U S E R M A N U A L
Series 1 - Maritime Multi Display Models
JH 15T15 MMD-xxx-Axxx - 15.0 inch Maritime Multi Display
JH 15T17 MMD-xxx-Axxx - 15.0 inch Maritime Multi Display
JH 19T12 MMD-xxx-Axxx - 19.0 inch Maritime Multi Display
JH 19T14 MMD-xxx-Axxx - 19.0 inch Maritime Multi Display
JH 20T17 MMD-xxx-Axxx - 20.1 inch Maritime Multi Display
JH 23T12 MMD-xxx-Axxx - 23.1 inch Maritime Multi Display
JH 27T11 MMD-xxx-Axxx - 27.0 inch Maritime Multi Display Widescreen
Please visit www.hatteland-display.com for the latest electronic version of this manual.
Hatteland Display AS, Åmsosen, N-5578 Nedre Vats, Norway
Tel: (+47) 5276 3700 - info@hatteland-display.com - www.hatteland-display.com
User Manual MMD Series 1
Updated: 28 May 2009
Doc Id: INB10036-1 (Rev 9)
Created: 363
Approved: 6542
Slim
User Manual

Advertisement

Table of Contents
loading

Summary of Contents for Hatterland Display JH 15T15 MMD-xxx-Axxx

  • Page 1 U S E R M A N U A L Series 1 - Maritime Multi Display Models JH 15T15 MMD-xxx-Axxx - 15.0 inch Maritime Multi Display JH 15T17 MMD-xxx-Axxx - 15.0 inch Maritime Multi Display JH 19T12 MMD-xxx-Axxx - 19.0 inch Maritime Multi Display JH 19T14 MMD-xxx-Axxx - 19.0 inch Maritime Multi Display...
  • Page 2 Copyright © 2009 Hatteland Display AS Aamsosen, N-5578 Nedre Vats, Norway Information in this manual is copyrighted to the respective owners. All rights are reserved by Hatteland Display AS. This information may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form without the prior written consent of Hatteland Display AS.

  • Page 3: Table Of Contents

    Contents Contents ..................3 Contents of package ..................6 General .................... 7 About Hatteland Display ................8 Contact Information ..................8 About this manual ..................8 Basic Construction ..................9 Touch screen products ................10 Touch screen Technology & Label markings ........ 11 Product Labeling (examples) ..............12 Labels and Locations ..............12 Typenumber Structure ..............12 Warranty Label ................12...
  • Page 4 Specifications - JH 23T12 MMD-xxx-Axxx ..........55 Specifications - JH 27T11 MMD-xxx-Axxx ..........56 Technical Drawings ..............57 Technical Drawings - JH 15T15 MMD-xxx-Axxx ........58 Technical Drawings - JH 15T17 MMD-xxx-Axxx ........59 Technical Drawings - JH 19T12 MMD-xxx-Axxx ........60 Technical Drawings - JH 19T14 MMD-xxx-Axxx ........61 Technical Drawings - JH 20T17 MMD-xxx-Axxx ........62...
  • Page 5 Contents Appendixes ................... 85 Pin Assignments - Common Connectors ..........86 Pin Assignments - Multifunction Cable Outputs ........87 Basic Trouble-shooting ................88 Declaration of Conformity ................89 Return Of Goods Information ..............90 Terms .......................91 Pixel Defect Policy ...................93 Notes ......................94 Revision History ..................95 INB100036-1 (Rev 9) IND100130-25...

  • Page 6: Contents Of Package

    Contents of package This product is shipped with: Item Description Illustration 1 pcs of Standard DVI Signal Cable. DVI-D 24P Male to DVI-D 24P Male - Length 2.0m 1 pcs of Standard VGA Signal Cable. DSUB 15P Male to DSUB 15P Male - Length 2.0m 1 pcs of power cable European Type F “Schuko”...

  • Page 7: General

    General INB100036-1 (Rev 9)

  • Page 8: About Hatteland Display

    Hatteland Display AS About Hatteland Display Hatteland Display is the leading technology provider of maritime display and computer products. We deliver high quality, unique and customized solutions to the international maritime market. The company represents innovation and quality to the system integrators world wide. Effective quality assurance and investment in sophisticated in-house manufacturing methods and facilities enable us to deliver type approved and Mil tested high quality products.

