safety Restraints extremely important that occupants be properly restrained as far away from the airbag module as possible while maintaining vehicle control. WARNING: Several airbag system components get hot after inflation. Do not touch them after inflation or you may be burned.
Page 119 Seating and Safety Restraints Front passenger sensing system The front passenger sensing system is designed to meet the regulatory requirements of Federal Motor Vehicle Safety Standard (FMVSS) 208 and is designed to disable (will not inflate) the front passenger’s frontal airbag under certain conditions.
Page 120 Seating and Safety Restraints • When the front passenger sensing system disables (will not inflate) the front passenger frontal airbag, the indicator lamp will illuminate and stay lit to remind you that the front passenger frontal airbag is disabled. • If the child restraint has been installed and the indicator lamp is not lit, then turn the vehicle off, remove the child restraint from the vehicle and reinstall the restraint following the child restraint manufacturer’s instructions.
Page 121 Seating and Safety Restraints WARNING: Even with Advanced Restraints Systems, children 12 and under should be properly restrained in a rear seating position. After all occupants have adjusted their seats and put on seat belts, it’s very important that they continue to sit properly. A properly seated occupant sits upright, leaning against the seat back, and centered on the seat cushion, with their feet comfortably extended on the floor.
Page 122 Seating and Safety Restraints If you think that the status of the passenger airbag off indicator lamp is incorrect, check for the following: • Objects lodged underneath the seat • Objects between the seat cushion and the center console (if equipped) •...
Page 123 Seating and Safety Restraints • Driver and/or adult passengers should check for any objects lodged underneath the front passenger seat or cargo interfering with the seat. • Remove the obstruction(s) (if found). • Restart the vehicle. • Wait at least 2 minutes and verify that the airbag readiness lamp is no longer illuminated •...
Page 124 Seating and Safety Restraints WARNING: Unless serviced, the system may not function properly in the event of a collision. Seat-mounted side airbag system WARNING: Do not place objects or mount equipment on or near the airbag cover on the side of the seatbacks of the front seats or in front seat areas that may come into contact with a deploying airbag.
Page 125 Seating and Safety Restraints How does the side airbag system work? The design and development of the side airbag system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 126 Seating and Safety Restraints WARNING: Several airbag system components get hot after inflation. Do not touch them after inflation. WARNING: If the side airbag has deployed, the airbag will not function again. The side airbag system (including the seat) must be inspected and serviced by an authorized dealer.
Page 127 Seating and Safety Restraints Side-curtain airbag system WARNING: Do not place objects or mount equipment on or near the headliner at the siderail that may come into contact with a deploying side-curtain airbags. Failure to follow these instructions may increase the risk of personal injury in the event of a collision.
Page 128 Seating and Safety Restraints How do the side-curtain airbags work? The design and development of the side air curtain system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 129 Seating and Safety Restraints The side-curtain airbags are mounted to roof side-rail sheet metal, behind the headliner, above the first and second row seats. In certain lateral collisions or rollover events, the side-curtain airbags will be activated, regardless of which seats are occupied. In certain rollover events, the side-curtain airbag on both sides of the vehicle will be inflated, regardless of which seats are occupied.
Page 130 Seating and Safety Restraints A difficulty with the system is indicated by one or more of the following: • The readiness light (same light as for front airbag system) will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is turned on.
Page 131: Child Restraints
Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Airbag supplemental restraint system (SRS) in this chapter for special instructions about using airbags. Important child restraint precautions WARNING: Always make sure your child is secured properly in a device that is appropriate for their height, age and weight.
Page 132 Seating and Safety Restraints Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Infants or Children weighing 40 lb (18 kg) or Use a child safety toddlers less (generally age four or younger) seat (sometimes called an infant carrier, convertible seat, or toddler...
Page 133 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by “X” LATCH LATCH Seat Seat belt Seat (lower (lower belt belt Restraint Child anchors anchors LATCH only Type Weight only) (lower tether anchors...
Page 134 Seating and Safety Restraints WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision, which may result in serious injury or death.
Page 135 Seating and Safety Restraints Follow all the safety restraint and airbag precautions that apply to adult passengers in your vehicle. If the child is the proper height, age, and weight (as specified by your child safety seat or booster manufacturer), fits the restraint and can be restrained properly, then restrain the child in the child safety seat or with the belt-positioning booster.
Page 136 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts The rear seat head restraints must be removed when using a child seat that utilizes the top tether anchor. Check to make sure the child seat is properly secured before each use. Children 12 and under should be properly restrained in a rear seating position whenever possible.
Page 137 Seating and Safety Restraints 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat...
Page 138 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 139 Seating and Safety Restraints Sometimes, a slight lean towards the buckle will additionally help to remove remaining slack from the belt. 9. Attach the tether strap (if the child seat is equipped). Refer to Attaching child safety seats with tether straps later in this chapter.
Page 140 Seating and Safety Restraints Your vehicle has LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol. The LATCH anchors are located at the rear section of the rear seat between the cushion and seat back. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments.
Page 141 Seating and Safety Restraints Use of inboard lower anchors from the outboard seating positions (center seating use) The lower anchors at the center of the second row rear seat are spaced 400 mm (16 inches) apart. The standardized spacing for LATCH lower anchors is 280 mm (11 inches) center to center.
Page 142 Seating and Safety Restraints Attaching child safety seats with tether straps Many forward-facing child safety seats include a tether strap which extends from the back of the child safety seat and hooks to an anchoring point called the top tether anchor. Tether straps are available as an accessory for many older safety seats.
Page 143 Seating and Safety Restraints 2. Locate the correct anchor for the selected seating position. There are three tether anchors located on the headliner at the rear of the vehicle. 3. Clip the tether strap to the anchor as shown. The arrow in the above graphic points toward the front of the vehicle.
