- Page 1 INSTALLATION 3940 IP i-Dome COHU, INC. ELECTRONICS DIVISION Installation Manual Figure 1. Model 394x-590x Ethernet iDome 3940 IP iDome CAMERA/POSITIONER SYSTEM June 28, 2012 Technical Manual 6X-1070D www.cohu-cameras.com www.cohu-cameras.com/content/contactus info@cohu.com 6X-1070D...
- Page 2 WinMPC.Net from the Cohu website. This software both controls the camera and views its video. For the day-to-day operating software download the SDK (Software Development Kit) from the Cohu website. A programmer will then use this SDK to write the operating software for the camera.
-
Page 3: General Description
Two software packages related to operating the point. There are 64 preset positions with a preset ac- camera are available for download from the cohu- curacy of 0.1 degree. When responding to standard cameras.com website. A third package is available pan-preset or manual control, the iDome can move to update the camera firmware. - Page 4 O3.00 1.2.1 WinMPC.Net Installation and Setup Software For installation and setup of a camera use Cohu WinMPC.Net software. This software is not intended for the day-to-day operation of the camera. It is in- tended to control a single camera during installation 10.42...
-
Page 5: Pendant Mount
INSTALLATION 3940 IP i-Dome 1. A DOS upload/burn program Table 1. Basic Mounting Arrangements 2. Firmware for a 8051 microcontroller MOUNT POLE iDOME CONFIG. BRACKET 3. Firmware for a DM642 digital media pro- cessor. • Pendant • • Wall 1.2.4 Functional Description •... -
Page 6: Installation
INSTALLATION 3940 IP iDome The actual installation should be performed by a under rain, snow, and other typical harsh weather qualified installation professional familiar with all the conditions. local code requirements and good practices for a A sealing type MS connector is used on the proper installation. -
Page 7: Equipment Supplied
INSTALLATION 3940 IP iDome Table 2. Required Cable Characteristics Section 5 of this manual covers receiving inspection, packing and return require- ments for sending the iDome back to the CONDUCTOR TYPICAL CHARACTERISTICS FUNCTION factory, and static discharge protections. Static should mainly be of concern when 2 pairs twisted, 26 AWG minimum (CAT5e Ethernet working inside a unit. -
Page 8: Cabling Requirements
RECOMMENDED SOURCE 5/16 inch grade 316 stainless steel Commercial stock items hardware Cable assembly Cohu CA-252A or CA-252B for 115 V ac models, or CA-252G for the 24 V ac model Connector Sealing Tape Coax Seal Power source (114 watts) 24 V ac or 115 V ac, depending on camera model Viewer &... - Page 9 INSTALLATION 3940 IP i-Dome Note: If the F.O. Transeciver is wired like a PC NIC card a crossover adapter will be required (or rewire the EQUIPMENT CABINET CA-252B cable for crossover connections at the RJ45 connector. See table 5. FIBER OPTIC...
- Page 10 Ethernet IP iDome Cohu WinMPC.Net fulfills these requirements. Field Setup for Local Communications with Ethernet IP iDome Figure 7. Local Operation Test Setup...
- Page 11 INSTALLATION 3940 IP i-Dome CA252A 115 V ac Figure 8. Type CA-252A Cable (Stripped Power & Ethernet Leads) CA252B 115 V ac Figure 9. Type CA-252B Cable (115 V ac Plug & RJ-45 Ethernet Plug) 6X-1070D...
- Page 12 INSTALLATION 3940 IP iDome CA252B 24 V ac Figure 10. Type CA-252G Cable, 24 V ac (Stripped Power Leads & RJ-45 Ethernet Plug) 2.4.3 Connector Sealing Figure 8 (CA-252A) shows a cable with stripped leads for on-site wiring of 115 V ac power and Eth- Even though the connector used with this cam- ernet as required.
- Page 13 Installation and testing of the camera should be performed with the Cohu WinMPC.NET software. Use a full wrap of this tape on the cable at the This is available at no cost from the Cohu website. beginning. Then continue with a diagonal half over- 6X-1070D...