  • Page 9: Basic Construction

    Basic Construction Basic Construction - Series 1 Touch Screen (option) Sun Visor (option) Centerbox Water Cover (option) Mounting Bracket (option) Mechanics Glass Casing Front Frame Bonding Electronics / PCB’s Rotary Bracket (option) User Controls Logo label (option) Example with mounting bracket Example with sun visor, mounting bracket and rotary bracket General INB100036-1 (Rev 9)

  • Page 10: Touch Screen Products

    Touch screen products Introduction to products with touch screen Both Resistive and Capacitive touch screen solutions are used for our products. Please review specifications found in this manual or our website (www.hatteland-display.com) to find your exact type number and then determine if it uses Resistive or Capacitive. Capacitive Touch screen The glass overlay has a coating that stores the charge deposited over its surface electrically.

  • Page 11: Touch Screen Technology & Label Markings

    Touch screen products Touch screen Technology & Label markings Information about the factory mounted touch screen and what driver to use, are indicated on the dedicated label on your actual product. The information and location of the label can vary depending on product, this page only decribes the concept. (This label is attached on products produced after September 2006) TOUCH SCREEN This product is equipped with a Resistive Touch Screen:...

  • Page 12: Product Labeling (Examples)

    Product Labeling (examples) Labels and Locations Warranty Label Quality Control Label Product Information Manufacture: Product: Product type: Jakob Hatteland Display 19 Inch JH 19T01MMD-A1-831 NORWAY Serial Number 100W 115VAC/50-60Hz 230VAC/50-60Hz Series 1 MMD Displays - Typenumber Overview Product Description IND100780-1 - Rev 07 - 15 Apr 2009 - Created Manufacturer/Country Power Rating In this document we shall explain the typenumber structure for standard HATTELAND®...

  • Page 13: Front Logo Label

    Product Labels (Example) Front Logo Label The Hatteland Display MMD front frame design offers an area for customized logo label. These labels can be ordered and customized with your own logo delivered from us The measurements are as follows. WxH = 181.66 x 44.16mm / 7.15” x 1.74”. R4.10 - 4 places in each corner. Depth of area is 0.5mm. General INB100036-1 (Rev 9) IND100077-76...
  • Page 14 This page left intentionally blank INB100036-1 (Rev 9)

  • Page 15: Installation

    Installation INB100036-1 (Rev 9)

  • Page 16: Installation And Mounting

    General Installation Recommendations Installation and mounting 1. Most of our products are intended for various methods of installation or mounting (panel mounting, bracket mounting, ceiling/wall mounting etc.); for details, please see the relevant mechanical drawings. 2. Adequate ventilation is a necessary prerequisite for the life of the product. The air inlet and outlet openings must definitely be kept clear;...

  • Page 17: General Installation Recommendations

    General Installation Recommendations - In the area of the wheel house, the distance of each electronics unit from the magnetic standard compass or the magnetic steering compass must not be less than the permitted magnetic protection distance. This distance is measured from the centre of the magnetic system of the compass to the nearest point on the corresponding unit concerned.

  • Page 18: Ergonomics

    General Installation Recommendations Ergonomics 1. Adjust the unit height so that the top of the screen is at or below eye level. Your eyes should look slightly downwards when viewing the middle of the screen. 2. Adjust screen inclination to remain gaze angle to the centre of the screen approximately perpendicular to the line of gaze.

  • Page 19: Cables

    General Installation Recommendations Cables Use only high quality shielded signal cables and the provided HATTELAND® Multifunction Cable. Cable Entries & Connectors (Marked area) - Illustration only Bottom View Back View Maximum Cable Length Any cable should generally be kept as short as possible to provide a high quality input/output. The maximum signal cable length will depend on the signal resolution and frequency, but also on the quality of the signal output from the computer/radar.

  • Page 20: Hatteland® Multifunction Cables

    General Installation Recommendations HATTELAND® Multifunction Cables This custom HATTELAND® Multifunction Cable with its 160 pins offers a wide range of additional signal types to be used togther with the display units. Please refer to the Contents of Package in this manual to determine which cable and connector functionality you received.

