Technology Corboy Law Center 711 Operating Instructions

The Electronic Classroom (EC) consists of three basic units: 1) Ceiling Projector and Remote Control
2) Computer and Monitor; and 3) Equipment Rack (shown below). Equipment rack includes: Main Power, Auxiliary
Plate, "Extron" MediaLink Switcher, Mixer, and VHS/DVD combo player.
To Turn On the Ceiling Projector:
1. Locate the remote control (attached to the worktable).
2. Point the remote at the ceiling projector and press softly, the ON button in the upper
right hand corner, a few times. You will hear the projector fan go on, and see a blue
light gradually glowing in the projector lens; this can take up to 1 minute.
To Turn On Equipment*:
The Equipment Rack is located inside the cabinet on or under the table.
1. Make sure the blue Main Power switch (on the right), as shown below, is "ON".
2. To adjust the volume, turn the Volume Adjust knob on the Extron Switcher.
* The power buttons of all rack equipment should remain in the "ON" position.
**If you are using the VHS/DVD combo player, and it does not respond, check to see if the power was shut off
manually on the left side of the player.
Extron Switcher
VHS/DVD
To Project an Image from the Computer Workstation:
1. Turn on the computer and monitor, if not already on, as you normally
would.
2. Turn on the ceiling projector (see "To Turn on the Ceiling Projector"
Instructions above).
3. On the remote control, press the Input 1 button.
4. Press input #4 PC on the Extron Switcher.
To Login to a Workstation:
For immediate assistance, please call ext. 8-4ITS
Hours of Operation: M-F 7am-9pm • Sat 8am-3pm • Sun Closed
**Please note that support hours are subject to change without formal posting.
Operating Instructions for Electronic Classroom:
Corboy Law Center 711
Instructional Technology & Research Support (ITRS) • Revised 6/22/2012
Input (1, 2, 3, 4)
Main Power
Volume Control
Input 1 button
#4 PC
ON button
buttons
