HiFiDiy CDM12 Assembly Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

HiFiDIY.NET

CDM12 CD-Player

Assembly Manual

Table of Contents

Need help?

Do you have a question about the CDM12 and is the answer not in the manual?

Questions and answers

Summary of Contents for HiFiDiy CDM12

Page 1 HiFiDIY.NET CDM12 CD-Player Assembly Manual...
Page 2 2009 Jochen Hammer All photographs are property of Hifidiy.net...
Page 3 CDM12 CD-Player Kit...
Page 5: Table Of Contents
Content 1. Kit Overview.....6 2. Remote Control....8 3. Display-Board....17 4. LED -Board......22 5. DAC-Board......25 6. Main-Board.....27 7.
Page 6: Kit Overview
3-8mm Aluminium Chassis Philips VAM102 Laser Pickup High-Precision 3PPM TXCO...
Page 7 Servo-Board pre-build and tested Mainboard with Power- Supply and DAC-Board TI PCM1798 DAC Burr-Brown AD604 OPAMP WIMA & Nichicon Capacitors 50 Watt R-Core Transformer...
Page 8: Remote Control
Remote Control...
Page 9 Install resistors R1=10R, R2=5.1K...
Page 10 Install touch switches Cut leads allowing to install IC and Crystal...
Page 11 Install IC, Crystal and capacitor...
Page 12 Install Transistor and IR Led...
Page 13 Battery Board assembly...
Page 14 Install keys in chassis Install PCBs to chassis...
Page 15 Connect Battery PCB to Remote Control PCB Test: Measure DC voltage at IR Led and press a key.
Page 16 Isolate battery connector...
Page 17: Display-Board
Display Board Install Display IC note the marking on the PCB –...
Page 18 Install Resistors, IC socket and small components Install Capacitors, Transistors and Connectors...
Page 19 Note polarity...
Page 22: Led Board
LED Board...
Page 25: Dac-Board
DAC Board Install DAC and resistors Install Capacitors and IC sockets...
Page 27: Main-Board
Main Board...
Page 28 Install SMD devices and Resistors Install Capacitors, Transistors and IC socket...
Page 29 Install Rectifiers Assembly Power Transistors...
Page 33 Install Connector for DAC module...
Page 39: Panel Assembly
Panel assembly...
Page 40 Install keys and 4 pcs 8mm HEX Standoffs for Display Board Install Display board...
Page 41 Install 2 pcs 10mm HEX Standoffs for Power Switch...
Page 43: Laser Module Assembly
Laser Module assembly Laser Pickup, Laser Control Board, Laser Pickup Panel, 4pcs 20mm HEX Standoff, 4pcs 3mm Φ x 6mm Screws, 4 pcs 2mm Φ Screws Install 4pcs 20mm HEX Standoff to the Laser pickup panel...
Page 44 Install Laser Pickup to the Laser Pickup Panel with 4 2mm Φ Screws...
Page 45 Solder Laser Pickup Wire Connect Laser Pickup Wire to the Control Board...
Page 47 Connect another wire to the Control Board...
Page 48 Install Control Board to the Laser Pickup Panel Install LED Board...
Page 51: Chassis Assembly
Chassis assembly Install Panel to the side covers (2 pcs Panel support, 4 pcs 3mm Φ x 10mm Screws)
Page 52 Install rubber feet to bottom cover Install ICE power socket to the rear panel Put side panel, front panel, rear panel and bottom cover together (front panel 3mm Φ x 12mm Screws, all other 3mm Φ x 10mm Screws)
Page 54 Install Transformer...
Page 55 Use two 12V connect to PCB two 9V...
Page 59 Install Laser Pickup Module...
Page 61 Connect wire from Display Board to Laser Pickup Module...
Page 62 Connect Wire from Laser Pickup Module to Mail Board...
Page 63 Wire DAC and Analog outputs...
Page 65: Top Cover Assembly
To Cover assembly 2pcs (Φ2mm X 8mm screws, 4 pcs Φ3mm X 3mm screws, 8pcs Φ3mm X 6mm screws, 7pcs Φ3mm X 10mm, Top cover switch, 2 pcs Top slide cover assembly piece and Top cover assembly piece) Install Top slide cover assembly piece to Top slide cover (Use 4pcs Φ3mm X 3mm screws)
Page 66 Install Top slide cover to Top Cover...
Page 67 Install Top cover switch...
Page 68 Connect Top cover switch cable and install Top cover...