  • Page 21: Physical Connections - Mmd Based Models

    Physical Connections - MMD Based Models Connection area of display (illustration) USB I/O DVI-I IN Multifunction Conn. AC Power Ouput RGB OUT DC Power Input AC Power Input RGB IN Cable Tension To reduce tension of the cables you connect, secure them with a cable tie to the base mounted clamp or to the chassis hinges.
  • Page 22 Physical Connections - MMD Based Models DVI-I IN: Connect your DVI cable to the DVI-I 29P Connector (female). The DVI-I connector can function as regular RGB IN by using a DVI-I > RGB/VGA adapter. Secure the DVI cable to the hex spacers provided on the unit and make sure you do not bend any of the pins inside the connector.
  • Page 23 Physical Connections - MMD Based Models Note: Other HATTELAND® Multifunction Cables may include other connections based on a customized solution. HATTELAND® MULTIFUNCTION CONNECTOR : Mount the 160 PIN cable connector (male) to the 160 PIN connector (female) on the back of the unit as indicated above.
  • Page 24 This page left intentionally blank INB100036-1 (Rev 9)

  • Page 25: Operation

    Operation INB100036-1 (Rev 9)

  • Page 26: User Controls

    User Controls USER CONTROLS OVERVIEW The units are available in two different factory user control configurations as illustrated below. Speaker/Buzzer Potmeter Keypad #1: Potmeter & buzzer (introduced Q4 2008) including keypad controls with its Status LED Ring. Brightness for the unit is adjusted by using the potmeter. The tactile keypad control provide access to the configuration menu and hotkey functionality.
  • Page 27 User Controls KEYPAD FUNCTIONALITY Up (+) button Power/Menu button Right/Hotkey button Push Buttons Left/Hotkey button +HOTKEY function Status LED Ring Down (-) button MENU function as: Power On/Off & On Screen Display (OSD) menu access. LEFT (◄) function as: Hotkey, exit the current function and navigate to the previous OSD menu. RIGHT (►) function as: Hotkey, enter sub-menu &...

  • Page 28: Status Led Overview

    Status LED Overview Status LED Overview The unit features a multi purpose indicator LED status ring which through different patterns and realtime activity gives back the status of the signal detected, power on/off, calibration, menu activity and more. The LEDs are multicolored which either illuminate green or red, based on the activity. OFF (No power connected) OFF (Standby, power detected) ON (Signal Search)

  • Page 29: Osd Menu Overview

    OSD Menu Overview OSD Menu Quick Start To understand the workflow of the OSD menu, follow these steps for a quick start. The table shows the various OSD overlays you might encounter while navigating, adjusting parameters or when text messages are displayed.

  • Page 30: Osd Functions Map

    OSD Menu Overview OSD Functions Map The OSD menu consists of main function groups with sub menu groups. On the following pages a complete map of the available functions is shown. The following section should be viewed in color. Please note that the red selection bar is not indicated in any of the following illustrations.
  • Page 31 OSD Menu Overview Main Group #1 - Picture In this group (with its sub groups) the user can adjust parameters that directly impact the picture visually for all incoming signal sources. Some of these Sub Groups have more options, please review this map to quickly determine the location of your desired function/option.
  • Page 32 OSD Menu Overview Main Group #2 - Setup In this group (with its sub groups) the user can adjust parameters that directly impact settings for the video controller software, OSD settings and gain access to settings that are physically accessible for the user. None of these settings will impact on the picture visually for the incoming signal sources.
  • Page 33 OSD Menu Overview Main Group #3 - Source In this group (with its sub groups) the user can change the signal input source and setup the Picture-In-Picture views or Picture-By- Picture views which both take advantage of the Maritime Multi Display functionality. Some of these Sub Groups have more options, please review this map to quickly determine the location of your desired function/option.