Page 144 Seating and Safety Restraints Child booster seats The belt-positioning booster (booster seat) is used to improve the fit of the vehicle seat belt. Children outgrow a typical child seat (e.g., convertible or toddler seat) when they weigh about 40 lb (18 kg) and are around four (4) years of age.
Page 145 Seating and Safety Restraints Booster seats should be used until you can answer YES to ALL of these questions when seated without a booster seat: • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat cushion? •...
Page 146 Seating and Safety Restraints • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 147 Seating and Safety Restraints If the booster seat slides on the vehicle seat, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition. Do not introduce any item thicker than this under the booster seat.
Page 148 Seating and Safety Restraints The energy absorbing functions may have been activated in a collision so the restraints should be examined; if the front airbags have deployed, the pretensioners have also deployed and must be replaced — regardless of whether there was an occupant in the passenger seat or not. The optional side airbags are not connected to the pretensioners.
Page 149: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 150 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter. Information on transfer case maintenance can be found in the Maintenance and Specifications chapter.
Page 151: Tire Information
Tires, Wheels and Loading • Narrower — to provide greater maneuverability in tight spaces, particularly in off-road use. As a result of the above dimensional differences, SUV’s and trucks often will have a higher center of gravity and a greater difference in center of gravity between the loaded and unloaded condition.
Page 152 Tires, Wheels and Loading Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
Page 153: Tire Inflation
Tires, Wheels and Loading Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture.
Page 154: Inflating Tires
Tires, Wheels and Loading Every day before you drive, check your tires. If one looks lower than the others, use a tire gauge to check pressure of all tires and adjust if required. At least once a month and before long trips, inspect each tire and check the tire pressure with a tire gauge (including spare, if equipped).
Page 155 Tires, Wheels and Loading When weather temperature changes occur, tire inflation pressures also change. A 10°F (6°C) temperature drop can cause a corresponding drop of 1 psi (7 kPa) in inflation pressure. Check your tire pressures frequently and adjust them to the proper pressure which can be found on the Safety Compliance Certification Label or Tire Label.
Page 156 Tires, Wheels and Loading TIRE CARE Inspecting your tires and wheel valve stems Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check the tire and valve stems for holes, cracks, or cuts that may permit air leakage and repair or replace the tire and replace the valve stem.
Page 157 Tires, Wheels and Loading WARNING: Age Tires degrade over time depending on many factors such as weather, storage conditions, and conditions of use (load, speed, inflation pressure, etc.) the tires experience throughout their lives. In general, tires should be replaced after six years regardless of tread wear.
Page 158 Tires, Wheels and Loading WARNING: Only use replacement tires and wheels that are the same size, load index, speed rating and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Mazda. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
Page 159 Tires, Wheels and Loading It is recommended that the two front tires or two rear tires generally be replaced as a pair. The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Mazda Motor Corporation may affect the operation of your Tire Pressure Monitoring System.
Page 160 Tires, Wheels and Loading Tire and wheel alignment A bad jolt from hitting a curb or pothole can cause the front end of your vehicle to become misaligned or cause damage to your tires. If your vehicle seems to pull to one side, vibrate or shake when you’re driving, the wheels may be out of alignment.
Page 161 Tires, Wheels and Loading • Front Wheel Drive (FWD) vehicles (front tires at top of diagram) • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD)/All Wheel Drive (AWD) vehicles (front tires at top of diagram)
Page 162 Tires, Wheels and Loading Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Mazda dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare tire/wheel.
Page 163 Tires, Wheels and Loading 3. 65: Indicates the aspect ratio which gives the tire’s ratio of height to width. 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter.
Page 164 Tires, Wheels and Loading 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 165 Tires, Wheels and Loading 13. Maximum Permissible Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 166 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 167: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 168 Tires, Wheels and Loading The Tire Pressure Monitoring System complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 169 Tires, Wheels and Loading Understanding your Tire Pressure Monitoring System (TPMS) The Tire Pressure Monitoring System measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The Low Tire Pressure Warning Lamp will turn ON if the tire pressure is significantly low.
Page 170 Tires, Wheels and Loading When you believe your system is not operating properly The main function of the Tire Pressure Monitoring System is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
Page 171 Tires, Wheels and Loading Low Tire Pressure Possible cause Customer Action Required Warning Light Flashing Warning Spare tire in use Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.
Page 172: Vehicle Loading
Tires, Wheels and Loading SNOW TIRES AND CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Mazda. Use of any tire or wheel not recommended by Mazda can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 173 Tires, Wheels and Loading Base Curb Weight – is the weight of the vehicle including a full tank of fuel and all standard equipment. It does not include passengers, cargo, or optional equipment. Vehicle Curb Weight – is the weight of your new vehicle when you picked it up from your authorized dealer plus any aftermarket equipment.
Page 174 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 175 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 176 Tires, Wheels and Loading • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury.
Page 177 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 178 Tires, Wheels and Loading WARNING: Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lb.”...
Page 179: Trailer Towing
Tires, Wheels and Loading the vehicle with the rear seat folded down, you have room for 12-100 lb. (45 kg) bags of cement. Do you have enough load capacity to transport the cement to your home? If you and your friend each weigh 220 lb.
Page 180 Tires, Wheels and Loading Follow these guidelines to ensure safe towing procedure: • Be sure to locate all the warnings supplied by the trailer rental or sales company and study the unique requirements of each trailer you intend to tow. •...
Page 181 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Engine Maximum Trailer Weight Maximum GCWR - lb Range - lb (kg) frontal area of (kg) trailer - ft Notes: For high altitude operation, reduce GCW by 2% per 1,000 ft. (300 meters) elevation.
Page 182 Tires, Wheels and Loading WARNING: Do not exceed the GVWR or the GAWR specified on the certification label. Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in: • engine damage •...
