Seyeon Technology FlexWATCH 1110L User Manual

Network camera server
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Network Camera Server
User's Manual
User's Guide
TM
FlexWATCH
1110L
(Version. 3.0_Rev0)
Seyeon Technology Co., Ltd
www.flexwatch.com
M4013
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexWATCH 1110L and is the answer not in the manual?

Questions and answers

Summary of Contents for Seyeon Technology FlexWATCH 1110L

  • Page 1 Network Camera Server User’s Manual User’s Guide FlexWATCH 1110L (Version. 3.0_Rev0) Seyeon Technology Co., Ltd www.flexwatch.com M4013 Seyeon Tech Co., Ltd...

  • Page 2: Table Of Contents

    Network Camera Server User’s Manual Table of Contents Overview of FlexWATCH Server ............9 Packing List....................9 What is FlexWATCH ? ................10 Key Function of FlexWATCH .............. 10 Product Specification ................. 11 Basic Network Connection Diagram............12 Application ..................14 Hardware Description ................
  • Page 3 Network Camera Server User’s Manual Simple viewer page guide..............34 FW-Voyager based view and recording ............36 Camera configuration ................36 Camera value string configuration............36 Camera configuration................. 38 Video Motion Detection ..............40 System Configuration ................43 System Information................... 43 Date &...
  • Page 4 Network Camera Server User’s Manual HTTP port configuration..............54 NVCP –Tx Port .................. 54 VDCP Port configuration ..............54 WAN Configuration and Application .............. 55 External Modem connection ..............55 Application with Dial-in/out feature ............55 Dial Out configuration ................ 56 Dial-in Configuration................
  • Page 5 Network Camera Server User’s Manual Automatic Control of Alarm Output device..........72 Advanced Service configuration ............73 Buffering Service ..................73 System and Pre Alarm Buffer memory..........74 Buffer calculator................76 Service Condition ..................78 Condition Setup ................79 Criteria Setup ................... 79 e-mail configuration ..................
  • Page 6 Network Camera Server User’s Manual Description of files system ..............92 Update Procedure................94 Seyeon Tech Co., Ltd...
  • Page 7 Network Camera Server User’s Manual Notice • The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy, Seyeon Tech assumes no liability resulting from errors or omissions in this document, or from the use of the information contained herein.

  • Page 8: Important Information

    Network Camera Server User’s Manual Warning To prevent risk of electric shock, Do not remove system-case. No user serviceable parts inside. Any repair or modification for the product will be allowed to qualified service personal only. Do not expose this appliance to water or moisture. Do not install this product in Hazardous areas where highly combustible or explosive products are stored or used.

  • Page 9: Tm Server

    Network Camera Server User’s Manual Overview of FlexWATCH Server Packing List Please check and make sure following items are included in your package without any missing items. If there are any missing items, please refer to your local distributor. A. FlexWATCH 1110L .…………………………………………………………………….1unit B.

  • Page 10: What Is Flexwatch

    Network Camera Server User’s Manual What is FlexWATCH The FlexWATCH server is the Network camera Server, which transmits digital images captured by Analog CCD camera over the Internet. So users can view real-time live images over the Internet at anytime and anywhere using the standard web browser such as MS Internet Explorer or Netscape Communicator.

  • Page 11: Product Specification

    Network Camera Server User’s Manual Product Specification Hardware · e-mail, FTP, alarm Buffer by event or schedule · 32bit Embedded CPU · IP notification, Alarm Notification to e-mail, CGI · Flash 4Mbytes /SDRAM: 32Mbytes path by event or schedule · Hardware Motion JPEG engine UART Control ·...