  • Page 34: Osd Menu Functions

    OSD Menu Functions OSD Menu Functions The following section covers all possible settings that the user can (in a certain mode) encounter or needs to adjust. The structure of these commands are identified as paths. Please review the “OSD Menu Overview Map”...
  • Page 35 OSD Menu Functions Display / Picture / Color This function only apply for analog Composite/S-VHS video signals when set as Main Source. Increase/decrease the overall video color saturation/color amount. Can be used if the incoming signal from older equipment or bad cables appear to have a lack of strong colors. Note that this function can also make noisy color signals appear crisper/clearer if adjusted to grayscales.
  • Page 36 OSD Menu Functions Display / Picture / PIP-PBP Adjustment / PIP Size To enable this function, please see [ Display / Source / xxx / xxx ] later in this section of the manual. Increase/decrease the Picture-In-Picture and Picture-By-Picture window sizes. These functions will allow any of the signal inputs to be placed as an real time window overlay (or side by side if using PBP) on top of the current Main Source signal enabling the main feature of the Maritime Multi Display functionality.
  • Page 37 OSD Menu Functions Display / Picture / PIP-PBP Adjustment / PIP Picture / Sharpness To enable this function, please see [ Display / Source / xxx / xxx ] later in this section of the manual. Increase/decrease the overall image sharpness. This will not change the sharpness of the Main Source signal behind the window overlay.
  • Page 38 OSD Menu Functions Display / Picture / Advanced Settings / Graphic Scaling / One to One Function only available in “Full” menu mode & when analog DVI/VGA/RGB signal are set as Main Source. Set the image scaling to 1:1. This means that the incoming signal is shown as is (with correct aspect ratio) and without any scaling to fit the display area.
  • Page 39 OSD Menu Functions Display / Picture / Advanced Settings / Horz Position Move the horizontal (left/right) position of the entire display area. This applies to the Main Source signal. Please note that this function can move information in the image outside the visible display area, so use caution when modifying this parameter.
  • Page 40 OSD Menu Functions Display / Picture / Picture Info / Second Source Please note that a valid input signal must be present for this function to work. This function will show the picture information as detected by the display controller such as Physical Port Input Name, Current Signal Resolution, H-Freq.
  • Page 41 OSD Menu Functions Display / Setup / OSD Settings / OSD Vert Position Move the vertical (left/right) position of the OSD Menu overlay. The OSD Menu can only be moved within the max display area available. ● Level adjusts from 0-100 steps. 50 is default. Display / Setup / OSD Settings / Full Menu Function only available through password protection.
  • Page 42 OSD Menu Functions Display / Setup / OSD Settings / OSD Lock Mode / Password Protect - May be set as factory default Function only available in “Full” menu mode. Enables a password protection before getting access to the OSD menu. Required for ECDIS Compliance. ●...
  • Page 43 OSD Menu Functions Display / Setup / User Settings / Communication / RS-232 - May be factory default. Function only available in “Full” menu mode. Configure the built-in HATTELAND® SCOM (Serial Remote Control Interface) to RS-232 protocol which enable software/remote control of a single HATTELAND® unit. The SCOM will enable operators to modify a wide range of parameters available inside the display controller.
  • Page 44 OSD Menu Functions Display / Setup / User Settings / Splash Screen Function only available in “Full” menu mode. Enable/disable the Splash Screen logo upon power on for the unit and while the display controller is initalizing. It will be gone as soon as the signal input appear on screen. This is by factory default shown as manufacturer’s brand logo (HATTELAND®).
  • Page 45 OSD Menu Functions Display / Setup / Direct Access / xxx This function will configure the hot-key functionality. It means that the user can access a function that is normally only accessible by browing through the OSD Menu and locate the function. It is assigned to the MENU button on the physical user controls normally located on the front bezel.
  • Page 46 OSD Menu Functions Display / Setup / Service Menu / Fault Status Function only available in “Full” menu mode. This function will show the last recorded fault message detected by the display controller. This information is stored electronically on the EVX component board. Example: “Video Chip, DVI Chip, NVRAM, DDC” Display / Source / Single / xxx This function will indicate what physical signal inputs is considered to be detectable by the OSD Menu and the display controller.
  • Page 47 OSD Menu Functions Display / Power Off This function will turn off the unit (soft power off) and shut down the display controller and cut internal power to all components except the power module. The LED indicator ring/power leds will all illuminate red. The unit will enter standby mode.
  • Page 48 This page left intentionally blank INB100036-1 (Rev 9)

  • Page 49: Specifications

    Specifications INB100036-1 (Rev 9)

  • Page 50: Specifications - Jh 15T15 Mmd-Xxx-Axxx

    Specifications - JH 15T15 MMD-xxx-Axxx PRODUCT SPECIFICATIONS - JH 15T15 MMD-xxx-Axxx Note: All specifications are subject to change without prior notice! TFT Technology: Physical Considerations: • High Quality SHARP TFT • 412 (W) x 345 (H) x 73 (D) mm / 16.22" (W) x 13.58" (H) x 2.87" (D) •...

