Workabout WA3113-G2 Instruction Sheet

To change the fuse:
1 Unscrew the end cap of the Cigarette
Lighter Adaptor:
The end cap and metal contact pin come loose:
Note: The end cap and contact pin are loose and
may become separated.
A metal ferrule on the main body
of the Adaptor may also come loose.
Ensure that these parts are reassembled and in position
before reassembling the Adaptor.
2
Remove the old fuse:
3
Insert the new fuse:
Replace the fuse with a
4.6 mm x 16 mm, 2A, 250V slow-blow fuse.
4
Screw the end cap and contact pin back on:
SAVE THESE INSTRUCTIONS! They contain important
safety information for the WORKABOUT PRO Cigarette
Lighter Adaptor.
*8100128*
8100128
ISO 9001 Certified
Rev. B
Quality Management System
Cigarette Lighter Adaptor
Model WA3113-G2
Instruction Sheet
April 3, 2007 PN: 8100128.B
