Summary of Contents for Naito V1
- Page 1 Page 1...
- Page 2 Thank you for purchasing Naito V1 The Naito V1 is a state-of-the-art ultra compact DashCam featuring full HD 1080 video, Loop Recording, Motion Detection and G-Sensor. Please read this manual carefully before using the product. » Motorcams Ltd retains all rights to this manual in accordance with copy right laws.
-
Page 3: Table Of Contents
Contents 1. Safety Instructions ......... 2. -
Page 4: Safety Instructions
Safety Instructions This manual covers what should be done to protect the user’s safety and prevent property damage. Please make sure to read these safety instructions before using the product. Do not disassemble, repair and/or alter the product. This may cause a fire, an electric shock and/or malfunction. Contact the service center if you need to have the product fixed. User may not be entitled to free service if and when product malfunction is caused by user’s fault. - Page 5 Drastic changes in brightness (on entry/exit of tunnels), strong backlight in the daytime, and no light source at night may result in deminished video quality. Excessively tinted windscreens may cause recorded images to look blurry or distorted. Installation Cautions » Installing or operating the device while driving may cause an accident. Only install and/ or operate the device while the vehicle is not in motion. » If the cigarette lighter receptacle emits fumes or a funny smell, stop using the product immediately and contact us or one of our dealerships. » Dust and built-up dirt in the cigarette lighter receptacle may cause heat or a fire. Clean it on a regular basis. » We do not take any responsibility for malfunction, injuries or damage to the product caused by inappropriate use. Page 5...
- Page 6 Memory Card Cautions » Do not forcefully remove the SD card while the product is in recording mode. Be sure to turn off the camera before removing the SD card. » Please format the SD card at least once a week Repeated read-write operations may damage the files contained on the SD card. Regular formatting will help prevent this from happening. » The maximum lifespan of a SD card is six months. We are not liable for any SD card errors after this period. » Be sure to back up your recorded videos using an additional storage device. » Format the SD card by using the computer or by using the camera’s format function found in settings menu. » Always use SD cards reccommended by our company. We are not responsible for any issues caused by using an incompatible SD card. Page 6...
-
Page 7: Whats Included
Whats Included? Main Unit Car Charger USB-cable AV-cable User Manual » Check to make sure all the components above are included. » Components may be changed without notice to improve product functionality and/or quality. » Original Motorcam components are recommended. The use of third party components may restrict warranty. » All Motorcam units come with a pre-installed 8GB memory card. Page 7... -
Page 8: Product Features
Product Features • High-definition Video: Motorcam uses high quality megapixel lenses, which produce clear and sharp images even at night. • G-Sensor: If the camera detects gravity acceleration of 4G or more the current file will auto- matically be protected from being overwritten by the Loop Record function. • Motion Detection: With Motion Detection enabled function turned on (settings menu) the camera will start recording when it detects motion in front of the car while parked. NOTE: This function requires hard wiring the camera into the car’s fuse box • Audio Recording: The camera is equipped with a high-performance microphone for audio recording. Page 8... - Page 9 • Night Vision: Motorcam X1 uses an extremely light sensitive image sensor to ensure clear images at night. • USB/HDMI: The camera connects to a computer via USB and to a TV/Monitor via HDMI. • Time Stamp: Date and time can be embedded in the video with the “Date Stamp” function in the setting menu. • Anti-Shake: Motorcam’s anti-shaking technology ensures stable images. Page 9...
-
Page 10: Product Overview
Product Overview 1. Bracket 2. USB-slot 3. AV-out 4. UP Button 5. OK Button 6. Down Button 7. Led Indicator 8. Wide Angle Lens Page 10... - Page 11 9. POWER Button 10. Micro SD-slot 11. HDMI Out Page 11...
-
Page 12: Operating Instructions
Operating Instructions Menu Navigation From Recording Mode press the POWER button once enter the Settings menu. Navigate the menu with the UP and DOWN buttons and press OK to enter sub-menus and selecting options. Exit menu or move up a level by pressing the POWER button again. Press the POWER button twice in succession to enter the system settings menu. Sub-Menu Description Function Video Mode Resolution 1080p / 720p / WVGA / VGA Set the video resolution Loop Recording OFF / 3min / 5min / 10min The length of the files Motion Detection ON/OFF(default) Motion Detection ON/OFF Date Stamp ON(default)/OFF Embed time and date... - Page 13 Sub-menu Description Function System Settings Date/Time Set the time Auto Power Off OFF/3min/5min/10min Set the Auto-Off time Beep Sound ON/OFF Turn ON/OFF the button beeps Language Select operating language Frequency 50/60 HZ European/US power supply TV Mode NTSC/PAL American/European Default Settings Cancel/OK Restore factory defaults Version Delay Power Off OFF/15s/1/5/30/60 min. Set the delay power off time Anti-Shaking ON/OFF Turns the anti-shaking ON/ Image Rotation...
-
Page 14: Operating Modes
Operating Modes 1. Video Mode The camera defaults to Video Mode when switched on manually or connected to the car charger. Press the OK button to start recording. Press OK again to stop recording. The indicator will start to flash blue when recording is initiated. When the camera connected to the 12V car charger it swill shut off automatically 5 seconds after you turn off the ignition or unplug the charger. 2. Photo Mode Press and hold the OK button to enter Photo Mode. Press OK again to take still photos. 3. Preview Mode In Photo Mode press and hold the OK button to enter Preview Mode. Use the the UP/ DOWN buttons to select video and photo files. Press the OK button to start/pause video. Press the POWER button once to enter the delete file / format SD card menu. Press and hold the ON button again to go back to Video Mode. Page 14... -
Page 15: Charging The Battery
• Connecting to Computer Press the OK button once and the PC will detect the camera as a storage device. Go to My Computer->Removable disk->DCIM where you will find all the files currently on the memory card. • Charging the Battery When attached to the car charger the camera will charge the battery while operating normally. The camera will also charge the battery when connected to a computer via USB • Reset If the camera behaves abnormally press the Reset button. The unit will reset automatically. • Screen Saver Set the amount of time before the screen saver will kick in or turn it off entirely Page 15... - Page 16 Specifications Video Resoloution 1920*1080p/1280*720p/720*480p/640* 480p Viewing Angle 120 degrees Screen 1.5” TFT display Video Format AVI 30fps Photo Format JPEG Storage Micro SD card Max 32GB USB-interface USB2.0 AV/HDMI/out NTSC/PAL Battery 250m/AH Charge time 3 hours Work temperature -10C – 60C Weight 55.2g Page 16...
- Page 17 Motorcams Ltd >> UK Headquarters Address: Unit D, 28 High Street, Hampton Hill, Middlesex TW12 1PD, Web: www.motorcams.co.uk E-mail: info@motorcams.co.uk Phone: +44 20 8819 5921 Conformité Eurpéene Federal Communications Commision (European Communities; EC) Electromagnetic Wave Suitability EU Joint Standard Certification Certification Page 17...