  • Page 51: Specifications - Jh 15T17 Mmd-Xxx-Axxx

    Specifications - JH 15T17 MMD-xxx-Axxx PRODUCT SPECIFICATIONS - JH 15T17 MMD-xxx-Axxx Note: All specifications are subject to change without prior notice! Physical Considerations: TFT Technology: • 412 (W) x 345 (H) x 73 (D) mm / 16.22" (W) x 13.58" (H) x 2.87" (D) •...

  • Page 52: Specifications - Jh 19T12 Mmd-Xxx-Axxx

    Specifications - JH 19T12 MMD-xxx-Axxx PRODUCT SPECIFICATIONS - JH 19T12 MMD-xxx-Axxx Note: All specifications are subject to change without prior notice! TFT Technology: Physical Considerations: • High Quality SHARP TFT • 483 (W) x 444 (H) x 82 (D) mm / 19.02" (W) x 17.48" (H) x 3.23" (D) •...

  • Page 53: Specifications - Jh 19T14 Mmd-Xxx-Axxx

    Specifications - JH 19T14 MMD-xxx-Axxx PRODUCT SPECIFICATIONS - JH 19T14 MMD-xxx-Axxx Note: All specifications are subject to change without prior notice! TFT Technology: Physical Considerations: • High Quality SHARP TFT • 483 (W) x 444 (H) x 82 (D) mm / 19.02" (W) x 17.48" (H) x 3.23" (D) •...

  • Page 54: Specifications - Jh 20T17 Mmd-Xxx-Axxx

    Specifications - JH 20T17 MMD-xxx-Axxx PRODUCT SPECIFICATIONS - JH 20T17 MMD-xxx-Axxx Note: All specifications are subject to change without prior notice! TFT Technology: Physical Considerations: • High Quality SHARP TFT • 534 (W) x 481 (H) x 87 (D) mm - 21.02" (W) x 18.93" (H) x 3.42" (D) •...

  • Page 55: Specifications - Jh 23T12 Mmd-Xxx-Axxx

    Specifications - JH 23T12 MMD-xxx-Axxx PRODUCT SPECIFICATIONS - JH 23T12 MMD-xxx-Axxx Note: All specifications are subject to change without prior notice! TFT Technology: Physical Considerations: • High Quality SHARP TFT • 584 (W) x 534 (H) x 85 (D) mm - 22.99" (W) x 21.02" (H) x 3.35" (D) •...

  • Page 56: Specifications - Jh 27T11 Mmd-Xxx-Axxx

    Specifications - JH 27T11 MMD-xxx-Axxx PRODUCT SPECIFICATIONS - JH 27T11 MMD-xxx-Axxx Note: All specifications are subject to change without prior notice! Physical Considerations: TFT Technology: • 660.00 (W) x 481.00 (H) x 101.50 (D) mm • High Quality SAMSUNG TFT •...

  • Page 57: Technical Drawings

    Technical Drawings INB100036-1 (Rev 9)

  • Page 58: Technical Drawings - Jh 15T15 Mmd-Xxx-Axxx

    Technical Drawings - JH 15T15 MMD-xxx-Axxx Technical Drawings - JH 15T15 MMD-xxx-Axxx Keypad only INB100036-1 (Rev 9) IND100132-125...

  • Page 59: Technical Drawings - Jh 15T17 Mmd-Xxx-Axxx

    Technical Drawings - JH 15T17 MMD-xxx-Axxx INB100036-1 (Rev 9) IND100132-145...

