EoSens GE Camera Manual
Camera-Firmware:
Camera ID:
Functions described in this manual may not be available with firmware versions prior than above mentioned.
Information presented in this publication has been carefully checked for reliability; however, no responsibility is
assumed for inaccuracies. The information contained in this document is subject to change without notice.
Copyright © 2010 Mikrotron GmbH
Mikrotron GmbH
Landshuter Str. 20-22
D-85716 Unterschleissheim
Germany
®
E
S
GE C
O
ENS
• H
S
CMOS C
IGH
PEED
Rev. 1.14
B2.02-V1.15-F1.09
MC1364-65
Tel.: +49 89 726342 00
Fax: +49 89 726342 99
info@mikrotron.de
www.mikrotron.de
M
AMERA
ANUAL
• H
S
AMERA
IGH
ENSITIVITY
•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EOSENS GE CAMERA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mikrotron EOSENS GE CAMERA

Summary of Contents for Mikrotron EOSENS GE CAMERA

  • Page 1 • H CMOS C • H • PEED AMERA ENSITIVITY EoSens GE Camera Manual Rev. 1.14 Camera-Firmware: B2.02-V1.15-F1.09 Camera ID: MC1364-65 Functions described in this manual may not be available with firmware versions prior than above mentioned. Information presented in this publication has been carefully checked for reliability; however, no responsibility is assumed for inaccuracies.

  • Page 2: Table Of Contents

    EoSens GE Camera Manual Table of contents 1 General......................4 1.1 For customers in the U.S.A..........................4 1.2 For customers in Canada..........................4 1.3 Pour utilisateurs au Canada.......................... 4 1.4 Life Support Applications..........................4 1.5 Declaration of conformity ..........................5 1.6 Warranty Note............................... 6 1.7 Remarks, Warnings............................
  • Page 3 EoSens GE Camera Manual 6.6.5 Read firmware version, command: FirmwareVersion................23 7 MC Control Tool....................24 8 Firmware......................25 8.1 Microcontroller firmware..........................25 8.2 FPGA firmware............................25 8.3 Firmware update procedure......................... 26 9 Technical Data....................27 9.1 Overview..............................27 9.2 Sensor defect specifications........................28 9.3 Spectral response............................

  • Page 4: General

    Mik- rotron customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Mikrotron for any damages resulting from such improper use or sale.

  • Page 5: Declaration Of Conformity

    General EoSens GE Camera Manual 1.5 Declaration of conformity Mikrotron GmbH Manufacturer: Landshuter Str. 20-22 Address: 85716 Unterschleissheim Germany Camera MC1364, MC1365 Product: The dedicated products conform to the requirements of the Council Directives 2004/108/EG for the approximation of the laws of the Member States relating to electromagnetic consist- ency.

  • Page 6: Warranty Note

    General EoSens GE Camera Manual 1.6 Warranty Note Do not open the body of the camera. The warranty becomes void if the body is opened. 1.7 Remarks, Warnings This document contains important remarks and warnings. See the corresponding symbols: ...

  • Page 7: Introduction

    Introduction EoSens GE Camera Manual 2 Introduction The CMOS high speed camera EoSens is a high resolution camera with 1280x1024 pixel. Benefits of CMOS technology are high speed, random access to pixels with free programmab- ility and low power. The camera uses industry-standard C-Mount or F-Mount lenses. The sensor diagonal is 22.9 mm with square pixels measuring 14 µm.

  • Page 8: Differences Between The Camera Types

    Introduction EoSens GE Camera Manual 2.3 Differences between the camera types The CMOS cameras are available in different versions depending on the supported features monochrome or color. Features Data Color C/F-Mount max. frame rate Image pre- width lens @ 1280 x 1024...

  • Page 9: Hardware

    Hardware EoSens GE Camera Manual 3 Hardware 3.1 GigE Vision ® interface ® GigE Vision is designed for digital cameras in machine vision applications. This interface can transfer data at a rate of 110 Mbytes/sec. ® The GigE Vision chipset and software is designed and implemented by Pleora Tech. Inc. the leading supplier of GigE Vision technology.

  • Page 10: Getting Started

    Getting started EoSens GE Camera Manual 4 Getting started Before starting to operate the camera, make sure that the following equipment is available:  Camera EoSens  C-Mount/F-Mount Lens  Mikrotron Support CD  Image processing system, e.g.: PC and Software Additional items: ...