Page 183 Tires, Wheels and Loading The braking system of the tow vehicle is rated for operation at the GVWR not GCWR. Trailer lamps Trailer lamps are required on most towed vehicles. Make sure all running lights, brake lights, turn signals and hazard lights are working. Do not connect trailer lamps directly to your vehicle’s tail lamps.
Page 184: Recreational Towing
Tires, Wheels and Loading • Allow more distance for stopping with a trailer attached. • The trailer tongue weight should be 10–15% of the loaded trailer weight. • After you have traveled 50 miles (80 km), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. •...
Page 185 Tires, Wheels and Loading Front Wheel Drive (FWD) vehicles: Tow your Front Wheel Drive vehicle with all four wheels on the ground or with the front wheels off the ground by using a tow dolly. If you are using a tow dolly follow the instructions specified by the equipment provider.
Page 186 Tires, Wheels and Loading Note: If you tow your vehicle with all four wheels on the ground, follow these instructions: • For automatic transmission vehicles, have your transmission fluid level checked by an authorized dealer. For the correct transmission fluid level when flat towing (all four wheels on the ground), refer to Transmission fluid in the Maintenance and Specifications chapter.
Page 187: Driving
Driving STARTING Positions of the ignition 1. Off— locks the gearshift lever and steering column and allows key removal. 2. Accessory— allows the electrical accessories such as the radio to operate while the engine is not running. 3. On— all electrical circuits operational and warning lights will illuminate.
Page 188 Driving WARNING: If you smell exhaust fumes inside your vehicle, have your authorized dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine.
Page 189 Driving • Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: • Make sure the parking brake is set. • Press and hold the clutch pedal to the floor and put the gearshift lever in N (Neutral).
Page 190 Driving Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights. Starting the engine 1. Turn the key to 3 (on) without turning the key to 4 (start). If there is difficulty in turning the key, rotate the steering wheel until the key turns freely.
Page 191 Driving Do not crank the engine for more than 10 seconds at a time as starter damage may occur. If the engine fails to start, turn the key to off and wait 30 seconds before trying again. Do not use starting fluid such as ether in the air intake system. Such fluid could cause immediate explosive damage to the engine and possible personal injury.
Page 192 Driving Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least once inch (2.5 cm). Adjust the heating or air conditioning (if equipped) to bring in fresh air. Note: Improve vehicle ventilation by keeping all air inlet vents clear of snow, leaves and other debris.
Page 193 Driving • Use as short an extension cord as possible. • Do not use multiple extension cords. Instead, use one extension cord which is long enough to reach from the engine block heater cord to the outlet without stretching. • Make certain that the extension cord is in excellent condition (not patched or spliced).
Page 194: Brakes
Driving BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by an authorized dealer. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by an authorized dealer.
Page 195 Driving Using ABS When hard braking is required, apply continuous force on the brake pedal; do not pump the brake pedal since this will reduce the effectiveness of the ABS and will increase your vehicle’s stopping distance. The ABS will be activated immediately, allowing you to retain steering control during hard braking and on slippery surfaces.
Page 196: Electronic Stability Control
Driving WARNING: Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transmission) or in 1 (First) (manual transmission). Note: The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency.
Page 197 Driving WARNING: Remember that even advanced technology cannot defy the laws of physics. It’s always possible to lose control of a vehicle due to inappropriate driver input for the conditions. Aggressive driving on any road condition can cause you to lose control of your vehicle increasing the risk of personal injury or property damage.
Page 198 Driving The system includes an ESC button on the instrument panel, and a “sliding car” icon in the instrument cluster. The “sliding car” icon in the instrument cluster will illuminate temporarily during start-up as part of a normal system self-check, or during driving if a driving situation causes the ESC system to operate.
Page 199 Driving If the TCS is activated excessively in a short period of time, the braking portion of the system may become temporarily disabled to allow the brakes to cool down. In this situation, TCS will use only engine power reduction or transfer to help control the wheels from over-spinning. When the brakes have cooled down, the system will regain all features.
Page 200 Driving Certain adverse driving maneuvers may activate the RSC system, which include: • Emergency lane-change • Taking a turn too fast • Quick maneuvering to avoid an accident, pedestrian or obstacle Switching Off Electronic Stability Control (ESC) If the vehicle is stuck in snow, mud or sand, and seems to lose engine power, switching off certain features of the ESC system may be beneficial because the wheels are allowed to spin.
Page 201 Driving WARNING: Trailer sway control does not prevent a trailer from swaying, it mitigates the sway from increasing once it has occurred. TSC cannot stop all trailers from swaying. If you are experiencing trailer sway, it is likely that the trailer is improperly loaded for the correct tongue weight or the speed of the vehicle and trailer is too high.
Page 202 Driving STEERING Your vehicle is equipped with an electric power-assisted steering (EPAS) system. There is no fluid reservoir to check or fill. If your vehicle loses electrical power while you are driving (or if the ignition is turned off), you can steer the vehicle manually, but it takes more effort.
Page 203 Driving WARNING: Vehicles with a higher center of gravity such as utility vehicles and trucks handle differently than vehicles with a lower center of gravity. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 204 Driving 2. Using a screwdriver or similar tool, carefully pry out the small Brake Transmission Shift Interlock (BTSI) cover cap located to the right of the gearshift lever. 3. Insert a screwdriver or similar tool straight down into the access hole and press downward while pulling the gearshift lever out of the P (Park) position and into the N (Neutral) position.
Page 205: Transmission Operation
Driving AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Automatic Transmission Adaptive Learning Your transmission is equipped with an adaptive learning strategy found in the vehicle computer. This feature is designed to increase durability and provide consistent shift feel over the life of the vehicle. A new vehicle or transmission may have firm and/or soft shifts.