  • Page 60: Technical Drawings - Jh 19T12 Mmd-Xxx-Axxx

    Technical Drawings - JH 19T12 MMD-xxx-Axxx Technical Drawings - JH 19T12 MMD-xxx-Axxx Keypad only INB100036-1 (Rev 9) IND100132-126...

  • Page 61: Technical Drawings - Jh 19T14 Mmd-Xxx-Axxx

    Technical Drawings - JH 19T14 MMD-xxx-Axxx Technical Drawings - JH 19T14 MMD-xxx-Axxx INB100036-1 (Rev 9) IND100132-144...

  • Page 62: Technical Drawings - Jh 20T17 Mmd-Xxx-Axxx

    Technical Drawings - JH 20T17 MMD-xxx-Axxx INB100036-1 (Rev 9) IND100132-146...

  • Page 63: Technical Drawings - Jh 23T12 Mmd-Xxx-Axxx

    Technical Drawings - JH 23T12 MMD-xxx-Axxx INB100036-1 (Rev 9) IND100132-127...

  • Page 64: Technical Drawings - Jh 27T11 Mmd-Xxx-Axxx

    Technical Drawings - JH 27T11 MMD-xxx-Axxx INB100036-1 (Rev 9) IND100132-142...

  • Page 65: Technical Drawings - Accessories

    Technical Drawings - Accessories INB100036-1 (Rev 9)

  • Page 66: 15" Sun Visor

    Technical Drawings - Accessories 15” Sun Visor INB100036-1 (Rev 9) IND100132-109...

  • Page 67: 19" Sun Visor

    Technical Drawings - Accessories 19” Sun Visor INB100036-1 (Rev 9) IND100132-67...

  • Page 68: 20" Sun Visor

    Technical Drawings - Accessories 20” Sun Visor INB100036-1 (Rev 9) IND100132-111...

  • Page 69: 23" Sun Visor

    Technical Drawings - Accessories 23” Sun Visor INB100036-1 (Rev 9) IND100132-112...

  • Page 70: 17" > 23" Rotary Bracket

    Technical Drawings - Accessories 17” > 23” Rotary Bracket INB100036-1 (Rev 9) IND100132-46...

  • Page 71: 17" > 20" Bracket

    Technical Drawings - Accessories 17” > 20” Bracket INB100036-1 (Rev 9) IND100132-69...

  • Page 72: 23" Bracket

    Technical Drawings - Accessories 23” Bracket INB100036-1 (Rev 9) IND100132-129...

  • Page 73: 27" Bracket

    Technical Drawings - Accessories 27” Bracket INB100036-1 (Rev 9) IND100132-143...

  • Page 74: 15" Tft To 19" Rack Adapter

    Technical Drawings - Accessories 15” TFT to 19” RACK Adapter INB100036-1 (Rev 9) IND100132-43...

  • Page 75: 15" Tft To 17" Crt Adapter

    Technical Drawings - Accessories 15” TFT to 17” CRT Adapter INB100036-1 (Rev 9) IND100132-137...

  • Page 76: 19" Tft To 21" Crt Adapter

    Technical Drawings - Accessories 19” TFT to 21” CRT Adapter INB100036-1 (Rev 9) IND100132-44...

  • Page 77: Vesa Bracket - 15

    Technical Drawings - Accessories VESA Bracket - 15” INB100036-1 (Rev 9) IND100132-113...

  • Page 78: Vesa Bracket - 19

    Technical Drawings - Accessories VESA Bracket - 19” INB100036-1 (Rev 9) IND100132-45...

  • Page 79: Vesa Bracket - 20

    Technical Drawings - Accessories VESA Bracket - 20” INB100036-1 (Rev 9) IND100132-115...

  • Page 80: Vesa Bracket - 23

    Technical Drawings - Accessories VESA Bracket - 23” INB100036-1 (Rev 9) IND100132-116...

  • Page 81: Water Cover - 15

    Technical Drawings - Accessories Water Cover - 15” INB100036-1 (Rev 9) IND100132-117...

  • Page 82: Water Cover - 19" (Hw01)

    Technical Drawings - Accessories Water Cover - 19” (HW01) INB100036-1 (Rev 9) IND100132-136...

