- Page 1 Professional Notebook English EasyGuide ESPRIMO Mobile V Series...
- Page 2 Are there ..any technical questions or problems? Please contact: • our Hotline/Help Desk (refer to the enclosed Help Desk List or go to: "www.fujitsu-siemens.com/support") • your sales partner • your sales office Additional information is contained in the Help Desk list and the "Warranty" manual. The "Warranty"...
- Page 4 This manual was produced by Xerox Global Services Published by Fujitsu Siemens Computers GmbH AG 07/07 Edition 2 Order no.: A26391-K243-Z120-1-7619...
- Page 5 ESPRIMO Mobile V Series EasyGuide Your ESPRIMO Mobile Important notes Ports and operating elements Removing and installing components during servicing Technical data Index...
- Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright © Fujitsu Siemens Computers GmbH 2007 All rights reserved, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole.
-
Page 7: Table Of Contents
Contents Contents Your ESPRIMO Mobile ..............Notational conventions . - Page 8 Contents A26391-K243-Z120-1-7619, edition 2...
-
Page 9: Your Esprimo Mobile
Your ESPRIMO Mobile Your ESPRIMO Mobile …offers you innovative technology and ergonomic design. This makes your notebook a reliable, convenient mobile PC. Your notebook is available in several different versions. Most of the sections in this manual apply to all models ‑ any differences are pointed out separately. Some of the illustrations and features in this manual may differ from your model and are for guidance only. -
Page 10: Notational Conventions
Your ESPRIMO Mobile Notational conventions Pay particular attention to text marked with this symbol. Failure to observe this warning will endanger your life, will damage the device or lead to loss of data. The warranty will be invalidated if you cause defects in the device through failure to take notice of this warning indicates important information that is required to use the device properly. -
Page 11: Important Notes
Important notes Important notes Take note of the safety hints provided in the "Safety" manual, in the "Professional Notebook" operating manual and in this manual. A26391-K243-Z120-1-7619, edition 2... -
Page 12: Ports And Operating Elements
Ports and operating elements Ports and operating elements This chapter presents the individual hardware components. This will provide you with an overview of the ports and operating elements on the notebook. Please familiarise yourself with these components before you start to work with your notebook. Statusindicators Microphone ExpressCardslot... -
Page 13: Switching On The Notebook
Ports and operating elements Switching on the notebook ► Slide the release button in direction of the arrow (1) and open the LCD screen (2). ► Press the ON/OFF switch (1) to switch the notebook on. The power-on indicator is lit. Windows XP You can configure the power button with Start - (Settings) - Control Panel - Performance and Maintenance - Power Options - Advanced. -
Page 14: Switching Off The Notebook
Ports and operating elements Switching off the Notebook ► Close all applications and shut down your operating system (please see operating system manual). If the notebook cannot be shut down properly, press and hold the ON/OFF button for approximately four seconds. The notebook will switch off. Any unsaved data may be lost. ►... -
Page 15: Status Indicators
Ports and operating elements Status indicators Statusindicators The status indicators provide information about the status of the power supply, the drives and the keyboard functions. Power indicator Caps Lock indicator Battery charging indicator Scroll Lock indicator Drive indicator Num Lock indicator Radio components indicator A26391-K243-Z120-1-7619, edition 2... - Page 16 Ports and operating elements The meanings of the symbols are as follows: Power-on indicator – mains operation • Indicator lights up green: the notebook is being powered from the mains. • Indicator flashes green: the notebook is in standby mode. Power-on indicator –...
-
Page 17: Key Combinations
Ports and operating elements Key combinations The key combinations described below apply when using Microsoft Windows operating systems. Some of the following key combinations may not function in other operating systems and with some device drivers. Key combinations are entered as follows: ►... - Page 18 Ports and operating elements Toggle output screen Fn+ F10 Toggleoutputscreen Use this key combination to select which screen(s) is/are used for display if an external monitor is connected. You can opt to use: • just the notebook’s LCD screen • just the external monitor •...