  • Page 12: Basic Network Connection Diagram

    Network Video Server User’s Manual Basic Network Connection Diagram FlexWATCH server provides flexible connectivity with any type of networks available around you such as Leased line, Cable modem, xDSL line and PSTN (POT) line. Thus, it can be installed either in LAN or WAN environment as long as there is network available. But its configuration is subject to change depending on its environment.
  • Page 13 Network Camera Server User’s Manual registered in AOIP server which is an IP gateway running by Flexwatch.com or your local Distributor. For more details, please refer to Technical guidebook in the CD manual. 2.3.4 Dial-up to AOIP server Using Dial-up function of FlexWATCH server and AOIP service, you can set the FlexWATCH server to make a call to ISP and get it connected AOIP server.

  • Page 14: Application

    Network Camera Server User’s Manual concerned about call charge, we are recommending using above connection. Application Unlimited application for remote monitoring and surveillance solution can be built up using FlexWATCH server and its supporting peripheral Hardware and software such as FW-5000 or FW-5440 Network video recorder server and FW-Manager DVR software.

  • Page 15: Hardware Description

    Network Camera Server User’s Manual Hardware Description • This chapter contains list of items to be prepared for the installation of FlexWATCH server. • Please carefully read this chapter before the installation. • Please prepare all the necessary items before start installation to prevent any possible malfunction or any other hazard can be happened during the installation.

  • Page 16: Hardware Description

    Network Camera Server User’s Manual Hardware Description 3.2.1 FW-1100 Hardware Description Front Panel View PWR LED Indicate power on/off Always red-light on when turned on LAN LED Blinking only when LAN is connected to the network Green-light on when LAN connection is OK Camera Control To adjust camera quality.
  • Page 17 Network Camera Server User’s Manual ELC(ON/OFF) When set to ‘ON’ mode, the electronic iris switch automatically varies the camera's shutter to mimic auto-iris control, allowing fixed or manual iris lens to be used in a wider range. When this switch is set to ‘ON’ mode, set the FLK switch to ‘OFF’ mode. When a manual iris lens is mounted on camera, set ELC switch to ‘ON’...
  • Page 18 Network Camera Server User’s Manual Notice a. set the ELC switch in the front panel to 'OFF' b Please check the pin number on the surface of auto iris lens connector Pin Number DC Iris Lens CONTROL( - ) CONTROL( + ) DRIVE( + ) DRIVE( - ) Seyeon Tech Co., Ltd...

  • Page 19: Key Words For Network

    Network Camera Server User’s Manual IP assignment Key Words for Network LAN (Local Area Network) : Under the LAN network, any network device in the same LAN network can be accessed by any other network device. But LAN network can not be accessed from the Internet (WAN).
  • Page 20 Network Camera Server User’s Manual assigned to a client station (computer, network equipment, etc.) in a TCP/IP network. Dynamic IP address is typically assigned by a DHCP server, which can be a computer on the network or another piece of hardware, such as router. A dynamic IP address may change every time your computer connects to the network DHCP (Dynamic Host Configuration Protocol) : DHCP is software that automatically assigns IP addresses to client stations logging onto a TCP/IP network.

  • Page 21: Check Points Before Ip Assignment

    AOIP (Always On Internet Protocol) Server: AOIP™ server (Always On IP) is run by Seyeon Technology or its business partner and is a gateway for remote users to access FlexWATCH™ servers which is connected dynamic IP address over DSL,Cable modem and PSTN network over the Internet.
  • Page 22 Network Camera Server User’s Manual ipconfig C:\> Windows 2000/XP IP Configuration Ethernet adapter Local area connection : Connection-specific DNS Suffix . : IP Address... . : 192.168.0.158 Subnet Mask ... : 255.255.255.0 Default Gateway .

  • Page 23: Lan Cable Or Cross-Over Cable

    Network Camera Server User’s Manual 2.1.2 DHCP Enabled PC If your PC is set to use DHCP, you need to check out IP address of your PC using ‘ ipconfig’ command at DOS Prompt window. You need to get IP address from your network administrator to assign it to FlexWATCH server.

