1-2 Product Specifications
CPU Support for Intel
Š
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Š
Chipset Intel
Š
Memory 8 x DDR4 DIMM sockets supporting up to 64 GB of system memory
Š
4 channel memory architecture
Š
Support for DDR4 2133/1866/1600/1333 MHz memory modules
Š
Support for non-ECC memory modules
Š
Support for Extreme Memory Profile (XMP) memory modules
Š
Support for RDIMM 1Rx8 memory modules (operate in non-ECC mode)
Š
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Creative
Š
Support for Sound Blaster Recon3Di
Š
TI Burr Brown
Š
High Definition Audio
Š
2/5.1-channel
Š
Support for S/PDIF Out
Š
LAN 1 x Qualcomm
Š
1 x Intel
Š
Wireless Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
Š
Communication Bluetooth 4.0, 3.0+HS, 2.1+EDR
Š
Module Support for 11ac wireless standard and up to 867 Mbps data rate
Š
Expansion Slots Š 2 x PCI Express x16 slots, running at x16 (PCIE_1, PCIE_2)
2 x PCI Express x16 slots, running at x8 (PCIE_3, PCIE_4)
Š
(All PCI Express x16 slots conform to PCI Express 3.0 standard.)
3 x PCI Express x1 slots
Š
(The PCI Express x1 slots conform to PCI Express 2.0 standard.)
1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
Š
Multi-Graphics Support for 4-Way/3-Way/2-Way AMD CrossFire
Š
Technology
Storage Interface Š Chipset:
-
-
-
Hardware Installation
Core i7 processors in the LGA2011-3 package
® ™
X99 Express Chipset
®
* D ue to a Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
Sound Core 3D chip
®
OPA2134 operational amplifier
®
Atheros Killer E2201 chip (10/100/1000 Mbit) (LAN1)
®
GbE LAN phy (10/100/1000 Mbit) (LAN2)
®
* Actual data rate may vary depending on environment and equipment.
* F or optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIE_1 slot; if you are installing two PCI Express graphics
cards, it is recommended that you install them in the PCIE_1 and PCIE_2 slots.
* T he PCIE_4 slot shares bandwidth with the PCIE_1 slot. When the PCIE_4 slot is
populated, the PCIE_1 slot will operate at up to x8 mode.
* W hen an i7-5820K CPU is installed, the PCIE_2 slot operates at up to x8 mode and
the PCIE_3 operates at up to x4 mode.
* T he 4-Way NVIDIA SLI configuration is not supported when an i7-5820K CPU is
® ™
installed. To set up a 3-Way SLI configuration, refer to "1-6 Setting up AMD CrossFire
NVIDIA SLI Configuration."
® ™
1 x M.2 Socket 3 connector (M2_10G)
1 x SATA Express connector
6 x SATA 6Gb/s connectors (SATA3 0~5)
- 10 -
/NVIDIA SLI technology
™ ® ™
™
/
