GadgetPC
Single Board Computer
UVC Web Camera Quick Start Guide
Document Revision: 1.02
Date: 28 June, 2010
BiPOM Electronics, Inc.
16301 Blue Ridge Road, Missouri City, Texas 77489
Telephone: 1-713-283-9970
Fax: 1-281-416-2806
E-mail: info@bipom.com
Web:
www.bipom.com
All trademarked names in this manual are the property of respective owners.
© 2009 BiPOM Electronics, Inc.
Page 1
Advertisement
Summary of Contents for BiPOM Electronics UVC
- Page 1 GadgetPC Single Board Computer UVC Web Camera Quick Start Guide Document Revision: 1.02 Date: 28 June, 2010 BiPOM Electronics, Inc. 16301 Blue Ridge Road, Missouri City, Texas 77489 Telephone: 1-713-283-9970 Fax: 1-281-416-2806 E-mail: info@bipom.com Web: www.bipom.com All trademarked names in this manual are the property of respective owners.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Overview 2. Configure UVC camera with Linux Control Panel 3. Hardware Setup 4. Software setup 5. Network Web Camera 6. How to embed the remote camera to the user's web page 7. Pre-installed software Page 2... -
Page 3: Overview
Thank you for your purchase of the GadgetPC Single Board Computer. GadgetPC is a powerful computer board that is capable of running high-level operating systems such as Linux. This document explains how to start with UVC compliant QuickCam® 3000 for Business WEB camera from Logitech ( http://www.logitech.com/index.cfm/business/products/webcam_communications/devices/47 83&cl=us,en... -
Page 4: Configure Uvc Camera With Linux Control Panel
2. Configure UVC camera with Linux Control Panel In order to configure UVC camera, start Linux Control Panel software from Start -> All Programs -> GadgetPC -> Linux Control Panel. After Linux Control Panel starts, open vars.sh file that is located in c:\bipom\devtools\GadgetPC\sh ( if you installed Linux Control Panel to default path ). - Page 5 Double click Hardware and Peripherals icon. Go to Peripherals group. In this group you can configure one variable: UVC Camera: Select ON or OFF. If you select ON then UVC Camera will be enabled. Select OFF if you don’t want to use UVC Camera.
- Page 6 Double click Software icon. Go to UVC Camera Server group. In this group you can configure four variable: Run UVC Camera Server: Select YES or NO. If you select YES then UVC camera server will run at boot time. Select NO if you want to disable UVC camera server.
-
Page 7: Hardware Setup
3. Hardware setup The setup includes: GadgetPC board; Logitech UVC web camera; D-Link USB Ethernet adapter; 2GB USB Flash drive. The setup allows to connect to a network WEB camera using FireFox, Opera, Chrome browsers. NOTE: Internet Exploler does not support the video stream. -
Page 8: Software Setup
4. Software setup 4.1. Bipom provides the prepared archives under FTP server: GadgetPC_USB_RootFS_BSVER107_loader.zip debian_rootfs_12Sep2009.tar.bz2 linux2.60.30.4_12Sep2009.tar.bz2 Account to access BiPOM FTP server: Host = www.bipom.com Port = 21 User = bipomftp Pass = guest123! 4.2. U-boot loader. In order to run RootFS on USB drive it is necessary to configure U-boot to provide correct arguments to Linux kernel. - Page 9 Create a dual partition USB flash drive. Please read GadgetPC Debian Installation Guide. Copy all the files/folders from FAT folder to /media/FAT sudo cp -R FAT/* /media/FAT Copy all the files/foders from EXT3 folder to /media/EXT3 sudo cp -R EXT3/* /media/EXT3 Page 9...
-
Page 10: Network Web Camera
5. Network Web Camera The Gadget PC is pre-configured to: IP address of Device: 192.168.1.210 Subnet mask: 255.255.255.0 IP address of Gateway: 192.168.1.1 Power the setup. Try Opera browser to get a snapshot from a camera. In order to get the video stream just type http://192.168.1.210:8080/?action=stream Page 10... -
Page 11: How To Embed The Remote Camera To The User's Web Page
The example below show HTML code for camera installe don device with IP 192.168.1.20. The UVC Camera server used port 8080 and resolution is 640x480: <img src="http://192.168.1.20:8080/action=stream" width="640" height="480"> Below you can see whole HTML page which will show stream from UVC Camera: <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"> <html> <head>... - Page 12 Page 12...
-
Page 13: Pre-Installed Software
7. Pre-installed software The current package includes the pre-installed SSH and NTP servers. 7.1. NTP server. If GadgetPC is connected to a network that provides access to Internet the board will get time from the remote server. Note. GadgetPC does not provide a hardware clock. 7.2. - Page 14 Page 14...