  • Page 11: Initial Setup

    Initial setup EoSens GE Camera Manual 5 Initial setup The EoSens is delivered with initial parameters and therefore does not need to be configured via the serial link. 5.1 Serial number and firmware revision Serial number and firmware revision is provided in EoSens non volatile memory and can be read via software.

  • Page 12: User Profiles

    Initial setup EoSens GE Camera Manual 5.5 User profiles The user can store up to four User Profiles in non volatile memory. All load or write commands exchange data between the Camera Profile and one of the four user profiles.

  • Page 13: Configuration

    Configuration EoSens GE Camera Manual 6 Configuration The content of all EoSens registers is called a profile. There is space in non volatile memory for 9 profiles: The PowerUpProfile, 4 user profiles and 4 factory profiles. Any change of a specific register through the serial interface is immediately processed and written to the volatile part of the memory and gets lost when power goes down.

  • Page 14: Genicam® Command Interface

    Configuration EoSens GE Camera Manual 6.1 GenICam ® command interface ® GenICam commands are used to change camera parameters. 6.1.1 Command overview ® Beside all mandatory commands like ‘DeviceModelName’ the following GenICam features are implemented: GenICam ® feature Function Chapter...

  • Page 15: Image Size And Position

    Configuration EoSens GE Camera Manual 6.2 Image size and position 6.2.1 Setting the ROI, commands: OffsetX, OffsetY, Width and Height Image size and position within the sensor is defined by four parameters: Command Description Value OffsetX Address of first pixel (x-start) 0…4F8...

  • Page 16: Invert Readout In X- And Or Y-Direction, Commands: Reversex, Reversey

    Configuration EoSens GE Camera Manual 6.2.3 Invert readout in x- and or y-direction, commands: ReverseX, ReverseY Commands: ReverseX, ReverseY Description: This feature allows to flip the frame in x- and or y-direction. Remark: This mode can not be combined with Decimation mode or MultiROI mode.

  • Page 17: Framerate And Shutter

    Configuration EoSens GE Camera Manual 6.3 Framerate and shutter 6.3.1 Setting the framerate, command: AcquisitionFrameRateAbs Command: AcquisitionFrameRateAbs Range: <xxxxxx> = 1...3b49 Description: With this command the framerate (unit Hz) in free run mode can be set. Note: The actual range depends on the current ROI.

  • Page 18: Non Destructive Readout For Multi Exposure, Command: Nondestructivereadout

    Configuration EoSens GE Camera Manual 6.3.4 Non destructive readout for multi exposure, command: NonDestructiveReadout Command: NonDestructiveReadout Range: <x> = 1...7 Description: This command controls the non destructive readout mode. If desired, pixel exposure can be accumulated up to 7 times, resulting in alternative image exposures.

  • Page 19: Type Of Exposure, Command: Exposuremode

    Configuration EoSens GE Camera Manual 6.4.1 Type of exposure, command: ExposureMode The EoSens can expose the images in free run mode or with an external signal. The external modes are used to synchronize EoSens cameras to each other or to an external event.

  • Page 20: Image Quality

    Configuration EoSens GE Camera Manual 6.5 Image quality 6.5.1 Digital gain, command: DigitalGain Command: DigitalGain Range : <xxxx> = 0 or 0400 ... 1000 Description: The digital gain can be set from 0400 which is equivalent to gain 1x to 1000 which is equivalent to gain 4x.

  • Page 21: Fpn Correction, Command: Fpnenable

    Configuration EoSens GE Camera Manual 6.5.3 FPN correction, command: FPNEnable Command: FPNEnable Description: With this command the column FPN (fixed pattern noise) correction can be activated or deactivated. At the beginning of each frame, before visible lines are read out, a fixed voltage is applied at the columns. These values are read out like real data and are stored inside the camera.

  • Page 22: Other

    Configuration EoSens GE Camera Manual 6.6 Other 6.6.1 In frame counter, command: InFrameCount Command: InFrameCount Description: If a sequence of frames is to be recorded for long time at a high frame rate, it can be useful to mark the images for later identification or check for completeness.

  • Page 23: Setting Threshold Mode, Command: Graythreshold (Optional Feature)

    Configuration EoSens GE Camera Manual 6.6.3 Setting threshold mode, command: GrayThreshold (optional feature) Command: GrayThresholdEnable and: GrayThresholdAbs Description: With this command the threshold mode can be activated. All pixels above the threshold level in the image will be output as white while all pixels below will be output as black.