  • Page 24: Pc Environment

    Network Camera Server User’s Manual 2.2.2 Cross-over cable If LAN network is not available, you can directly connect FlexWATCH server to your PC through Cross-over cable. In this case, you need to prepare Cross-over cable separately (Note that The LAN cable included in the product package is not Cross-over cable, but normal straight cable) and you need to set your PC IP address as 10.20.30.41 and connect the server with Factory default IP address, 10.20.30.40 through web browser.

  • Page 25: Factory Default

    Network Camera Server User’s Manual Factory Default Please refer to the following factory defaults to change setting up. Factory Default Admin ID root Admin password root IP address 10.20.30.40 Network mask 255.255.255.0 IP Assignment FlexWATCH server can be configured by two different configuration method and following is brief explanation.
  • Page 26 Network Camera Server User’s Manual 2) Run the IP installation Wizard program in your PC. Then following IP Installation Wizard window will show up. Description of Window Menu Description Serial No. (MAC Address) Enter FlexWATCH server Serial No. (Mac of System address) attached at the bottom of the unit and select the LAN port.
  • Page 27 Network Camera Server User’s Manual ‘Go to Home Page’ Button To launch FlexWATCH Web browser and start other configuration through Administration page. ‘Telnet to System’ Button To guide you Telnet mode for Advanced Configuration. Result window Show the result of IP assignment. If failed, try again from the start or use other configuration method 3) Input the Serial No.

  • Page 28: Ip Assignment Through Hyper Terminal Mode

    Network Camera Server User’s Manual you need to set-up a new IP address again. Note If IP address set result is failed, please check whether correct IP/MAC address is entered. And try again with correct IP/MAC address, or please use HyperTerminal method. IP Assignment through Hyper Terminal mode Microsoft Windows provides Terminal emulation program, namely Hyper Terminal.
  • Page 29 Network Camera Server User’s Manual 5) When ‘Port Settings’ window show up, input each values from the table below. Serial Port Settings Value Bits per Second 115200 Data bits Parity None Stop bits Flow control None 6) After setting Hyper Terminal, press Enter key several times and then you can see messages as below.
  • Page 30 Network Camera Server User’s Manual FlexWATCH login: root Password: ----------------------------------------------------------- SYSTEM : FlexWATCH VERSION : 3.0.040130 MODEL : FW-1110 ----------------------------------------------------------- login[504]: root login on `ttyS0' bash# 8) Input ‘netconfig’ command after ‘bash# ’ prompt, and press Enter key. Then you can see following network setup values.
  • Page 31 Network Camera Server User’s Manual Your network configuration was changed. Shutting down interface eth0 [ OK ] Shutting down interface ppp1 [ OK ] Shutting down interface ppp2 [ OK ] Setting network parameters [ OK ] Bringing up interface lo [ OK ] Bringing up interface eth0 eth0: Setting half-duplex based on auto-negotiated partner ability 0000.
  • Page 32 Network Camera Server User’s Manual bash# bash# savecfg Saving a current config to flash memory [ OK ] Updated flash bash# bash# bash# reboot Broadcast message from root (ttyp0) Mon Sep 6 19:28:51 2004... The system is going down for reboot NOW !! bash# Seyeon Tech Co., Ltd...

  • Page 33: Live View & Camera Configuration

    Network Camera Server User’s Manual Live view & Camera Configuration Once IP assignment is finished, you can view live view through standard web browser such as MS Internet Explorer or Netscape Navigator. There are two different type of viewing option provided by FlexWATCH server.

  • Page 34: Java Applet Based Live View

    Network Camera Server User’s Manual When the Client pc is not connected to Internet, you need to manually install ActiveX components in your viewing PC. Insert the product CD in your PC Select “FlexWATCH Simple Viewer control” program Application idea ActiveX based SDK is provided for software developers so that application program developers can easily utilize digital video from FlexWATCH server for his own video...
  • Page 35 Network Camera Server User’s Manual Module Selection : Not user selectable option field. Frame rate : You can adjust display frame rate by control Frame rate option Display size : X1 for Real size, x2 for double size and Full screen mode is supported. Snap shot : You can make a snapshot of video while viewing the live video.

