Summary of Contents for Turin Networks CMG Router
- Page 1 CMG Router UICK TART UIDE Part Number: 002-0142-0230 Product Release: 2.91 November 2008...
- Page 2 Turin Networks Inc. Adit and the Turin Networks logo are registered trademarks of Turin Networks Inc. All other brand or product names are trademarks or registration trademarks of their respective companies or organizations.
-
Page 3: In This Guide
UICK TART UIDE In this Guide Installation Basic Setup Basic VoIP Setup Fax and Modem Setup PPP Internet Connection and Public IP Address Routing Frame Relay Internet Connection and Public IP Address Routing Back-to-Back with PPP Back-to-Back with Multi-Link PPP Back-to-Back with Frame Relay... -
Page 4: Installation
Unit can be on or off CMG Router card will work in any slot Slide card into slot until fully seated CMG Router has completed its boot cycle when CRD light is solid The following setups are all executed with CLI NOTE: Configuration can be done with the following CLI commands or with the Router Menu-Driven Software. -
Page 5: Basic Voip Setup
This example is with an Adit 600 with the following cards installed: Controller Card (4.0 or higher) CMG Router Card, 1.0 or higher (example - slot 6) 3 FXS Cards, 1.03 or higher (example - slots 1, 2 and 3). Cards are configured for Loop Start POTS lines. - Page 6 Connect CMG voice ports to FXS ports connect 6:1:1:1-8 1:1-8 Connect CMG voice ports to FXS ports connect 6:1:1:9-16 2:1-8 Connect CMG voice ports to FXS ports connect 6:1:1:17-24 3:1-8 Disable verification prompts set verification off CMG Router - Release 2.91...
- Page 7 Set the address value to be used for the origin set 6 voip sdpaddress 11.168.1.1 and connection lines in the SDP. (May be required depending on how the LAN and WAN are configured.) Reset the CMG card, to apply all configurations reset CMG Router - Release 2.91...
-
Page 8: Fax And Modem Setup
To configure the fax and modem bypass, the following is required. Adit 600, release 8.0 CMG Router, release 2.3 with G.729 feature enabled (software keyed) CMG Router User Interface to configure, CLI configuration not available until Adit 600 9.0 The following will configure the Fax and Modem 1. - Page 9 Quick Start Guide Fax and Modem Setup 2. Select Configuration: <Profile Directory> from the Main Menu, and select NTER Main Menu 3. Select Router CARD <Setup -> and select [E NTER Profile Directory Window CMG Router - Release 2.91...
- Page 10 Quick Start Guide Fax and Modem Setup 4. Select VOIP Configure -> and select [E NTER CMG Router - Release 2.91...
- Page 11 Quick Start Guide Fax and Modem Setup 5. Tab to Voice Algorithm Settings - > and select [E NTER CMG Router - Release 2.91...
- Page 12 6. Verify that the RTP Payload type for nse events is set to a value that other gateways are using. For most applications this is 100, which is the default setting. Select [E ] to exit this window, select <YES> and [E ] to save NTER any changes. CMG Router - Release 2.91...
- Page 13 Quick Start Guide Fax and Modem Setup 7. Select Voice Channels Configure -> and select [Enter]. CMG Router - Release 2.91...
- Page 14 Note: there is a limit of six simultaneous T.38 sessions. <T38reserved> - this line will always be able to use T.38 relay. Card Maximum # of Channels configured for T.38 Reserved 6 Channels CMG-02 12 Channels CMG Router - Release 2.91...
- Page 15 In the status field, the following can be displayed, regarding Fax and Modem settings: Display Setting Channel is set to T.38 Data Channel is set to Modem Bypass Active Channel is set for a Voice call CMG Router - Release 2.91...
-
Page 16: Ppp Internet Connection And Public Ip Address Routing
1 "wan1" static ip network interface 0.0.0.0 0.0.0.0 Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.91... -
Page 17: Frame Relay Internet Connection And Public Ip Address Routing
Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Set the DLCI number set 1 "wan1" dlci 101 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.91... -
Page 18: Back-To-Back With Ppp
1 "wan1" static ip network interface 2.2.2.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.91... -
Page 19: Denver Router In Slot 1
1 "wan1" static ip network interface 1.1.1.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.91... -
Page 20: Back-To-Back With Multi-Link Ppp
2.2.2.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk multilink mapped to trunk multilink group 1 group 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.91... - Page 21 1.1.1.0 255.255.255.0 1 Set the WAN interface named "wan1" to be set 1 "wan1" trunk multilink mapped to trunk multilink group 1 group 1 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.91...
-
Page 22: Back-To-Back With Frame Relay
Set the WAN interface named "wan1" to be set 1 "wan1" trunk 1 mapped to trunk 1 Set the DLCI number set 1 "wan1" dlci 101 Reboot the router, to enable all configurations set reset 1 CMG Router - Release 2.91... -
Page 23: Denver Router In Slot 3
Set the WAN interface named "wan1" to be set 3 "wan1" trunk 1 mapped to trunk 1 Set the DLCI number set 3 "wan1" dlci 101 Reboot the router, to enable all configurations set reset 3 CMG Router - Release 2.91... - Page 24 Quick Start Guide Back-to-Back with Frame Relay CMG Router - Release 2.91...
