Reyconns GPS168G User Manual

Gps vehicle tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GPS VEHICLE TRACKER
USER MANUAL
1

Advertisement

Table of Contents
loading

Related Manuals for Reyconns GPS168G

Summary of Contents for Reyconns GPS168G

  • Page 1 GPS VEHICLE TRACKER USER MANUAL...

  • Page 2: Table Of Contents

    Content 1 Summary functions --------------------------------------------------------------------------------- 2 Application --------------------------------------------------------------------------------- 3 Hardware Description 3.1 Front face -------------------------------------------------------------------------------------- 3.2 Bottom face --------------------------------------------------------------------------------------- 4 Specifications ---------------------------------------------------------------------------------------- 5 Usage SIM card installation ----------------------------------------------------------------------- GPS Vehicle Tracker Installation ---------------------------------------------------------- Startup ------------------------------------------------------------------------------ Initialization ------------------------------------------------------------------------ Change or resume the password ----------------------------------------------------- Authorization ------------------------------------------------------------------------...

  • Page 3: Summary Functions

    1 Summary function Working Based on existing GSM network and GPS satellites, this product can locate and monitor any remote targets by SMS and GPS. 1.1 Positioning and Tracking: Through the on-line Positioning Platform or the cell phone to locates at times, and get the working status.

  • Page 4: Bottom Face

    3.2 Bottom face PRESS BUTTON TAKE OUT SIM CARD. WIRE BOX MICROPHONE SIM CARD 4 Specification Content Specs. Dim. 86mm *63mm *25mm Weight 0.51kgs Network GSM/GPS Band 850/1800/1900Mhz or 900/1800/1900Mhz or 850/900/1800/1900 GPS chip SIRF3 chip GSM module SIMCOM 900B GPS sensitivity -159dBm GPS accuracy...

  • Page 5: Usage

    5 Usage 5.1 SIM card installation Make sure that there is no call transfer and call display is on, and PIN code off. The SMS message must in Text format, can’t be identified for PDU format. 5.1.1 Put SIM card into card box. 5.1.2 Put the card box into host as picture.

  • Page 6: Startup

    Installation steps (caution: the following installation should under no power, otherwise will be dangerous) Wire for cutting off oil of the tracker Wire for cutting off circuit of the tracker Yellow wire connects the relay feet 86; 85 feet to White wire connects relay feet 86;...

  • Page 7: Real-Time Polling

    5.6.1 Call the tracker for 10 times, it will make the cell phone number as the authorized number automatically. 5.6.2 Send SMS "admin+password+space+cell phone number" to set up a authorized number. The other authorized numbers should be set by the first authorized number. If the number is successfully authorized, the unit will reply "admin ok!"...

  • Page 8: Modes Switch Between "Track" And "Monitor

    5.10 Modes switch between "tracker" and "monitor" 5.10.1 The default mode is "tracker". 5.10.2 Send SMS "monitor+password" to the unit, and it will reply “monitor ok!” and switch to “monitor”mode. 5.10.3 Send SMS "tracker+password" to the unit, it will reply “tracker ok!” and restore to “track” mode. 5.11 Geo-fence Set up a geo-fence for the unit to restrict its movements within a district.

  • Page 9: Cut Power Alert

    5.16 Cut power alert If cut power,the unit will send SMS alert. SMS format: " Cut power Alert+Geo-info". 5.17 Set Time Zone In order to make the time as the same with the user country, please send SMS command "zone123456 space time zone". For example, if user country time is GMT+8, then send"zone123456 8"to the device.

  • Page 10: How It Works

    8. How it works...