Page 206 Driving WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the off position and remove the key whenever you leave your vehicle. R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse).
Page 207 Driving • The grade assist lamp in the instrument cluster is illuminated. Grade assist is designed to aid the driver with optimal gear selection in hilly terrain or mountainous areas but is not intended for normal operation. It is recommended that you return to O/D (overdrive mode) on flat terrain to provide the best fuel economy and transmission function.
Page 208 Driving 2. Press the clutch pedal to the floor, then put the gearshift lever in the neutral position. 3. Start the engine. 4. Press the brake pedal and move the gearshift lever to the desired gear; 1 (First) or R (Reverse).
Page 209: Rear-View Camera System
Driving 1. Hold the clutch pedal down and move the gearshift lever into the neutral position. 2. From the neutral position, move the gearshift lever all the way to the right, then move it down into the R (Reverse) position. Note: The gearshift lever can only be moved into R (Reverse) by moving it from left of 3 (Third) and 4 (Fourth) before shifting into R (Reverse).
Page 210 Driving • (1) Rear bumper • (2) Red zone • (3) Yellow zone • (4) Green zone • (5) Centerline of vehicle Always use caution while backing. Objects in the red zone are closest to your vehicle and objects in the green zone are further away.
Page 211 Driving WARNING: The camera is a reverse aid supplement device that still requires the driver to use it in conjunction with the rearview mirror and the side mirrors for maximum coverage. WARNING: Objects that are close to either corner of the bumper or under the bumper, might not be seen on the screen due to the limited coverage of the camera.
Page 212 Driving Your vehicle is equipped with an intelligent 4WD System that continuously monitors vehicle conditions and automatically adjusts the power distribution between the front and rear wheels. It combines transparent all-surface operation with highly capable four-wheel drive. The 4WD system is always active and requires no driver input. It is capable of handling all road conditions, including street and highway driving as well as off-road and winter driving.
Page 213 Driving • It may be safer to stay on the apron or shoulder of the road and slow down gradually before returning to the pavement. You may lose control if you do not slow down or if you turn the steering wheel too sharply or abruptly.
Page 214 Driving Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur. WARNING: Do not spin the wheels at over 35 mph (56 km/h). The tires may fail and injure a passenger or bystander. Emergency maneuvers •...
Page 215 Driving Avoid excessive speed because vehicle momentum can work against you and cause the vehicle to become stuck to the point that assistance may be required from another vehicle. Remember, you may be able to back out the way you came if you proceed with caution. Mud and water NOTE: •...
Page 216 Driving “Tread Lightly” is an educational program designed to increase public awareness of land-use regulations and responsibilities in our nations wilderness areas. Mazda Motor Corporation joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 217 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
Page 218 Driving WARNING: If you are driving in slippery conditions that require tire chains or cables, then it is critical that you drive cautiously. Keep speeds down, allow for longer stopping distances and avoid aggressive steering to reduce the chances of a loss of vehicle control which can lead to serious injury or death.
Page 219 Driving DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).
Page 220: Roadside Emergencies
Roadside Emergencies HAZARD FLASHER CONTROL The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Press in the flasher control and all front and rear direction signals will flash.
Page 221: Fuses And Relays
Roadside Emergencies This switch is located in the front passenger’s footwell, behind a flip-up cover, by the kick panel access cover. To reset the switch: 1. Turn the ignition to the off position. 2. Check the fuel system for leaks. 3.
Page 222 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 223 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Protective Circuits Location Rating Not used (spare) Brake on/off switch Not used (spare) Moon roof Brake-shift interlock (BSI), Passenger compartment fuse panel Turn signals, Stop lamps Low beam headlamps (left) Low beam headlamps (right) Interior lights Backlighting...
Page 224 Roadside Emergencies Fuse/Relay Fuse Amp Protective Circuits Location Rating Climate control Not used (spare) All lock motor feeds, Liftgate release, Liftglass release Heated seat Rear wiper Datalink Fog lamps Park lamps High beam headlamps Horn relay Demand lamps Instrument panel cluster Ignition switch Radio Instrument panel cluster...
Page 225 Roadside Emergencies Fuse/Relay Fuse Amp Protective Circuits Location Rating Not used (spare) Rear wiper logic, Heated seats relay, Instrument cluster Not used (spare) Front wiper logic, Blower motor relay 7.5A Occupant classification system (OCS), Passenger airbag deactivation indicator (PADI) 30A Circuit Power windows Breaker —...
Page 226 Roadside Emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Protected Circuits Location Rating 80A Midi Electronic power steering module (EPAS) 125A Midi Passenger compartment fuse panel 15A* Heated mirror 30A** Rear defroster 20A** Rear power point (center console) —...
Page 227 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 15A* Trailer tow turn lamps — Not used 40A** Cooling fan 1 40A** Cooling fan 2 20A** ABS solenoid 30A** Power seats — A/C clutch relay — Rear defroster relay — Fuel relay —...
Page 228: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating — Liftgate latch relay — Not used — PCM diode — Start diode 10A* Run/start, Reverse lamps, Rear defrost relay — Not used * Mini fuse ** Cartridge fuse CHANGING A FLAT TIRE If you get a flat tire while driving: •...
Page 229 Roadside Emergencies WARNING: Refer to Tire pressure monitoring system (TPMS) in the Tire, Wheels and Loading chapter for important information. If the tire pressure monitor sensor becomes damaged, it will no longer function. Dissimilar spare tire/wheel information WARNING: Failure to follow these guidelines could result in an increased risk of loss of vehicle control, injury or death.
Page 230 Roadside Emergencies Use of one of the dissimilar spare tires listed above at any one wheel location can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs •...
