Before using this air conditioner, please read the following instructions carefully and keep
this manual along with your proof of purchase in a safe place for future reference.
OWNER'S MANUAL
CANADIAN STANDARDS
MINI-SPLIT AIR CONDITIONER
12,000 BTU (EER13)
MODEL: 13-05000
MODE
ON / OFF
© Copyright, Sunrise Tradex Corp., 2007
00226-11/01/07
Advertisement
Table of Contents
Related Manuals for Sunrise Tradex ForestAir 13-05000
Summary of Contents for Sunrise Tradex ForestAir 13-05000
- Page 1 Before using this air conditioner, please read the following instructions carefully and keep this manual along with your proof of purchase in a safe place for future reference. OWNER’S MANUAL CANADIAN STANDARDS MINI-SPLIT AIR CONDITIONER 12,000 BTU (EER13) MODEL: 13-05000 MODE ON / OFF © Copyright, Sunrise Tradex Corp., 2007 00226-11/01/07...
-
Page 2: Table Of Contents
CONTENTS Safety precautions .........2 Air conditioner diagram . -
Page 3: Safety Precautions
If the outlet grilles of both inside power cord is damaged, and outside units. contact SUNRISE TRADEX Warn children. Customer Service. Always close the air To eliminate risks of electric Do not put any combustion... -
Page 4: Air Conditioner Diagram
AIR CONDITIONER DIAGRAM INDOOR UNIT Air in Panel Air filter Front case Wiring cover Handling swit- Air out Louver Timer Remote control Drain hose OUTDOOR UNIT Air in Suction and liquid refrige- rant piping Air outlet grill Air out... -
Page 5: Remote Control
REMOTE CONTROL 2 AAA - 1.5V BATTERIES POWER THE REMOTE CONTROL • Do not use rechargeable batteries How to insert the batteries 1. Following the arrows (see Figure), remove the battery cover. 2. Insert the 2 batteries, making sure that the terminals (+/-) are correctly fitted. -
Page 6: Remote Control
REMOTE CONTROL IMPORTANT : Some functions on this remote control are not available on models sold in Canada. The usage and operation of these functions are therefore not detailed in this manual. IAGRAM OF THE REMOTE CONTROL WITH OPEN COVER SWING Press this button to Press this button to... -
Page 7: Remote Control Operation (Cooling)
REMOTE CONTROL OPERATION COOLING • Based on set temperature, the air conditioner’s microcomputer controls the cooling system (compressor) to maintain room temperature. If the room temperature is higher than the set temperature, the compressor resumes and the air conditioner runs in cooling mode. -
Page 8: Remote Control Operation (Dehumidifying)
REMOTE CONTROL OPERATION DEHUMIDIFYING • In DEHUMIDIFYING mode, the FAN runs at LOW speed and will cycle on and off. Both fan speed and temperature cannot be changed. PERATIONS ARE NUMBERED IN ORDER OF STEPS TO FOLLOW 3. OSCILLATION Press on SWING to start the automatic oscillation of the louvers. -
Page 9: Remote Control Operation (Auto Mode)
REMOTE CONTROL OPERATION AUTO MODE • When the air conditioner is set to AUTO (Automatic) mode, the cooling and dehumidifying functions will cycle on and off to maintain the room humidity rate and temperature to an optimum comfort zone. Both functions may not cycle on and off simulateneously. -
Page 10: Remote Control Operation (Timer)
REMOTE CONTROL OPERATION TIMER • When the TIMER is on, you can program the air conditioner to automatically turn on (TIMER ON) or shut off (TIMER OFF) and set the time delay before the start or the shut off of the air conditioner. •... -
Page 11: Remote Control Operation (Sleep Mode)
REMOTE CONTROL OPERATION SLEEP MODE • When the unit is COOLING or DEHUMIDIFYING, if the SLEEP operation is on, the set temperature will increase BY 1°C every hour, until the unit shuts off after 7 hours of operation. • In SLEEP mode, the indoor fan runs at low speed in DEHUMIDIFYING mode. 3. -
Page 12: Safety Notes
SAFETY NOTES Always set the most adequate temperature. • The airflow direction can be moved It is recommend to set the temperature upward or downward when unit is about 5°C cooler than the outside running. temperature to reduce energy costs. •... -
Page 13: Maintenance
MAINTENANCE CAUTION Turn power off and then cut the circuit-breaker off before cleaning the air conditioner. Never spray water on the indoor and outdoor units when cleaning the air conditioner. Always use a dry soft cloth and warm water, without or with a mild detergent. Cleaning the front panel 1. -
Page 14: Maintenance
MAINTENANCE Active-carbon air filters (optional) 1. Remove the air filters, as described in step #1 of “Cleaning the air filters” section. 2. Take the active-carbon air filters out of the bag and place them into the filter frames. • Be cautious not cut yourself on the fins. 3. -
Page 15: Troubleshooting
TROUBLESHOOTING WARNING: Do not attempt to repair your system by yourself. It can cause electric shock or fire. Please verify the following items before calling for a technician, it can save you time and money Problem Possible cause and solution The air conditioner does not run In cooling mode, the compressor takes immediately after the power key is... - Page 16 TROUBLESHOOTING If any of the following situations occur, stop all operations and call the Sunrise Tradex Corp. Customer Service: 1-800-686-2175 Unusual noise can be heard during operation. Power fuse or switch often breaks. Carelessly splash water or something into air conditioner.
