Summary of Contents for Midwest MTC-6000
- Page 1 Master Time Clock MTC-6000 Users Manual Midwest Time Control Phone (972)987-4408 Toll Free (888)713-0373 FAX (877)720-9291 www.midwest-time.com sales@midwest-time.com...
-
Page 2: Table Of Contents
SPECIFICATIONS OPTIONAL EQUIPMENT Copyright 2002 by Midwest Time Control, Incorporated. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means without the prior written permission of Midwest Time Control, Incorporated. -
Page 3: General Description
Automatic daylight savings time changes. (May be turned off) Automatic updating of Impulse secondary clocks after a power failure. The MTC-6000 records the time of power failure and the current time. When power is restored, correction pulses are sent to the clocks. -
Page 4: Front Panel Controls
FRONT PANEL CONTROLS The ENTER button is used to enter selected data into the memory. This button is active in the program mode. The CANCEL button is used in the review mode to cancel programmed times and dates that are no longer needed. It is also used to exit the program mode and return the clock to normal operation. -
Page 5: Programing
Daylight Savings Time ON or OFF (Default is ON) 12/24 Display (Default is 12 Hour format) Synch-Wired Clock Type (Default is Midwest Time Control Clocks) Impulse Clock Type (Default is 59 minute, no 12 hour correction) BAUD Rate (Default is 9600 BAUD) SECURITY ACCESS CODE A Security Access Code must be entered before a time set, a program change, addition or review. -
Page 6: Set Current Time & Date
4. SET HOLIDAY SCHEDULE Note: Each Holiday must be programmed with a beginning and ending month and date. Beginning and ending dates can not be the same. STEP PRESS INDICATION COMMENT TIME SET Enter Security Access Code MODE HOLIDAY, BEGIN, MONTH AHEAD/BACK Set month of holiday... -
Page 7: Review & Cancel
Circuit 2 is to turn on a light at 7:45 AM Monday and off at 5:15 PM Monday. TIME SET Enter security access code MODE CIRCUIT CIRCUIT 2 MO = Monday AHEAD/BACK Set time to 7:45 AM ENTER Display will blank momentarily MODE CIRCUIT CIRCUIT 2... - Page 8 REVIEW OUTPUT CIRCUIT PROGRAMING TIME SET Enter security access code MODE DURATION REVIEW REVIEW Any programmed duration will CIRCUIT CIRCUIT 1, 2, 3, 4, 5, or 6 be displayed. REVIEW Review off MODE REVIEW REVIEW CIRCUIT CIRCUIT 1, 2, 3, 4, 5, or 6 Programmed ON times will be displayed SU, MO, TU, WE,...
-
Page 9: Bulk Memory Erase
7. BULK MEMORY ERASE STEP PRESS INDICATION COMMENT TIME SET Enter security access code MODE ERASE ENTER The display will show :88 for approx. 5 seconds. The mode will revert to Time Set with the current time and day displayed. All user programmed events will be erased except the current time, day and date. -
Page 10: Equipment Warning
SECONDARY CLOCK CONTROL The MTC-6000 Master Time Clock controls and synchronizes a wide range of secondary clocks. It will control one variety of Minute Impulse Clocks and one variety of Synchronous Clocks simultaneously. The Time display is used to select the clock types. The Minutes side of the display is used to select the Synchronous-wired clock type and the Hours side of the display is used to select the Impulse clock type. -
Page 11: Minute Impulse Secondary Clocks
Impulse Clock Codes CODE CLOCK TYPE CORRECTION ASC-3 or ASC-4 59th Minute 2 Wire reverse polarity Midwest Time or 3 wire ASC-6 59th Minute 2 Wire reverse polarity Midwest Time 12-hour correction @ 5:00 58th Minute Special No Rapid correction Pulses or Polarity Reversal... -
Page 12: Maintenance
MAINTENANCE There are a limited number of field maintenance items in the MTC-6000. Fuses - Located on the PCB under the insulating cover. The ratings are listed on the back cover. Midwest Time Control Part No. 530001-02 Impulse Relays Note: The life of the Impulse Relays will be determined by the number of Impulse Clocks connected. -
Page 13: Specifications
SPECIFICATIONS Power requirements 115 VAC, 60 HZ, 15 Watts Max. Program Capacity 2691 Events Holidays 10 Holidays (Holidays may be multiple days) Operating Temp. 0 to 60 Deg. C Storage Temp. -30 to 75 Deg. C Humidity 95% non-condensing Weight 12 Lbs. - Page 14 NOTES:...
- Page 15 WARRANTY Midwest Time Control warrants the MTC-6000 Master Clock to be free of defects in materials and workmanship for a period of one year from the date of delivery to the purchaser. This period may be extended to one year from the date of...