Page 231 Roadside Emergencies Stopping and securing the vehicle 1. Park on a level surface, set the parking brake and activate hazard flashers. 2. Place gearshift lever in P (Park) (automatic transmission) or R (Reverse) (manual transmission) and turn engine off. Removing the jack and tools The jack and tools are located under the carpeted load floor.
Page 232 Roadside Emergencies Remove the lug wrench from the jack in order to remove the spare tire from under the vehicle. Removing the spare tire or spare tire and tether (if equipped) 1. Insert the lug wrench through the access hole in the rear bumper.
Page 233 Roadside Emergencies 5. Use the lug wrench to remove the lug nut from the spare tire tether. 6. If not replacing the spare or flat tire to the underbody storage area, raise winch up into the installed position. 7. Use the attached fastener strap (2) to tie the tether end to the winch actuator shaft (if equipped).
Page 234 Roadside Emergencies WARNING: Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 235 Roadside Emergencies • Front View shown from rear of front tire. Position the jack directly below the protruding bolt. • Rear View shown from forward of rear tire. Position the jack directly below the stud on the rear trailing arm.
Page 236 Roadside Emergencies 3. Position the jack according to the guides and turn the jack handle clockwise until the tire is a maximum of 1 inch (25 mm) off the ground. Never use the differentials as a jacking point. WARNING: To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a...
Page 237 Roadside Emergencies Stowing the jack and tools • Make sure the jack is fully lowered. • Reclip the tools onto the jack making sure that the tools are fully contained by the clips as shown. • Reinstall the jack in the pocket with the left side first, then snap the right side down.
Page 238: Wheel Lug Nut Torque
Roadside Emergencies carrier will ratchet when the tire is in the fully stowed position. The spare tire carrier has a built-in ratchet feature that will not allow you to overtighten. If the spare tire carrier ratchets with very little effort, take the vehicle to your authorized Mazda dealer for assistance at your earliest convenience.
Page 239: Overheating
Roadside Emergencies Note: Inspect the wheel pilot hole prior to installation. If there is visible corrosion in wheel pilot hole, remove loose particles by wiping with clean rag and apply grease. Apply grease only to the wheel pilot hole surface by smearing a “dime” (1 square cm) sized glob of grease around the wheel pilot surface (1) with end of finger.
Page 240: Jump Starting
Roadside Emergencies WARNING: When the engine and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury. Do not remove the cooling system cap when the engine and radiator are hot. See Adding engine coolant in the Maintenance and Specifications section.
Page 241 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the automatic transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 242 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 243 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the disabled vehicle’s engine, away from the battery and the fuel injection system. NOTE: Do not attach the negative (-) cable to fuel lines, engine rocker covers, the intake manifold or electrical components as grounding points.
Page 244 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 245 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 246: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member of a roadside assistance program, your roadside assistance service provider. It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment.
Page 247 Roadside Emergencies If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Emergency towing In case of a roadside emergency with a disabled vehicle (without access to wheel dollies, car hauling trailer, or flatbed transport vehicle) your vehicle (regardless of transmission powertrain configuration) can be flat towed (all wheels on the ground) under the following conditions: •...
Page 248: Customer Assistance
Customer Assistance CUSTOMER ASSISTANCE (U.S.A. MAINLAND AND HAWAII) Your complete and permanent satisfaction is our business. We are here to serve you. All Authorized Mazda Dealers have the knowledge and the tools to keep your Mazda vehicle in top condition. If you have any questions or recommendations for improvement regarding the service of your Mazda vehicle or servicing by Authorized Mazda Dealer personnel, we recommend that you take the following...
Page 249 Customer Assistance 4. Purchase date and current mileage 5. Your authorized dealer’s name and location 6. Your question(s) If you live outside the U.S.A., please contact your nearest Mazda Distributor. STEP 3: Contact Better Business Bureau (BBB) Mazda North American Operations realizes that mutual agreement on some issues may not be possible.
Page 250 Customer Assistance Boulevard, Arlington, Virginia 22203] through local Better Business Bureaus. BBB AUTO LINE and MAZDA have been certified by the Arbitration Certification Program of the California Department of Consumer Affairs. 2. If you have a problem arising under a MAZDA written warranty, we encourage you to bring it to our attention.
Page 251 Customer Assistance 7. California Civil Code Section 1793.2(d) requires that, if MAZDA or its representative is unable to repair a new motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, MAZDA may be required to replace or repurchase the vehicle.
Page 252 Customer Assistance 10. You may reject the decision issued by a BBB AUTO LINE arbitrator. If you reject the decision, you will be free to pursue further legal action. The arbitrator’s decision and any findings will be admissible in a court action. 11.
Page 253 Customer Assistance 4. Purchase date. 5. Present odometer reading. 6. Your authorized dealer’s name and location 7. The nature of your problem and/or cause of dissatisfaction. The Department, in cooperation with the local Mazda Service Representative, will review the case to determine if everything possible has been done to ensure your satisfaction.
Page 254 Customer Assistance CAMVAP is fully implemented in all provinces and territories. Consumers wishing to obtain further information about the Program can obtain an information booklet from their authorized dealer, the Provincial Administrator at 1 (800) 207-0685, or by contacting the Canadian Motor Vehicle Arbitration Office At: 235 Yorkland Boulevard, Suite 407 North York, Ontario...
Page 255 Customer Assistance CUSTOMER ASSISTANCE (PUERTO RICO & VIRGIN ISLANDS) Your complete and permanent satisfaction is our business. That is why all Authorized Mazda Dealers have the knowledge and the tools to keep your Mazda vehicle in top condition. If you have any questions or recommendations for improvement regarding the service of your Mazda vehicle or servicing by Authorized Mazda Dealer personnel, we recommend that you take the following steps:...
