TurfEx TS-65 Owner's/Operator's Manual

Hide thumbs Also See for TS-65:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
This Manual Must be Read Before Operating The Equipment
Owner/Operator's Manual
FOR MODEL
TS-65/TS-65SS
CUSTOMER COPY
Madison Heights, Michigan 48071
800-725-8377
www.turfexproducts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-65 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TurfEx TS-65

Summary of Contents for TurfEx TS-65

  • Page 1 This Manual Must be Read Before Operating The Equipment Owner/Operator’s Manual FOR MODEL TS-65/TS-65SS CUSTOMER COPY Madison Heights, Michigan 48071 800-725-8377 www.turfexproducts.com...

  • Page 2: Table Of Contents

    Spreader Maintainence ....................................9 Calibration ......................................10-11 Warranty ........................................12 Assembly Views ......................................13 Hopper Assembly Parts Breakdown Model# TS-65/TS-65SS .................................. 14-15 Handle Assembly Parts Breakdown Model# TS-65 ....................................16-17 Axle Assembly Parts Breakdown Model# TS-65 ....................................18-19 Handle Assembly Parts Breakdown Model# TS-65SS .....................................

  • Page 3: General Information

    General Information CONGRATULATIONS! The Turfex product you have purchased is an example of turf management product at its fi nest! Your Turfex product ’s, self contained design is a trademark of all Turfex products. Here’s why... SIMPLICITY: Fewer moving parts manufactured of higher quality means minimal maintenance for your Turfex product.

  • Page 4: Introduction

    We require that you read and understand the contents of this manual completely (especially all safety information) before attempting any procedure contained herein. Extra copies of Owner/Operator Manuals can be purchased at your Turfex Dealer. THIS SIGN SHOULD ALERT YOU: The Society of Automotive Engineers has adopted this SAFETY ALERT SYMBOL to pinpoint characteristics that, if NOT carefully followed, can create a safety hazard.

  • Page 5: Safety

    For your safety warning and information decals have been placed on this product to remind the operator of safety precautions . If anything happens to mark or destroy the decals, please request new ones from TurfEx. Remember, most accidents are preventable and caused by human error. Exercising of care and precautions must be observed to prevent the possibility of injury to operator or others! Never operate equipment when under the infl...

  • Page 6: Spreader Assembly Instructions

    Spreader Assembly Instructions TS-65/TS-65SS Step 1: Assemble Axle Assembly A) Slide shaft collars onto axle toward gear housing. B) Slide hopper frame onto axle through bushings. C) Assemble wheels to axle with long cotter key through drive wheel and the short cotter key outside free wheel through axle.

  • Page 7: Spreader Assembly Instructions

    Spreader Assembly Instructions (con’t) TS-65/TS-65SS Step 5: Assemble handle assembly to leg A) Slide handle onto leg and fasten with (2) bolts. (see fi gure1) B) Insert rod into upper control handle. (see fi gure 2) C) Insert rod end into gate linkage and lock in place with hair pin clip (see fi...

  • Page 8: Operating Instructions

    Operating Instructions TS-65/TS-65SS SPREADER LOADING Capacity: 1 1/2 Cubic Ft Hopper WARNING – Do not overload spreader. Weights of material are an average for dry materials. Material Weight Per Cubic Ft. Fertilizer See product information on bag or bulk materials that you are using •...

  • Page 9: Spreader Maintainence

    Spreader Maintainence TS-65/TS-65SS Important Gears and Axles Must Be Lubricated and Greased Every 20 Hours of Use. Remove gear housing and apply Chain Lube spray lubrication. Use general purpose grease on both grease zerks. © Trynex International 2011 L1193...

  • Page 10: Calibration

    Calibration Instructions To Calibrate your spreader close the gate completly then start to open (notice the handle will move before the gate starts to slide.) As the handle begins to actvate the gate slide watch the slide and just as it starts to open then stop.

  • Page 11: Calibration

    Calibration Disclaimer It is the responsibilty of the person using this equipment to make sure that every type of material is properly calibrated to perform as expected. This process should take place on a solid fl at surface away from drains and livestock areas in order to achieve a safe and accurate reading for proper material distribution.

  • Page 12: Warranty

    Warranty Limited Warranty Two year warranty on Turfex brand products against defects in material or workmanship under normal use and service, subject to limitations detailed below. Warranty period of two years begins on the date of purchase by the original retail user.

  • Page 13: Assembly Views

    Assembly Views Model # TS-65/TS-65SS TA-200000 © Trynex International 2011 L1193...
  • Page 14 Hopper Assembly Parts Breakdown Model # TS-65/TS-65SS © Trynex International 2011 L1193...
  • Page 15 Hopper Assembly Parts Breakdown Model # TS-65/TS-65SS BOM ID Description Qty BOM ID Description Qty D5907 D5907 T15014 T15014 D5967 D5967 T15016 T15016 D5973 D5973 T30168 T30168 © Trynex International 2011 L1193...

  • Page 16: Handle Assembly Parts Breakdown

    Handle Assembly Parts Breakdown Model # TS-65 © Trynex International 2011 L1193...

  • Page 17: Model# Ts-65

    Handle Assembly Parts Breakdown Model # TS-65 BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty D5905 D5905 D5918 D5918 D5934 D5934 D5946 D5946 D5906 D5906 D5924 D5924 D5935 D5935 D5948 D5948 T15016...

  • Page 18: Axle Assembly Parts Breakdown

    Axle Assembly Parts Breakdown Model # TS-65 © Trynex International 2011 L1193...

  • Page 19: Model# Ts-65

    Axle Assembly Parts Breakdown Model # TS-65 BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty D5902 D5902 D5915 D5915 D5930 D5930 D5993 D5993 D5904 D5904 D5916 D5916 D5938 D5938 D5994 D5994 D5909...

  • Page 20: Handle Assembly Parts Breakdown

    Handle Assembly Parts Breakdown Model # TS-65SS © Trynex International 2011 L1193...

  • Page 21: Model# Ts-65Ss

    Handle Assembly Parts Breakdown Model # TS-65SS BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty D5905 D5905 D5925 D5925 D5943 D5943 T15016 T15016 D5907 D5907 D5927 D5927 D5944 D5944 T15018 T15018 T30152 T30152 D5912 D5912...
  • Page 22 Axle Assembly Parts Breakdown Model # TS-65SS © Trynex International 2011 L1193...
  • Page 23 Axle Assembly Parts Breakdown Model # TS-65SS BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty BOM ID Description Qty D5902 D5902 D5915 D5915 D5938 D5938 D5994 D5994 D5904 D5904 D5919 D5919 D5939 D5939 D6024 D6024 D5909 D5909 D5921 D5921...

  • Page 24: Notes

    Notes © Trynex International 2011 L1193...
  • Page 25 Notes © Trynex International 2011 L1193...