  • Page 36: Fw-Voyager Based View And Recording

    Network Camera Server User’s Manual FW-Voyager based view and recording FW-Voyager is web based DVR software for personal video recording. Using this free software, user can easily install the software and do video recording at any time. Note that FW-Voyager is works on MS Internet explorer of Window OS. Click “Voyager”...
  • Page 37 Network Camera Server User’s Manual Default Video Format : To manually change video format. Note that server auto sense the video format Video with UART sensor data: Serial input data can be sent along with video so that application program can read serial input data Video with channel name: To send video along with channel name...

  • Page 38: Camera Configuration

    Network Camera Server User’s Manual 3.1.1 Image encryption Image encryption is security feature to prevent unwanted image hacking when anonymous user accesses the system. Once it is enabled, user must enter encryption code to view live video. 1) Simple set up encryption code 2) Enter encryption key code to view live.
  • Page 39 Network Camera Server User’s Manual User defined camera name will be appeared on the camera name column of video. Up to 20 different English characters can be used. ( Notice : If you are using 2-Byte Unicode Character, number of character is limited to 10 ) Image Size : 4 different size of video can be set up.

  • Page 40: Video Motion Detection

    Network Camera Server User’s Manual Video Source: color and Gray mode option Image Quality: 5 quality levels - highest, high, normal, low, lowest Note Please note that if you increase image size and quality, actual JPEG file size will be increased and this may affect actual transmission frame rate.
  • Page 41 Network Camera Server User’s Manual 3.3.2 How to save Motion triggered image in the NVR solution Recording in the FW-5440/5000 Simply check “Motion Detection” option in the recording condition menu in the FW- 5440 or FW-5000 when motion detection option is enabled in the FlexWATCH server.
  • Page 42 Network Camera Server User’s Manual Recording in the FW-Manager To record motion triggered image in the FW-Manager (NDVR Software) client program, you should not use Software motion detection function in the FW-Manager. Simply configure motion detection for the selected camera in the FlexWATCH server Set up Motion based recording condition in the FW-Manager (Do not set...

  • Page 43: System Configuration

    Network Camera Server User’s Manual System Configuration System configuration is to set up basic functions which help you properly run and manage the system. It is highly recommended to set up the configuration before any other configurations. Following functions are provided in the System configuration mode. System name and Info System Administration account set up System access level setting...

  • Page 44: Date & Time Using Ntp Server

    Network Camera Server User’s Manual 2) Set the correct time and click “Apply” button Date & Time using NTP server If multiple servers are installed over the network and controlled by client program and synchronized time info is required, use NTP(Network Time Protocol) option. 1) Go to [NTP setup] menu in the Network configuration section of Admin Mode 2) Type in NTP server name or use default NTP timeserver, ntp.ewha.net, if you do not know any NTP timeserver available in your area.

  • Page 45: Full Access

    Network Camera Server User’s Manual C. Different control authority for Video, Audio, and relay output device control Full Access To allow system access by anyone who know the IP address. PTZ, Audio and Relay output device can be controlled by anyone. Thus, if security for video is important, it is highly recommended to user limited access mode below Limited Access and User registration This is to limit server access to the authorized user only.

  • Page 46: Frame Rate Control

    Network Camera Server User’s Manual Full Access : If full access is selected, any body can access the server and control the video. No Access : This is to temporally restrict camera access by specific user without delete user account to temporally block access to the camera.