Page 256 Customer Assistance IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, the manufacturer shall be required to either replace the vehicle with one substantially identical or repurchase the vehicle and reimburse the buyer in an amount equal to the actual price paid or payable by the consumer (less a reasonable allowance for consumer...
Page 257 Customer Assistance CANADA Mazda Canada, Inc. 55 Vogell Road Richmond Hill, Ontario L4B 3K5 Canada TEL: 1 (800) 263–4680 (in Canada) (416) 609–9909 (outside Canada) PUERTO RICO & VIRGIN ISLANDS Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936–2722 TEL: (787) 788–9300 GUAM (d.b.a.
Page 258 Customer Assistance WARRANTIES FOR YOUR MAZDA • New Vehicle Limited Warranty • Safety Restraint System Limited Warranty • Anti-perforation Limited Warranty • Federal Emission Control Warranty – Emission Defect Warranty – Emission Performance Warranty • California Emission Control Warranty (if applicable) •...
Page 259 Customer Assistance Outside Canada Government regulations in Canada require that automobiles meet specific emission regulations and safety standards. Therefore, vehicles built for use in Canada, may differ from those sold in other countries. The differences may make it difficult or even impossible for your vehicle to receive satisfactory servicing in other countries.
Page 260 Customer Assistance WARNING: Add-On Electrical and Electronic Equipment: Incorrectly choosing or installing improper add-on equipment or choosing an improper installer could be dangerous. Essential systems could be damaged, causing engine stalling, air-bag (SRS) activation, ABS inactivation, or a fire in the vehicle. Be very careful in choosing and installing add-on electrical equipment, such as mobile telephones, two-way radios, stereo systems, and car alarm systems.
Page 261: Reporting Safety Defects (U.s. Only)
Customer Assistance REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect that could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mazda Corporation.
Page 262: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo. • Never use strong household detergents or soap, such as dish washing or laundry liquid. These products can discolor and spot painted surfaces.
Page 263 Cleaning PAINT CHIPS Your dealer has touch-up paint to match your vehicle’s color. Touch-up paint can be used to repair minor scratches to painted surfaces. • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips. •...
Page 264 Cleaning • 2.5L I4 Engine • 3.0L V6 Engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. • Never wash or rinse any ignition coil, spark plug wire or spark plug well, or the area in and around these locations.
Page 265 Cleaning • If tar or grease spots are present, use Extra Strength Tar and Road Oil Remover (0000–77–410E-01), available at your authorized Mazda dealer. WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly.
Page 266 Cleaning • Be certain to wash or wipe your hands clean if you have been in contact with certain products such as insect repellent and suntan lotion in order to avoid possible damage to the interior painted surfaces. INTERIOR For fabric, carpets, cloth seats, seat belts and seats equipped with side air bags (if equipped): •...
Page 267 Cleaning UNDERBODY Flush the complete underside of your vehicle frequently. Keep body and door drain holes free from packed dirt. MAZDA CAR CARE PRODUCTS Your Mazda dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 268: Maintenance And Specifications
Maintenance and Specifications INTRODUCTION Be extremely careful to prevent injury to yourself and others or damage to your vehicle when using this manual for inspection and maintenance. If you’re unsure about any procedure it describes, we strongly urge you to have a reliable and qualified service shop perform the work, preferably an authorized Mazda Dealer.
Page 269 Maintenance and Specifications SCHEDULE 1 I: Inspect and repair, clean, adjust, or replace if necessary (Oil-permeated air filter cannot be cleaned using the air-blow method) R: Replace L: Lubricate Maintenance Interval (Number of months or km (miles), whichever comes first) Months Maintenance Item x 1000 Miles...
Page 270 Maintenance and Specifications Maintenance Interval (Number of months or km (miles), whichever comes first) Months Maintenance Item x 1000 Miles 7.5 15 22.5 30 37.5 45 52.5 60 67.6 82.5 (x 1000 Km) (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144) Drum brakes Tire (rotation), check wheel lug Rotate every 7,500 miles (12,000 km)
Page 271 Maintenance and Specifications SCHEDULE 2 I: Inspect and repair, clean, adjust, or replace if necessary (Oil-permeated air filter cannot be cleaned using the air-blow method) R: Replace L: Lubricate Maintenance Interval (Number of months or km (miles), whichever comes first) Months Maintenance Item x 1000 miles...
Page 272 Maintenance and Specifications Maintenance Interval (Number of months or km (miles), whichever comes first) Months Maintenance Item x 1000 miles (x 1000 Km) (8) (16) (24) (32) (40) (48) (56) (64) (72) (80) (88) (96) CHASSIS and BODY Brake lines, hoses and connections Brake fluid level Disc brakes Drum brakes...
Page 273 Maintenance and Specifications OWNER MAINTENANCE SCHEDULE The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an authorized Mazda Dealer or qualified service technician as soon as possible.
Page 274 Maintenance and Specifications PRECAUTIONS WHEN SERVICING YOUR VEHICLE WARNING: A hot engine is dangerous. If the engine has been running, parts of the engine compartment can become very hot. You could be burned. Don’t inspect the coolant system or add coolant when the engine is hot.
Page 275 Maintenance and Specifications Working with the engine on • Automatic transmission: 1. Set the parking brake and shift to P (Park). 2. Block the wheels. • Manual transmission: 1. Set the parking brake, press and hold the clutch pedal, place the gearshift in N (Neutral), and release the clutch pedal.
Page 276: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.5L I4 engine 1. Engine coolant reservoir 2. Engine oil filler cap 3. Automatic transmission dipstick (if equipped) 4. Brake/Clutch fluid reservoir 5. Air filter assembly 6. Power distribution box 7. Battery 8.