-
Page 14: Operation
Operating software for the camera can be de- supporting device. Always be sure to imme- veloped using the Cohu Software Development Kit diately reattach this strap after the dome half (SDK). of the assembly is attached. Also snug down the two locking bolts that secures the two halves of the assembly from turning. -
Page 15: Shipping And Handling
Cohu offers a lifetime “pressurization” warranty adapter See table 6. (Refer to Cohu’s Warranty Statement). You may elect to send the unit into Cohu for repressurization of the dry nitrogen or elect to Table 6. Cable Wiring to a PC do so yourself. - Page 16 INSTALLATION 3940 IP iDome Table 7. 24 V ac iDome Connector Functions Table 8. 115 V ac iDome Connector Functions FUNCTION FUNCTION no connection no connection 24 V ac high (camera) no connection 24 V ac high (heaters) no connection Ethernet Tx+ Ethernet Tx+ Ethernet Tx-...
-
Page 17: Static Discharge Protection
INSTALLATION 3940 IP i-Dome humidity below 30 percent requires extraor- dinary procedures not listed here. Please contact the Customer Service Depart- 5. Use antistatic bags to store and transport ment for a Return Authorization (RA) number an exposes chassis, circuit boards, and before sending any shipments to the factory: components. -
Page 18: Installation Checklist
Connecting a PC directly to an IP iDome requires an Ethernet crossover cable or adapter. When using 7.3 MOUNTING EQUIPMENT SUPPLIED one of the Cohu supplied cables that already has a RJ-45 plug, an adapter will have to be used so that Depending on the mounting configuration, sev- another cable can make the connection to the PC. - Page 19 INSTALLATION 3940 IP i-Dome WALL Route system cable through hole in wall into Arm 1.5 NPT for dome Use weather-tight gasket quick disconnect between Arm and wall adapter Figure 13. Wall Mount Arm 4.125 UNLESS OTHERWISE NOTED ALL DIMENSIONS IN INCHES O0.375...
-
Page 20: Wall Mount Installation
INSTALLATION 3940 IP iDome 7.3.3 POLE (Pole Mount). See figure15. are provided. The 1.5 inch NPT pipe thread on top the dome (figure 12) is attached to an appropriate Mounting to a pole is similar to mounting to a mount supplied by the installer. Provisions must be wall. -
Page 21: Pole Mount Installation
INSTALLATION 3940 IP i-Dome Lock Down Bolts (2) 18 Pin Connector (Below) 1.5 NPT Nipple Pressure Relief Valve (5 psig) (Protected by Plastic Tubing) Schrader Valve Safety Strap (Cap Installed) Quick Disconnect Assembly Ventilation Hole Sun Shield (Camera Body Below) Figure 16. - Page 22 INSTALLATION 3940 IP iDome Lock Bolt Threaded Hole (2) (2 Used) Mounting Lug Slot Mounting Lug (4) Fixed Collar Dome Collar Sun Shield Safety Strap Lock Bold Detent (4) (2 used) NOTE: Dome can be mounted to fixed collar at any of four positions - in 90°...
-
Page 23: Alternate Mounting Methods
INSTALLATION 3940 IP i-Dome Figure 20. Mast Arm Mount For example, figure 20 shows a mount suitable for Figure 19. Pole Mount Dimensions attaching to an arm suspended over a roadway or other location. This mount straps to the arm and is threaded for 1.5 inch NPT mounting. -
Page 24: System Specifications
INSTALLATION 3940 IP iDome Table 9. Specifications SYSTEM SPECIFICATIONS CAMERA SPECIFICATIONS PAN/TILT DRIVE 1/4 inch interline transfer Imager color CCD 360° continuous pan range Angular Travel -90° to +5° tilt range Resolution 520 horizontal tv lines Pan Speed (preset) 250°/second 35X lens &... - Page 25 INSTALLATION 3940 IP i-Dome Table 9. Specifications (continued) VIDEO SPECIFICATIONS ENVIRONMENTAL SPECIFICATIONS VLIW/DSP TI TMS320DM642-600 IP67 & NEMA 4X; sealed & pres- Protection Rating surized to 5 psi with dry nitrogen MPEG4 ISO/IEC 14496-2 ASP; Video Encoding RTP/UDP stack Ambient Temp. Limits -34 to 50 °C (-27 to 122 °F)
- Page 26 INSTALLATION 3940 IP iDome 8.0 Warranty Please refer to the Cohu website for product warranty information: http://www.cohu-cameras.com/warranty/WarrantyStatement.pdf. Revision History Revision Date Comments • the manual is revised to replace contact infor- Rev D 06/28/12 mation with a link to the web page.