  • Page 47: Tx Module Registration(Nvcp)

    Network Camera Server User’s Manual 1) Go to [Access Control] option in the system configuration menu in the Admin page. 2) Set up Maximum frame rate. Following table could be an example. File size is variable depending on the complexity of the scene. Thus, it hard to get exact and fixed number of file size.
  • Page 48 Network Camera Server User’s Manual NDVR server as well Video proxy function is supported by NDVR server such as FW-5440 and FW-5000 server. By registering FlexWATCH video server into NDVR server, live video can be recorded in the NDVR server and live view can be accessed through NDVR server web page which means user does not need to separately run web browser to view respective cameras from FlexWATCH video servers.
  • Page 49 Network Camera Server User’s Manual 3) Select TX Module. By configuring TX module, you can program the server to communicate with different NVR servers. Up to16 different NDVR servers can simultaneously work with FlexWATCH server. 4) Select Passive or Active Mode depends on the network situation with NDVR server. 5) Once Active mode is selected, type in IP address of NDVR server.
  • Page 50 Network Camera Server User’s Manual Following is recommended setting guide for TX and RX module for FlexWATCH server and NDVR depending on the network environment Video server NDVR Server Mode Network environment Mode Network environment Passive mode WAN Network(Global Static) Active Mode LAN network (Private) Passive mode...

  • Page 51: Network Configuration

    Network Camera Server User’s Manual Network Configuration Network configuration mode provides interface for the server to be connected to broadband network or PSTN line. In addition to basic network, application port such as HTTP, NVCP, Voice port configuration and IP filtering options are provided. Network configuration You can change IP address of server through LAN configuration mode.
  • Page 52 Network Camera Server User’s Manual Once DHCP is enabled, there is not other setting to be changed in the network works configuration except DNS info, if required. 2.1.1.1 IP notification by E-mail service You can receive IP address of the server through e-mail from the server, when the server is connected to DHCP server.

  • Page 53: Pppoe Configuration

    Network Camera Server User’s Manual 2.1.1.1 Server access through AOIP server Once Server is registered in the AOIP server and DHCP is enabled, you can access the server through AOIP server. IP address of server can be found from AOIP server as well. In this case you do not need to configure e-mail address setting to get IP address from the server.

  • Page 54: Network Port Configuration

    Network Camera Server User’s Manual Note Once PPPoE is enabled, LAN network setting will be disabled. Network port configuration HTTP port, NVCP and VDCP ports are application port through which video and audio data can be transmitted over the TCP/IP network. HTTP port configuration When you need to change Default HTTP Port (#80) to other port, you can change HTTP port.

  • Page 55: Wan Configuration And Application

    Network Camera Server User’s Manual router. Note that when Voice Kit is connected to Internet, respective UDP port of the router must be opened. WAN Configuration and Application Server is designed to make a call to ISP or can receive a call from outside so that server can establish Internet connect to send FTP, e-mail or send video &...

  • Page 56: Dial Out Configuration

    Network Camera Server User’s Manual Server can establish the Internet connection through PSTN line and send FTP or e-mail when the alarm condition is triggered by any event. Following can be done through Dial-out function • Pre/post alarm image sending through e-mail •...
  • Page 57 Network Camera Server User’s Manual PPP Client : This means that FlexWATCH server act as client and call out to ISP.\ PPP Server : This means that FlexWATCH server acts as a Server and receives a call from remote user. Tel#, User ID and User password : ISP phone number and user account for Internet connection to ISP.

  • Page 58: Dial-In Configuration

    Network Camera Server User’s Manual This mode is not for general users. Thus, if you need to connect special modem device, please contact your vendor or manufacturer for more information, sales@flexwatch.com Dial-in Configuration Dial-in is to allow client PC to call into the server and get live video through PSTN line. Overall configuration is very similar to that of Dial-out configuration.

  • Page 59: Service Path

    Network Camera Server User’s Manual Modem connection only Local IP address : System default IP address (192.168.2.1) resides in the FlexWATCH server for modem connection only. So when you connect the FlexWATCH server from remote PC using dial-up networking and physical connection is made, you need to run your web browser and enter this system default IP address(192.168.2.1) to view live video.