  • Page 83: Water Cover - 20

    Technical Drawings - Accessories Water Cover - 20” INB100036-1 (Rev 9) IND100132-119...

  • Page 84: Water Cover - 23

    Technical Drawings - Accessories Water Cover - 23” INB100036-1 (Rev 9) IND100132-120...

  • Page 85: Appendixes

    Appendixes INB100036-1 (Rev 9)

  • Page 86: Pin Assignments - Common Connectors

    Pin Assignments - Common Connectors Note: Not all connectors may be available on your specific product. This depends on the amount of additional hardware installed from factory, or customized solutions. These pin assignments are for the common connectors used. Connectors are seen from users Point Of View (POV). Pin Assignments - 24P DVI-I 1 2 3 4 5 6 7 8 C1 C2...

  • Page 87: Pin Assignments - Multifunction Cable Outputs

    Pin Assignments - Multifunction Cable Outputs Connectors that are commonly available on the HATTELAND® Multifunction Cable or customized cable. Connectors are seen from users Point Of View (POV). Pin Assignments - 9P Serial COM RS232 4 3 2 1 9 8 7 6 Pin 01 - CTRL(+) Buzzer Control (+) (+12V input for driving the buzzer) Pin 02 - TX Transmit Data...

  • Page 88: Basic Trouble-Shooting

    Basic Trouble-shooting GENERAL ISSUES FOR TFT PANEL BASED PRODUCTS Note: Applies for a range of various products. This is only meant as a general guide. O PICTURE / LED BEHAVIOUR: If there is no light at all in the LED at the FRONT, check power cables. If the LED in front is green then check if the brightness knob is turned to the right (max brightness).

  • Page 89: Declaration Of Conformity

    Declaration of Conformity We, manufacturer Hatteland Display AS Åmsosen, N-5578 Nedre Vats, Norway declare under our sole responsibility that the JH MMD, JH MMC, JH STD, JH MIL, HM NMD HM MIL, HM CMD, HT STD, HD MMD & HT MMC product ranges is in conformity with the following standards in accordance with the EMC Directive.

  • Page 90: Return Of Goods Information

    Return Of Goods Information Return of goods: (Applies not to warranty/normal service/repair of products) Hatteland Display referenced as “manufacturer” in this document. Before returning goods, please contact your system supplier before sending anything directly to manufacturer. When you return products after loan, test, evaulation or products subject for credit, you must ensure that all accessories received from our warehouse is returned.

  • Page 91: Terms

    Terms Terms Of Sale And Delivery 1) APPLICATION The terms of sale and delivery apply for Hatteland Display. 2) PRICE a) The price is per each, if nothing else has been stated, VAT not included. Price is based on the prices from our suppliers, current custom rates, taxes, rate of exchange and international raw material prices.
  • Page 92 Terms 12) CANCELLATION / RETURN Binding sales contract is concluded when we have confirmed customer’s purchase order. Any disagreements in our order confirmation must be reported to seller within 6 days. The agreement can not be altered without our permission, after acceptance from our supplier.

  • Page 93: Pixel Defect Policy

    Pixel Defect Policy PIXEL DEFECT POLICY Dot-defects (Bright or dark spots on the panel) Due to the effect that dot failures are part of the TFT technology such failure occurrence cannot be prevented basically. Even though dot defects usually occur during production process, new defects can appear within the lifespan of a TFT display. Neither the production at LCD-supplier nor the use of a LCD-Monitor after shipment can be influenced by Hatteland Display.

  • Page 94: Notes

    Notes General Notes: - The unit is type approved according to EN60945 (1997), 4.4, equipment category b) protected from the weather. - Use of brightness and push buttons may inhibit visibility of information at night. Appendix INB100036-1 (Rev 9) IND100077-71...

  • Page 95: Revision History

    Revision History Rev. Date Notes 05 Oct 07 First release, preliminary for prototypes and internal reviews. 06 Feb 08 Commercial final release 1 07 Apr 08 Revised contents of package chapter (US power cable and console mounting screws added). Revised company profile and company logos throughout manual. Added illustrations and info for DC models (own dedicated housing connector with screw terminal).
  • Page 96 h attel and-d isp l ay . com...
