XTA DC1048 Operator's Manual

Audio processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

DC1048
Operator's Manual Revision 1.10
XTA Electronics Ltd.
The Design House,
Vale Business Park,
Worcester Road,
Stourport-on-Severn,
Worcs. DY13 9BZ.
England
Tel: 01299 879977 (Intl. +44 1299 879977)
Fax: 01299 879969 (Intl. +44 1299 879969)
Web: http://www.xta.co.uk
x
ta
© XTA Electronics Ltd 2012
First published 01/2010
If you have any comments or suggestions about this manual, please
contact XTA at the address above, or email info@xta.co.uk
DC1048 Integrated Audio Management
Operator's Manual
Page 1