  • Page 60: Aoip Setup

    Network Camera Server User’s Manual LAN : This is default path the send any data to outside. Modem : when PSTN or other medium than LAN is used to send data to outside. This service port must be checked when any data is to be sent through PSTN or other medium than LAN which is connected to COM port.

  • Page 61: Aoip Configuration

    Network Camera Server User’s Manual FlexWATCH™ server. Note AOIP is proprietary data service run by FlexWATCH™ or its business partners around the world. Thus, depending on the country AOIP service can run by your local vendor or master distributor or in some case, you need to user AOIP server run by manufacturer. More detailed information about how to use can be acquired by contact your local distributor or sales@flexwatch.com...

  • Page 62: Network Status

    Network Camera Server User’s Manual not enable this option. Network Status You can see all the network status configured in the system through “Network status” option. Please Select “Network Status” menu in the Network configuration mode of Admin Window. Seyeon Tech Co., Ltd...

  • Page 63: External Device Connection & Configuration

    Network Camera Server User’s Manual External Device connection & configuration External device such as Serial input device, Serial output (UART) device, PTZ (pan/Tilt/Zoom) device, Audio kit and Alarm input and output device can be connected to the system and controlled over the TCP/IP network. Serial Ports Configuration Guide This chapter will guide you how to install and configure Serial-interface devices.

  • Page 64: Installation & Configuration Of External Device

    Network Camera Server User’s Manual 1.1.2 Ports Connection for using two different devices. Two different devices can simultaneously connected to the server and work together. Please refer to following port connection guide and use the right port to get the external devices worked with FlexWATCH server.

  • Page 65: Serial Input Device

    Network Camera Server User’s Manual 3) Select ‘Console’ at COM mode, and Click ‘Apply’ button 4) System reboot will be recommended, then click ‘Reboot’ button. Serial Input device Serial input device such as Car Speed sensor, BOG sensor, POS (Point of sales), ATM device which communicate with external device through RS-232 port can be integrated with the system.

  • Page 66: Serial Output Device

    Network Camera Server User’s Manual This function is not for general use. Thus, if you need more close information about this, please contact your local distributor or manufacturer for further information, sales@flexwatch.com. Serial output device The system supports to relay third party command to target device through Serial output device control mode.

  • Page 67: Voice Kit Connection And Configuration

    Network Camera Server User’s Manual G. After setting up the parameters in the each filed, click ‘Apply’ button. Note that if you are using X10 or Z256 device protocol, you do not need to set up parameters, but simple select X10 “Enable” option. 2.3.2 X 10 device &...
  • Page 68 Network Camera Server User’s Manual video stream but also full duplex two real time Voice through web browser or proprietary application program. Voice broadcasting for voice connection by multiple users is also supported by the system as well. Note Once Multi user connection is enabled, only root Account user can enjoy full duplex audio and rest of users can listen only.

  • Page 69: Alarm Input Device Connection

    Network Camera Server User’s Manual port configuration mode to change VDCP port if required. Application Idea By changing VDCP port, you can install multiple Voice kit and FlexWATCH server behind the single broadband network. Single/Multi User: Once Multiple users are selected, only Admin account user can enjoy full duplex Audio and User account user can listen only.

  • Page 70: Alarm Output(Relay Output) Device Connection

    Network Camera Server User’s Manual 1) Simply connect the alarm sensor to the server. 2) Go to “Alarm input/out” menu to name the alarm input name. 3) Once configuration is done, alarm based services can be done such as e-mail, FTP, Sensor notification Application Idea Followings are list of services which is related to alarm input device connection.
  • Page 71 Network Camera Server User’s Manual Alarm output device can manually be controlled through simple viewer page or admin page. 4.2.1 Alarm output device through web browser Alarm output device control panel can separately run in the simple viewer page, if control authority for Alarm output device is given to user.

