  • Page 1 USER GUIDE PURE ACOUSTICS 5.1 Home Theater Speaker Package LORD-8...

  • Page 3: Table Of Contents

    Specifications ........12 Welcome Congratulations on your purchase of a high-quality Pure acoustics product. Your...

  • Page 4: Pure Acoustics Lord-8

    PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Safety information To reduce the risk of electric shock, do not remove the cover or back. No user serviceable parts inside. Refer servicing to qualified service personnel. To reduce the risk of fire or electric shock, do not expose your speakers to rain or moisture.

  • Page 5: Important Safety Instructions

    PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Important safety instructions 1 Read these instructions. 2 Heed all warnings. 3 Follow all instructions. 4 Do not use your speakers near water. 5 Clean only with a dry cloth. 6 Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

  • Page 6: Features

    PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Features Satellite/center channel speaker • 0.75-inch (19 mm) balanced dome tweeter (center channel) • 2.5-inch (64 mm) midwoofer • 0.5-inch (13 mm) balanced dome tweeter (satellite) • Video shielding for placement near a TV or monitor •...
  • Page 7 PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Back of subwoofer PURE ACOUSTICS LORD-8 Component Description Left channel (high These binding post terminals for speaker wires accept level) input a stereo, speaker-level, full-range signal from a receiver or power amplifier. This signal is processed Right channel and amplified to power the subwoofer.
  • Page 8 PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Component Description Line level input These RCA jacks accept a line-level, full-range signal from the pre-amplifier or LFE output of a receiver or preamplifier. This full-range signal is processed and amplified to power the subwoofer.

  • Page 9: Setting Up Your Speakers

    PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Setting up your speakers Positioning your speakers The following illustration depicts the most generally accepted speaker locations for a home theater system. Center front Left front Right front Subwoofer Listening area...
  • Page 10 PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Front speaker heights One of the most important parameters for the front speakers in a home theater system is their height. Refer to the following illustration for an example of ideal speaker height placement.
  • Page 11 PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Connecting your speakers Turn off all power to your subwoofer and other equipment before making any connections. Refer to the following illustration as a guide for connecting the speakers using speaker-level (high-level) inputs.

  • Page 12: Care And Maintenance

    PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Refer to the following illustration as a guide for connecting speakers using line-level (subwoofer) inputs from A/V amplifiers and receivers with 5.1-channel outputs. Connect the subwoofer LFE output of a receiver to either the left or right line-level RCA input jack.

  • Page 13: Troubleshooting

    PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Troubleshooting After you have set up your new speakers, they should give you years of listening enjoyment with your favorite movies and music. However, if you should experience a problem with your speakers, try these troubleshooting steps to help diagnose and fix the problem.

  • Page 14: Specifications

    PURE ACOUSTICS LORD-8 Home Theater Speaker Package PURE ACOUSTICS Specifications Satellite/center-channel speaker Driver complement Midwoofer: 2.5-inch (64 mm) shielded with paper cone, foam surround Tweeters: • 0.5-inch (13 mm) balanced dome tweeter (satellite) • 0.75-inch (19 mm) balanced dome tweeter (center channel)
