Energy Sistem Battery Charger AA/AAA
NNATURA 6700 Worl-Wide Traveller.
Please read this manual carefully. It contains important
operating instructions.
Warning :
l
Batteries are not charged as shipped. Must be charged
prior to first
l
Charge only Ni-MH type batteries on this charger.
l
Batteries may leak or explode causing personal injury if
inserted improperly, disposed of in fire, mixed with other
battery types, or short circuited.
Features :
l
The charger includes 4-pin USB cable, car adaptor and
external AC adaptor
l
Powered by the supplied AC adaptor when using indoor
or by the supplied 12VDC Car adaptor when using in a
vehicle.
l
Specially designed with USB input cable , fits USB ports
l
Recharges 2 pieces or 4 pieces high capacity of AA &
AAA Ni-MH batteries at a time.
l
Batteries life well protected by –dV detection and timer
protection.
l
Automatic charging current selection for size AA and
AAA batteries.
l
LED display for rapid charge/trickle charge/bad cell
detection.
Flashing LED – rapid charge ; LED lighting up– trickle
charge ;
User Manual
use.
Advertisement
Table of Contents
Related Manuals for ENERGY SISTEM NATURA 6700
Summary of Contents for ENERGY SISTEM NATURA 6700
-
Page 1: User Manual
User Manual Energy Sistem Battery Charger AA/AAA NNATURA 6700 Worl-Wide Traveller. Please read this manual carefully. It contains important operating instructions. Warning : Batteries are not charged as shipped. Must be charged prior to first use. Charge only Ni-MH type batteries on this charger. - Page 2 No LED display – Cells are not suitable for charging. High efficiency, compact size & light weight. Safety Features : Negative delta V cut -off function Safety timer to prevent over charge Short circuit protection Reverse-polarity protection Bad cell Detection Charging Instructions Insert 2 or 4 pieces of AA/AAA rechargeable Ni-MH batteries into the battery compartment;...
- Page 3 The charger will adjust the suitable charging current for AAA battery automatically. Charge either AA or AAA size at a time. Do not mix to charge AA or AAA at same time. When using indoor Connect the supplied AC adaptor’s barrel plug into the jack on the back of the charger.
- Page 4 After the batteries are fully charged, the LED will light up indicating the trickle charge is on. The charged batteries are ready for use. Unplug the charger and remove the batteries from the charger when not in use. Begin again at Step 1 to charge the next set of batteries.
- Page 5 (when using indoor or in a vehicle) – 12VDC input Size Charging Ni-MH Charging Charging time current time (FOR 2 (For 4 PCS) PCS) 1000mA for 1300mAh 80 minutes 145 minutes charging 2 1600mAh 95 minutes 175 minutes 1800mAh 105 minutes 195 minutes batteries 2000mAh...
- Page 6 **For 4 pcs AA Ni-MH (using 4-pin USB cable input), the charging current is 400mAh. For 2 pcs AA Ni-MH, the charging current is 700mA. **For 4 pcs AA Ni-MH (using supplied adaptor), the charging current is 600mAh. For 2 pcs AA Ni-MH, the charging current is 1000mA.
- Page 7 The appliance is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the appliance. Before scrapping your charger, remove the batteries from the unit and they are disposed of safety...