  • Page 24: Mc Control Tool

    MC Control Tool EoSens GE Camera Manual 7 MC Control Tool The MC Control Tool must be installed on a Windows PC. (Win9x, WinNT, Win2K, WinXP) by means of the setup software. See also www.mikrotron.de to download the latest version.

  • Page 25: Firmware

    EEPROM. Upon power up or a command the FPGA is loaded with this con- figuration. Configuration data can be downloaded via the serial interface. Mikrotron may provide configuration files (*.ibf) on request. After download of configuration data, this data is permanently stored in EEPROM and the FPGA is configured with the new data.

  • Page 26: Firmware Update Procedure

    Firmware EoSens GE Camera Manual 8.3 Firmware update procedure Before you disable the loaded firmware please ensure that you have an adequate application firmware version to load (e.g. EoSens….A101.ibf for application firmware, EoSens…F101.ibf for FPGA firmware).  After this command the camera may not be able to deliver any images, load/send/store register or profile data.

  • Page 27: Technical Data

    Technical Data EoSens GE Camera Manual 9 Technical Data 9.1 Overview MC1364 Monochrome MC1365 Bayer Filter Number of pixel 1280 x 1024 Pixel size 14 x 14 µm Active area 17.92 (H) x 14.34 (V) mm Fill factor Sensitivity 25 V/lux.s @ 550nm Spectral response 400..720nm monochrome...

  • Page 28: Sensor Defect Specifications

    Technical Data EoSens GE Camera Manual 9.2 Sensor defect specifications Parameter Description Limit Amount of bright pixels (response higher then half BrightPix scale) in a dark image. Dark image must first be FPN < 10 corrected. DarkMeanOutput Average value of a dark image (10-bit scale).

  • Page 29: Spectral Response

    Technical Data EoSens GE Camera Manual 9.3 Spectral response The charts below show the sensitivity of the monochrome and the color sensor with a bayer pattern filter on the sensor glass lid. The color camera is by default equipped with a UV/IR cut filter with a transmittance of 370-670nm resulting in a sensitivity shown in the second chart.

  • Page 30: Bayer Pattern Filter

    Technical Data EoSens GE Camera Manual 9.4 Bayer pattern filter The EoSens color camera has a bayer pattern filter on the sensor glass lid. To get the color in - formation the imaging software must decode the information. The pattern beginning from first...

  • Page 31: Connector Pinning

    Technical Data EoSens GE Camera Manual 9.5 Connector pinning 9.5.1 Gigabit Ethernet Connector Connector type: RJ45 female 9.5.2 Circular power connector, 12-pin Signal Voltage level 8 - 24V DC STROBE_GND STROBE_OUT LVTTL 3.3V TRIG_GND TRIG_IN (LV)TTL 3.3 - 5V 8 - 24V DC...

  • Page 32: Timing Diagrams

    Technical Data EoSens GE Camera Manual 9.6 Timing diagrams 9.6.1 Timed (Free run with electronic shutter) In this mode framerate and exposure time is controlled by the camera. At the strobe output (in power connector) there is a high signal while the camera exposes a picture.

  • Page 33: Mechanical Dimensions

    Technical Data EoSens GE Camera Manual 9.7 Mechanical dimensions...

  • Page 34: Quick Start Guide For Gigevision

    Quick start guide for GigE Vision® EoSens GE Camera Manual ® 10 Quick start guide for GigE Vision This guide describes the basic steps to set up a connection to a GigE Vision camera using the EBus driver. Other driver configurations are possible but for high performance it is recommen- ded to use the EBus Optimal Driver if possible.

  • Page 35: Configure The Network Card

    Quick start guide for GigE Vision® EoSens GE Camera Manual 10.3 Configure the network card Go to the network property page and set the IP and the subnet mask for the NIC. • Note: If you have more than one network card in your computer make sure to configure...

  • Page 36: Connecting Using The Gev Player

    Quick start guide for GigE Vision® EoSens GE Camera Manual 10.4 Connecting using the GEV Player Start the GEV player • (Start->Programs->Pleora Technologies Inc-> eBUS-PureGEV Package ->GEV Player) and click select. Your IP Engine should now appear in the list (This could take a while ..).

  • Page 37: Camera Configuration

    Quick start guide for GigE Vision® EoSens GE Camera Manual 10.5 Camera configuration Click GEV Device control to configure the camera. •...