  • Page 72: Automatic Control Of Alarm Output Device

    Network Camera Server User’s Manual Automatic Control of Alarm Output device Alarm Output device can automatically be controlled by setting up control condition properly. This is to automatically to activate alarm output or any relay output device connected to the server. Up to three different conditions per alarm output port with schedule, Sensor or its combination is provided so as to set up powerful and various working condition for each alarm output device.

  • Page 73: Advanced Service Configuration

    Network Camera Server User’s Manual Advanced Service configuration Advanced service configuration is intended to provide more sophisticated functions which are required by sophisticated users. Thus, if you are not familiar with or not good at advanced features, we recommend you to read this guide carefully and consult with your local vendor to get more close information about these features.

  • Page 74: System And Pre Alarm Buffer Memory

    Network Camera Server User’s Manual Steps to use Buffering service Following is a step to configure and use Buffering services A. System memory allocation : This is to allocated limited system memory for e-mail & ftp and Alarm buffering service B.
  • Page 75 Network Camera Server User’s Manual Total Pre-alarm Buffer size : This is to assign memory space for the services that Pre Alarm video buffer is required such as e-mail and FTP (Edge service) and Alarm buffering service. Once it is configured, pre alarm buffer size for respective camera can be done within this assigned memory.

  • Page 76: Buffer Calculator

    Network Camera Server User’s Manual Pre-alarm Buffer size : This is to assign pre-alarm image buffer for each camera. Once this is configured, the maximum number of pre alarm for e-mail, ftp or Alarm buffering service (Pre alarm only) can be done with this buffer size, if there is enough memory space for respective services. Note that there must be enough memory space left for e-mail, ftp and Alarm Buffering service (Pre alarm only), since respective service (e-mail, ftp or Alarm buffering service) consumes separate memory in addition to pre alarm buffer size configured to make a real...
  • Page 77 Network Camera Server User’s Manual Total buffer size 1000 kb Total Pre-alarm buffer size (40%) Alarm buffering service size (60%) • Total Buffer size is variable depending on the memory used by the system * Above is only for example Total number of Pre Alarm+ Post Alarm for FTP per channel <...

  • Page 78: Service Condition

    Network Camera Server User’s Manual 4) Pre configure pre/post alarm buffer for each service. This previous window can be open till you manually disclose the Window. Thus, you can refer to this table when you configure e-mail, ftp or Alarm buffering service configuration. Service Condition Sophisticated advanced services can be done by lots of serviced conditions provides by the system.

  • Page 79: Condition Setup

    Network Camera Server User’s Manual Condition Setup This is to define basic condition to activate any option selected. Select right condition from the option provided. Always : To active any selected option regardless condition. If you select this condition Schedule and Event condition window become inactive.
  • Page 80 Network Camera Server User’s Manual the year. 2.2.2 Event Alarm senor, Server reboot and Serial device activation or combined activation can be recognized as an event . Event number can be mapped as a Sensor port and camera number. DI Open State : This means that sensor is triggered and become open status from Normal close status.

  • Page 81: E-Mail Configuration

    Network Camera Server User’s Manual sensor. Please check out sensor type connected to FlexWATCH server e-mail configuration Schedule, event or schedule and event driven e-mail sending is supported by the server so that when there is any pre-configured event is happened, e-mail notice will be sent to any e-mail account.
  • Page 82 Network Camera Server User’s Manual get this info, consult with your Internet service provider or check the e-mail setting in your e-mail program such as outlook or Eudora. Authentication Login: Now these days most of ISP is try to authenticate sender e-mail address due to security and spam mail issue.

  • Page 83: E-Mail Condition Set Up

    Network Camera Server User’s Manual Less than 10 frames can be assigned as post-alarm images. Post alarm has nothing to do with Pre alarm buffer size. Note that the sum of pre and post alarm can not exceed 10 frames. Value Format : Value strings can be sent together with e-mails.
  • Page 84 Network Camera Server User’s Manual slightly different. 4.1.1 Directory option for Buffered FTP Buffered FTP means that only pre/post alarm buffered image will be sent to FTP server when the ftp is triggered by the event. FTP function of FlexWATCH server has two different level of directory and file name option and following are details.
  • Page 85 Network Camera Server User’s Manual automatically be concatenated after prefix( Base File name ). Directory name : Multiple directories can be created in the Base directory so that ftp image can be stored in a classified directory. Once you select Directory name filed and click “Make Directory” button, multiple sub- directories will automatically be created in the Base directory according to selected option.