-
Page 19: Removing And Installing The Battery
Removing and installing the battery Notes Battery Only use batteries approved by Fujitsu Siemens Computers for your notebook. Never use force when inserting or removing a battery. Make sure that no foreign bodies get into the battery connections. Removing the battery ►... -
Page 20: Sim Card (Depending On Your Computer)
Ports and operating elements SIM card (depending on your computer) Follow the instructions supplied by the provider of the SIM card. Inserting the SIM card ► Switch the notebook off and pull the power plug out of the mains socket. ►... -
Page 21: Removing A Sim Card
Ports and operating elements Removing a SIM card ► Switch the notebook off and pull the power plug out of the mains socket. ► Close the LCD screen so that it locks into place. ► Disconnect all cables connected to the notebook. ►... -
Page 22: Radio Components: Wireless Lan/ Bluetooth/Umts
Ports and operating elements Radio components: Wireless LAN/ Bluetooth/UMTS Wireless LAN Bluetooth UMTS The installation of a wireless LAN module not approved by Fujitsu Siemens Computers GmbH voids the permits issued for this device (see chapter "Technical data", Page 22). Depending on the device variant, wireless LAN, Bluetooth and/or UMTS may be integrated in your notebook. -
Page 23: Removing And Installing Components During Servicing
Removing and installing components during servicing Removing and installing components during servicing Only qualified technicians should repair your notebook. Unauthorised opening or incorrect repair may greatly endanger the user (electric shock, fire risk) and will invalidate your warranty. Servicing Components You may remove and install the components described in this chapter yourself after consulting the Hotline/Help Desk. -
Page 24: Hard Disk
Removing and installing components during servicing Hard disk The hard disk is the most important storage medium of your notebook. You can work considerably faster and more efficiently if you copy applications and files from CDs to your hard disk. When the hard disk is accessed, the hard disk indicator lights up in the status indicator panel. -
Page 25: Installing The Hard Disk
Removing and installing components during servicing Installing the hard disk ► Insert the hard disk into the hard disk compartment in the direction of the arrow (1) . ► Place the hard disk cover over the opening (1). ► Tighten the screw (2). ►... -
Page 26: Removing And Installing Memory Modules
Removing and installing components during servicing Removing and installing memory modules Mainmemory Memoryexpansion Memoryupgrade System expansion Your notebook supports dual-channel DDR2 technology. The dual-channel DDR2 technology can only be used with two identical memory modules. When two different memory modules are installed, only "single-channel" mode is supported. -
Page 27: Removing The Cover
Removing and installing components during servicing Removing the cover ► Remove the screws (1). ► Pull the cover off the notebook (2). Removing memory modules ► Carefully push the two mounting clips outwards (1). Memory expansion Memory module The memory module snaps upwards (2). ►... -
Page 28: Attaching The Cover
Removing and installing components during servicing Attaching the cover ► Place the cover in the correct mounting position (1). ► Secure the cover with the screws (2). ► Reinstall the battery (see "Installing the battery", Page 11). ► Turn the notebook the right way up and place it on a flat surface. ►... -
Page 29: Removing And Installing The Optical Drive
Removing and installing components during servicing Removing and installing the optical drive If you are asked by the Hotline/Help Desk to remove and install the optical drive yourself, proceed as follows: Removing the optical drive ► Switch off your notebook and disconnect the power plug from the mains socket. ►... -
Page 30: Technical Data
Technical data Technical data Notebook Technicaldata Environmental conditions Environmental class Temperature Operating (3K2) 5°C – 35°C Transportation (2K2) -15 °C – 60 °C Dimensions Width x Depth x Height (front/back) 360 mm x 260 mm x 22-39 mm Weight (depending on configuration) Approx. -
Page 31: Mains Adapter 90W
Technical data Mains adapter 90W Technicaldata forthe Use the mains adapter 90W for the following processor: T7XXX. Electrical data Rated voltage 20 V Max. rated current 4.5 A An additional mains adapter and power cable can be ordered at any time. A26391-K243-Z120-1-7619, edition 2... -
Page 32: Index
Index Index Activate energy saving mode 10 Hard disk 4 Alt+Tab 10 removing 16, 21 Headphones port/Line Out 4 Back tab 10 Battery 4 Indicator important notes 11 Drive 8 inserting 11 removing 11 Battery charging indicator 8 Kensington Lock 4 Battery indicator see battery indicator 8 Battery release latch 4... - Page 33 Index switching off 9 Screen brightness switching on 9 decrease 9 Touchpad buttons 4 increase 9 Scroll indicator 8 UMTS 14 Scroll Lock indicator 8 switching off 14 Scroll Lock: switching on 14 indicator 8 USB port 4 Servicing 15 Shift+Tab 10 Sleep mode activating 10...
