Page 1: Table Of Contents
User Manual for USB Phone with LCD Unpacking Learn About Your Phone Overview Host System Requirements Specifications Phone Layout Keypad Instructions LCD Icons Instructions Getting Started Step 1: Install the Latest VoIP Applications Step 2: Install the Latest SkyU2M Driver Step 3: Connect the USB Phone to PC Step 4: Activate a Needed VoIP Application Step5: Set the Intelligent Router for SkypeOut... -
Page 2: Unpacking
User Manual for USB Phone with LCD Unpacking When you receive your USB phone SX-08L, please check to make sure that your package contains the following items: One USB handset One installation CD One user manual* Note: This user manual is written for the SkyU2M driver version 2.0.0.3. -
Page 3: Learn About Your Phone
User Manual for USB Phone with LCD Learn About Your Phone Overview This is a high quality USB hand phone with LCD and chord music ring tones. The fully functional keypad and the LCD screen enable you to make/receive Skype calls without using mouse and keyboard. -
Page 4: Phone Layout
User Manual for USB Phone with LCD Phone Layout Speaker Earphone Connector LCD Screen Scroll Up/Down Key Left Function Key Right Function Key End/Cancel key Answer/Call key VoIP Applications Key Voice Mail Key Numbers Volume Increasing Volume Decreasing Key Microphone - 4 - Version 1.0.0.0 2006-09-18... -
Page 5: Keypad Instructions
User Manual for USB Phone with LCD Keypad Instructions Instructions Choose the corresponding operations or menus in the bottom-right corner of the LCD screen. Choose the corresponding operations or menus in the bottom-right corner of the LCD screen. Scroll up/down a list Answer/Make a VoIP call End/Cancel a VoIP call;... -
Page 6: Lcd Icons Instructions
User Manual for USB Phone with LCD LCD Icons Instructions Icons Instructions Skye Contact Online status Unavailable status Away status Offline status Not sharing contact details Incoming call Outgoing call Missed call Voice mail Conference mode The call has been connected The call has been disconnected Volume value The black bar shows the browsing position in the menu... -
Page 7: Getting Started
User Manual for USB Phone with LCD Getting Started Step 1: Install the Latest VoIP Applications The latest version of Skype (Version 2.0 or above) is strongly recommended. You can download it from Skype’s official website: http://www.skype.com/download/skype/windows/ Other VoIP applications can be downloaded in the following websites: VoipBuster http://www.voipbuster.com/en/download.html VoipStunt... -
Page 8: Step 3: Connect The Usb Phone To Pc
User Manual for USB Phone with LCD Step 3: Connect the USB Phone to PC The hardware installation is very simple. All you need to do is to connect the USB phone to the USB port on your PC. The LCD screen will show as below: Now can see a green icon in the task bar which indicates you are ready to make/receive calls with the USB phone. -
Page 9: Step5: Set The Intelligent Router For Skypeout
User Manual for USB Phone with LCD Or Press on standby mode and choose “Active VoIP” as below: Step5: Set the Intelligent Router for SkypeOut There are some other famous VoIP applications except Skype providing cheaper or free VoipOut service for subscribers. The “Intelligent Router for SkypeOut” is designed for you to enjoy this cheaper or free VoipOut services when you make a SkypeOut calls. - Page 10 User Manual for USB Phone with LCD made thru SkypeOut service. If you click both “Use a FREE VoIP service to make SkypeOut calls” and “Use the below VoIP service to make SkypeOut calls”, the SkypeOut calls will be routed to the selected VoIP service if the free VoIP service is unavailable.
-
Page 11: Update The Usb Phone Driver
User Manual for USB Phone with LCD Update the USB Phone Driver Please remember to update the USB phone driver regularly. You can follow this guideline here: Right click the icon and choose “Check for Update”. Or you can enable your driver to check for update automatically in the driver ’s panel as follows: ①... -
Page 12: The Call Functions
User Manual for USB Phone with LCD The Call Functions Make a VoIP call ① Use on your phone to scroll up/down and select the contact. ② Press to make the call. Note: Or you can use Speed-dial number to make calls. ①... -
Page 13: Start A Voip Conference
User Manual for USB Phone with LCD Note: For more detailed usages of making a SkypeOut call, please visit Skype’s official If you dial a wrong number, please press (“Clear”) to clear it. website: http://www.skype.com If you input a wrong number, please press to clear it. -
Page 14: Other Functions
User Manual for USB Phone with LCD Other Functions Select a Chord Music Ring Tone To select your favorite chord music ring tone, please right click the tray icon choose “Options” and go to “Advanced” panel. Select a ring tone here Adjust the volume for ring tone here Note:... -
Page 15: Receive Voice Mail
User Manual for USB Phone with LCD Receive Voice Mail Press to receive the voice mail Adjust Volume for Speaker Press to adjust the volume for speaker during a call. You can see the volume status icon in the LCD screen on your phone Set LCD Display Please right click the tray icon and choose “Options…”... -
Page 16: Trouble Shooting
User Manual for USB Phone with LCD Trouble Shooting For latest information about the Trouble Shooting and the FAQ, please visit http://www.skyu2m.com/support.htm Q1: Why did I see the icon rather than in the taskbar? What’s wrong with the driver software? If you see the icon 1) please check whether Skype is running at the moment. - Page 17 User Manual for USB Phone with LCD Step 2: “Privacy”--“Related Task: Manage other program’s access to Skype”. Step 3: Choose “Change” Step 4: Choose “allow this program to use Skype” - 17 - Version 1.0.0.0 2006-09-18...
- Page 18 User Manual for USB Phone with LCD Q2: After turning on the computer, I see the icon . Why? There are two possible causes if you see the icon 1) The USB phone fails to communicate with your PC. Please check whether the USB port is in a normal state.
- Page 19 User Manual for USB Phone with LCD Right click the device and choose “Uninstall”. Then into REPLUG THE USB PHONE the USB port. Windows will reinstall the device driver. Q3: When I plug in the USB phone, the music was played from the phone also rather than from the PC's speaker.
- Page 20 User Manual for USB Phone with LCD Q4: How to assign a Speed-dial number for my contact? You can assign Speed Dial number for the contacts directly on the related VoIP application’s panel. Here we take Skype for example. Right click on the selected Skype contact and choose “Set Speed-Dial”...