  • Page 86: Ftp Service Configuration

    Network Camera Server User’s Manual the FTP server. Overwrite: This is to refresh old image with new image in the ftp server. This is normally used when the ftped image should be refreshed every time. FTP service configuration If you get good understanding of Pre/post alarm buffering and FTP directory option, now you can easily configure FTP function of the system.

  • Page 87: Alarm Buffering Service

    Network Camera Server User’s Manual 3) Set up FTP directory and file name option 4) Select the camera and set up FTP condition for each camera. Up to 3 different ftp condition can be set up for each camera. 4.2.2 Periodic FTP service Periodic FTP means that image will continuously be sent to FTP server when there is any event.

  • Page 88: Playback Of Pre/Post Alarm Image

    Network Camera Server User’s Manual 6) Click “Save” button to memorize your new setting in the system. 7) Click the Condition menu and set up alarm buffering service condition. 8) Click “Advance Service” menu in the Admin window and click “Stop and Apply” button to start record alarm triggered image in the system memory.

  • Page 89: Sensor Notification Service

    Network Camera Server User’s Manual Preview Single Images: This is to view image one by one. Preview Multi images: You can view panoramic images of all the saved images at a glance. 2) Click Preview Single Imager or Preview Multi images option to playback. 3) Click “Clear Buffer”...
  • Page 90 Network Camera Server User’s Manual CGI Path : Common Gateway Interface to the Application program User ID /Password : Authentication ID and Password of the application program. 3) Type in CGI Path and User ID & Password to third party application program. 4) Select sensor input number 5) Type CGI Name (User definable) and set up condition to trigger Sensor notification function.

  • Page 91: Utilities

    Network Camera Server User’s Manual Utilities Utilities is to manage and control system properly. Save Configuration, Flash Update, System Reboot and system upgrade options are provided. Save Configuration This is to save all new configuration and settings in the system memory. Once new configuration is saved by “Save Configuration”...

  • Page 92: System Update

    Network Camera Server User’s Manual will lose all of your setting. System Update System update can remotely be done through web page of the system or ftp option with telnet and Hyper Terminal mode. In this user manual only web based system update method is described and ftp based system update method can separately provided.
  • Page 93 Network Camera Server User’s Manual All (kernel, RAM disk, System, Web) Update: To completely update all the system for Kernel, RAM Disk, System and Web all together except PTZ Device Driver or Sensor Device Driver. This option is recommended if there is special notice by manufacturer.
  • Page 94 Network Camera Server User’s Manual software change. Sensor Device Driver : Serial input device driver can separately be uploaded into the system so that independent Serial input device can work with FlexWATCH Server. Update Procedure Step by step procedure is provided by the system which means, each file will separately uploaded one by one.
  • Page 95 Network Camera Server User’s Manual 4) Once update is successfully done following result will come up. 5) If you want to update RAM Disk, System and web page, please click “Next” button follow the web guide to update more files. 6) If all of file update is finished “System Reboot”...
  • Page 96 Network Camera Server User’s Manual Warranty Product Network Video Server Model FlexWATCH 1110L 1 year Seyeon Tech Ltd. Warranty Limited +82-2-3017-0866 www.flexwatch.com Seyeon Tech Co., Ltd. TEL : +82-2-3017-0855 FAX : +82-2-3017-0843 http://www.seyeon.co.kr http://www.flexwatch.com A/S Center: Tel : +82-2-3017-0855 Fax: +82-2-3017-0843 Seyeon Tech Co., Ltd...