Page 277 Maintenance and Specifications 3.0L V6 engine 1. Engine coolant reservoir 2. Air filter assembly 3. Brake fluid reservoir 4. Automatic transmission fluid dipstick 5. Power distribution box 6. Battery 7. Coolant bleed valve 8. Engine oil dipstick 9. Engine oil filler cap 10.
Page 278 Maintenance and Specifications WINDSHIELD WASHER FLUID Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Mazda specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash.
Page 279 Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper blade and arm away from the glass. 2. Squeeze the locking tabs to release the blade from the arm and pull the blade away from the arm to remove it. 3.
Page 280: Engine Oil
Maintenance and Specifications Changing rear window wiper blade The rear wiper arm is designed without a service position. This reduces the risk of damage to the blade in an automatic car wash. To replace the wiper blade: 1. Grab the wiper arm with one hand close to the arm/blade joint and pull it as far away from the glass as possible.
Page 281 Maintenance and Specifications • 2.5L I4 engine • 3.0L V6 engine 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is within the lower and upper holes or lower and upper lines, the oil level is acceptable.
Page 282 Maintenance and Specifications • 3.0L V6 engine • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter. • Do not overfill the engine with oil. Oil levels above the upper hole or upper line may cause engine damage. If the engine is overfilled, some oil must be removed from the engine by an authorized dealer.
Page 283 Maintenance and Specifications Engine oil and filter recommendations SAE 5W-20 engine oil is recommended Look for this certification trademark. Use SAE 5W-20 motor oil certified for gasoline engines by the American Petroleum Institute (API). An oil with this trademark symbol conforms to the current engine and emission system protection standards and fuel economy requirements of the International Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S.
Page 284: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Mazda maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
Page 285 Maintenance and Specifications WARNING: Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.
Page 286: Engine Coolant
Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance.
Page 287 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the FULL COLD level or within the COLD FILL RANGE as listed on the engine coolant reservoir (depending upon application).
Page 288 Maintenance and Specifications • The use of an improper coolant may harm engine and cooling system components and may void the warranty of your vehicle’s engine cooling system. If you are unsure which type of coolant your vehicle requires, contact your local authorized dealer. WARNING: Do not put engine coolant in the windshield washer fluid reservoir.
Page 289 Maintenance and Specifications Add the proper mixture of coolant and water to the cooling system by following these steps: 1. Before you begin, turn the engine off and let it cool. 2. When the engine is cool, wrap a thick cloth around the coolant pressure relief cap on the coolant reservoir (an opaque plastic bottle).
Page 290 Maintenance and Specifications Recycled engine coolant Not all coolant recycling processes produce coolant which meets Mazda recommended coolants. Use of a recycled engine coolant which does not meet the Mazda recommended coolant, may harm engine and cooling system components. Always dispose of used automotive fluids in a responsible manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids.
Page 291 Maintenance and Specifications • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate protection at the temperatures in which you drive. Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection.
Page 292: Fuel Information
Maintenance and Specifications 2. Arrange for the vehicle to be taken to an authorized dealer. 3. If this is not possible, wait a short period for the engine to cool. 4. Check the coolant level and replenish if low. WARNING: Never remove the coolant reservoir cap while the engine is running or hot.
Page 293 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuels such as gasoline and ethanol are highly toxic and if swallowed can cause death or permanent injury.
Page 294 Maintenance and Specifications Pure ethanol is the alcohol which is the intoxicating agent in liquor, beer and wine. It is distilled from the fermentation of plants such as field corn and sugar cane. When ethanol is produced for use in motor fuels, a small amount of gasoline is added to make it unfit for beverage use.
Page 295 Maintenance and Specifications Refueling WARNING: Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 296 Maintenance and Specifications 4. After you are done pumping fuel, slowly remove the fuel filler nozzle—allow about five seconds after pumping fuel before removing the fuel filler nozzle. This allows residual fuel to drain back into the fuel tank and not spill onto the vehicle. Note: A fuel spillage concern may occur if overfilling the fuel tank.
Page 297 Maintenance and Specifications The use of leaded fuel is prohibited by law and could damage your vehicle. Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based additives. Note: Use of any fuel other than those recommended may cause powertrain damage, a loss of vehicle performance, and repairs may not be covered under warranty.
Page 298 Maintenance and Specifications Fuel quality If you are experiencing starting, rough idle or hesitation driveability problems, try a different brand of unleaded gasoline. If the problems persist, see your authorized dealer. Do not add aftermarket fuel additive products to your fuel tank. It should not be necessary to add any aftermarket products to your fuel tank if you continue to use high quality fuel of the recommended octane rating.
Page 299 Maintenance and Specifications Refilling with a portable fuel container With the Easy Fuel™ “no cap” fuel system, use the following directions when filling from a portable fuel container: WARNING: Do not insert the nozzle of portable fuel containers or aftermarket funnels into the Easy Fuel™ system. This could damage the fuel system and its seal, and may cause fuel to run onto the ground instead of filling the tank, which could result in serious personal injury.
Page 300 Maintenance and Specifications 4. When done, clean the funnel or properly dispose of it. Extra funnels can be purchased from your authorized dealer if you choose to dispose of the funnel. Do not use aftermarket funnels; they will not work with the Easy Fuel™ system and can damage it. The included funnel has been specially designed to work safely with your vehicle.
Page 301 Maintenance and Specifications • Use the same side of the same pump and have the vehicle facing the same direction each time you fill up. • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. Calculating fuel economy 1.
Page 302 Maintenance and Specifications • Slow down gradually. • Driving at reasonable speeds (traveling at 55 mph [88 km/h] uses 15% less fuel than traveling at 65 mph [105 km/h]). • Revving the engine before turning it off may reduce fuel economy. •...