-
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS GSW18-22L/A INDOOR UNIT GSW18-22L/A OUTDOOR UNIT (OUTDOOR UNIT) (OUTDOOR UNIT) COOLING CAPACITY 12,000 BTU/H COOLING CAPACITY 12,000 BTU/H VOLTAGE ~115V VOLTAGE ~115V FREQUENCY/PHASE 60 HZ FREQUENCY/PHASE 60 HZ DESIGN PRESSURE (High) 2.5 mpa TOTAL INPUT CURRENT DESIGN PRESSURE (Low) 1.0 mpa (Cooling) 9.6 A... -
Page 18: Installation Setup Diagram
• It is important to have your mini-split air conditioner installed by a Sunrise Tradex Corp. certified installer for your warranty to be valid. A mini-split air conditioner installed by a technician other than a Sunrise Tradex Corp. -
Page 19: Installation Location
INSTALLATION LOCATION INDOOR UNIT 1. The inlet and outlet should not be covered so that the outflow air can reach all parts of the room. 2. Install in a location where is permitting easy connection with the outdoor unit. 3. A location from which the condensation water can be drained out conveniently. 4. -
Page 20: Installation Instructions
INSTALLATION INSTRUCTIONS INSTALL THE REAR PANEL 1. Always mount the rear panel horizontally. 2. Fix the rear panel on the selected location with screws supplied with the unit. 3. Be sure that the rear panel has been fixed 50 mm (2”) 50 mm (2”) firmly enough to withstand the weight of an adult of 60 kg (132.3 lbs.), furthermore, the... -
Page 21: Electrical Wiring - Indoor Unit
INSTALLATION INSTRUCTIONS ELECTRICAL WIRING - INDOOR UNIT *Only an electrician must do the connection of this unit. Note: The power of indoor unit is supplied by the outdoor unit.The outside disconnect switch must be installed between electrical panel and condensing unit. Operation procedures: 1. - Page 22 INSTALLATION INSTRUCTIONS Note: Wiring must be done by an electrician according to the local rules & regulations and this manual. The connecting wire should be correctly connected to circuit interface. Otherwise, it can cause a fire, electrical malfunction or cause damage to the unit. The diagram is shown as below: 4-way terminal board Power connection cord...
-
Page 23: Electrical Wiring - Outdoor Unit
INSTALLATION INSTRUCTIONS ELECTRICAL WIRING - OUTDOOR UNIT Operating procedures : • Open the cover of outdoor unit. • The connecting wire led from the terminal board of indoor unit should be connected correctly • The connecting wire should be a little longer so that it can easily maintened 8-way terminal board 6-way terminal board Power connection cord... - Page 24 INSTALLATION INSTRUCTIONS INSTALL THE POWER LINE 1. Open the wiring cover. 2. The connector of wire pipe should be fixed by the fixed nut and the wiring cover should be also fixed. Fixed nut Electric box assembly Connector Wiring cover NOTE 1.
-
Page 25: Installation Instructions
INSTALLATION INSTRUCTIONS Installation of the indoor unit 1. When routing the piping and wiring from the left or right side of the indoor unit, cut off the tai- Right rear piping Right piping lings from the chassis in neces- sary (shown in Fig.4, (a), (b) (c)). (1) Cut off the tailings 1 when Tailings 3 routing the wiring only. -
Page 26: Air Purging And Leakage Test
AIR PURGING AND LEAKAGE TEST 1. Take out the nut cover of the inlet for Pressure gauge refrigerant. 2. Connect the tube of the vacuum watch with the vacuum pump, having the low- pressure end linking to the inlet for refri- gerant. -
Page 27: Test Operation
TEST OPERATION 1. Before test operation (1) Do not switch on power before installation is finished completely. (2) Electric wiring must be connected cor- rectly and securely. AUTO/STOP (3) Cut-off valves of the connection pipes should be opened. (4) All the impurities such as scraps and thrums must be clear from the unit. -
Page 28: Important Notice
IMPORTANT NOTICE • Always consult a qualified electrician to install the unit. • Please contact the after sales service for any problems. • If you have to carry your air conditioner in down position, it is suggested to wait 12 hours before you restart the machine. -
Page 29: Warranty
This air conditioner is covered by a warranty against defects in materials and workmanship including the compressor, if used for the applications specified in this owner’s manual, if installed by a Sunrise Tradex Corp. certified installer, for a period of ONE (1) year from the date of original purchase in Canada.
