I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Fusion Universal CPU Accessory
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCA102
Advertisement
Table of Contents
Related Manuals for CHIEF FCA102
Summary of Contents for CHIEF FCA102
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Fusion Universal CPU Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA102...
-
Page 2: Save These Instructions
WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the FCA102 does not exceed 15 lbs (6.8 kg). -
Page 3: Installation Instructions
165.1 FROM FUSION 6.50 MOUNTING RAILS LEFT ASSEMBLY RIGHT ASSEMBLY FCA102 POSSIBLE POSITIONS WHEN INSTALLED FCA102 POSSIBLE POSITIONS WHEN INSTALLED ON THE LARGE FUSION MOUNTS MEDIUM FUSION MOUNTS COMPONENT DIMENSION LIMITS WHEN INSTALLED IN MIDDLE OF UPPER BAR COMPONENT DIMENSION LIMITS WHEN MAX WIDTH = STUD DISTANCE - 3.50"... -
Page 4: Tools Required For Installation
FCA102 Installation Instructions LEGEND By Hand Phillips Screwdriver A mano Destornillador Phillips Von Hand Kreuzschlitzschraubendreher Com a mão Chave de fendas Phillips A mano Cacciavite a stella Met de hand Kruiskopschroevendraaier À la main Tournevis à pointe cruciforme TOOLS REQUIRED FOR INSTALLATION... - Page 5 Installation Instructions FCA102 INSTALLATION NOTE: The FCA102 may be used to support a surge adapter or other components that don’t exceed the weight capacity of the FCA102. Put Velcro tabs (C) together so there are 4 squares of Velcro. Remove paper from one side of each of the four Velcro squares.
- Page 6 FCA102 Installation Instructions Tighten the Phillips pan machine screws to complete installation of the FCA102 bracket. (See Figure 4) Figure 4...
- Page 7 Installation Instructions FCA102...
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