Page 303 Maintenance and Specifications • Transmissions give their best fuel economy when operated in the top cruise gear and with steady pressure on the gas pedal. • Close windows for high speed driving. EPA fuel economy estimates Every new vehicle should have a sticker on the window called the Monroney Label which contains EPA fuel economy estimates.
Page 304 Maintenance and Specifications WARNING: Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 305 Maintenance and Specifications If the service engine soon indicator remains on, have your vehicle serviced at the first available opportunity. Although some malfunctions detected by the OBD-II may not have symptoms that are apparent, continued driving with the service engine soon indicator on can result in increased emissions, lower fuel economy, reduced engine and transmission smoothness, and lead to more costly repairs.
Page 306 Maintenance and Specifications BRAKE/CLUTCH FLUID Brake and clutch systems are supplied from the same reservoir. The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Fluid levels between the MIN and MAX lines are within the normal operating range;...
Page 307 Maintenance and Specifications 6. Install the dipstick making sure it is fully seated in the filler tube. 7. Remove the dipstick and inspect the fluid level. The fluid should be in the operating range for normal operating temperature. Your vehicle is equipped with one of the following dipsticks. Low fluid level Type A Type B...
Page 308 Maintenance and Specifications Type B DO NOT ADD ADD (CHECK HOT) The transmission fluid should be in the zone, identified by the arrows in the above figures, if at normal operating temperature 185°F-200°F (85°C-93°C). High fluid level Type A Type B DO NOT ADD ADD (CHECK HOT) Fluid levels above the zone, identified by the arrows in the above figures,...
Page 309 Maintenance and Specifications Type A Type B DO NOT ADD ADD (CHECK HOT) If an overfill occurs, excess fluid should be removed by an authorized dealer. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. Do not use supplemental transmission fluid additives, treatments or cleaning agents.
Page 310: Air Filter(S)
Maintenance and Specifications See the Tires, Wheels and Loading chapter for more information on recreational flat towing. Checking and adding manual transmission fluid (if equipped) 1. Park the vehicle on a level surface. 2. Engage the parking brake fully – put in first gear.
Page 311 Maintenance and Specifications 1. Release the clamps that secure the air filter housing cover. • 2.5L I4 engine • 3.0L V6 engine 2. Pull the air filter housing cover away. 3. Remove the air filter element from the air filter housing. 4.
Page 312 Maintenance and Specifications...
Page 313 Maintenance and Specifications...
Page 314: Engine Data
Maintenance and Specifications ENGINE SPECIFICATIONS Engine 2.5L I4 engine 3.0L V6 engine Cubic inches Required fuel 87 octane 87 octane or E85 Firing order 1-3-4-2 1-4-2-5-3-6 Ignition system Coil on plug Coil on plug Spark plug gap 0.049–0.053 inch 0.045–0.049 inch (1.25–1.35mm) (1.15–1.25mm) Compression ratio...
Page 315 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
Page 316 6. Model year 7. Assembly plant 8. Production sequence number TRANSMISSION CODE DESIGNATIONS You can find a transmission code on MFD. BY FORD MOTOR CO. IN U.S.A. FOR MAZDA MOTOR CORPORATION the Safety Compliance Certification DATE: XX/XX GVWR:XXXXXLB/ XXXXXKG Label . The following table tells you...
Page 317: Accessories
Accessories CELL PHONES Use of cell phones and other devices by driver: WARNING: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver’s hands.
Page 318: Index
Index refill capacities ......312 ABS (see Brakes) .....194 Accessory delay ......57 Battery ........284 Air cleaner filter ....310, 312 acid, treating emergencies ..284 jumping a disabled battery ..240 Air conditioning maintenance-free ....284 manual heating and air servicing ........284 conditioning system ....36 Belt-Minder ......110 Airbag supplemental restraint...
Page 319 Index Cleaning your vehicle engine oil .........280 engine compartment ....263 Driving under special instrument panel ....265 conditions ....207, 213, 216 interior ........266 sand .........214 Mazda car care products ..267 snow and ice ......217 plastic parts ......264 through water ....215, 219 washing ........262 waxing ........262 wheels ........263...
Page 320 Index Fluid capacities ......312 Headlamps ........40 aiming ........43 Fog lamps ........41 bulb specifications ....46 Four-Wheel Drive vehicles daytime running lights .....42 driving off road .......212 flash to pass ......42 preparing to drive your vehicle ........202 high beam .........41 replacing bulbs ......47 Fuel ..........292 calculating fuel economy ..300 turning on and off ....40...
Page 321 Index fold away ........59 heated ........59 side view mirrors (power) ..58 Lamps bulb replacement Moon roof ........63 specifications chart ....46 cargo lamps .......42 daytime running light ....42 fog lamps ........41 Octane rating ......297 headlamps .........40 Oil (see Engine oil) ....280 headlamps, flash to pass ..42 Overdrive ........205 instrument panel, dimming ..42...
Page 322 Index Relays ........221 heated ........93 Remote entry system ...80–81 SecuriLock passive anti-theft illuminated entry ....83–84 system ..........84 locking/unlocking doors ..81–82 Servicing your vehicle ....273 opening the trunk .....82 Setting the clock ......19 panic alarm .......82 replacement/additional Side air curtain ......127 transmitters .......83 Side-curtain airbags system replacing the batteries .....82...
Page 323 Index changing ......231, 233 Turn signal ........44 checking the pressure ....156 inflating ........153 label .........166 Universal garage door opener ..65 replacing ........157 rotating ........160 safety practices .......159 sidewall information ....162 Vehicle Identification Number snow tires and chains ....172 (VIN) ..........315 spare tire ......229, 231 Vehicle loading ......172 terminology ......153...

Mazda 2010 Tribute Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Table of Contents

Related Manuals for Mazda 2010 Tribute

Summary of Contents for Mazda 2010 Tribute

Table of Contents
