Page 1: Table Of Contents
RTS 2nd Generation SERVO AMPLIFIER CONTENTS SAFETY INSTRUCTIONS ……………………………………………………………………………3 1. GENERAL 2. TECHNICAL SPECIFICATIONS RTS Servo amplifier performance chart Block diagram 3. DIMENSIONS, LABELLING, Dimensions Labelling 4. - ELECTRICAL CONNECTIONS General Wiring Requirements 4.1.1 Appliance handling 4.1.2 Electromagnetic compatibility RTS Servo amplifier connection...
Page 2 RTS 2nd Generation SERVO AMPLIFIER Speed loop rapid adjustment Complete speed loop adjustment Diagnostic helpI Calibration 7.4.1 Tachometric generator voltage calibration (R104) 7.4.2 Rated speed selection (R105) 7.4.3 Pulse current adjustment (R113) 7.4.4 Current limitation by external resistance or external voltage (terminal block X1) 7.4.4.1...
Page 3: Safety Instructions
RTS 2nd Generation SERVO AMPLIFIER SAFETY Servodrives present two main types of hazard : - Electrical hazard Servoamplifiers may contain non-insulated live AC or DC components. Users are advised to guard against access to live parts before installing the equipment.
Page 4 RTS 2nd Generation SERVO AMPLIFIER Upon delivery All servoamplifiers are thoroughly inspected during manufacture and tested at length for bugs before shipment. • Unpack the servoamplifier carefully and check it is in good condition. • Also check that data on the manufacturer's plate comries with data on the order acknowledgement.
Page 5: General
RTS 2nd Generation SERVO AMPLIFIER 1. GENERAL The RTS servo amplifier is designed for four-quadrant control of DC servo motors up to mechanical powers of 2500 W. It incorporates power and chopping supplies, including the energy dissipation resistor for some versions.
Page 6: Technical Specifications
RTS 2nd Generation SERVO AMPLIFIER - COMPLIANCE WITH STANDARDS RTS bears the CE mark under European Directive 89/336/EEC as amended by Directive 93/68/EEC on electromagnetic compatibility. This European Directive refers to the harmonised generic standards EN50081-2 of December 1993 (Electrical Compatibility - Generic Standard for Emissions - Industrial Environments) and EN50082-2 of June 1995 (Electromagnetic Compatibility - Generic Standard for Immunity - Industrial Environments).
Page 7: Rts Servo Amplifier Performance Chart
RTS 2nd Generation SERVO AMPLIFIER 2.1 RTS Servo amplifier performance chart RTS CHARACTERISTICS 3/10-40M 10/20-60 12/24---B 12/24-130T 20/40-130T 16/32-190T at 40°C ambient temperature single-phase single/three- battery three-phase three-phase three-phase phase Input voltage range 18/36Vac 18/56Vac 16/60Vdc 58/116Vac 58/116Vac 82/164Vac Rated input voltage...
Page 8: Block Diagram
RTS 2nd Generation SERVO AMPLIFIER 2.2 Block diagram PVD 3487 GB 03/2004...
Page 9: Dimensions, Labelling
- in single Europe 3U DIN rack, in two widths 10" and 19". - wall- or panel-mounted, with rear angle bracket. Racks are available with or without ventilation, while RTS wall-mounted versions have individual ventilation where required (RTS 12/24-130T, RTS 20/40-130T and RTS 16/32-190T). Unventilated racks are for RTS 3/10-40M only.
Page 10 RTS 2nd Generation SERVO AMPLIFIER Dimensional PARVEX Ref. Input supply Ventilation Supply drawing (with or without customisation card) RTS 3/10-40M RTS 5104-301 Single-phase * RTS 7104-301 fan-cooled FELX 304743 RTS 10/20-60T RTS53060102R Three-phase (p16) *RTS73060102R fan-cooled FELX 304749 RTS 12/24---B...
Page 11 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 12 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 13 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 14 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 15 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 16 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 17 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 18 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 19 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 20 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 21 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 22 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 23: Labelling
3.2 Labelling RTS SERVO AMPLIFIER IDENTIFICATION Each RTS servo amplifier has an identification label affixed either on the metal plate at the rear for wall-mounted versions or on the side of the heat sink for rack versions. The information should be recorded and stored as with the information about the corresponding servo motor.
Page 24: Electrical Connections
The drive will then be earthed via a low impedance link between the potential reference plate and the earth screw at the back of the RTS. If this link exceeds 30 cm, a flat braid should be used instead of a conventional lead.
Page 25: Rts Servo Amplifier Connection
FELX 305823 (p29) The terminal block description and terminal functions are shown in the following pages : The RTS servo amplifiers are factory set to match the characteristics of the servo motor to be used or the application where known.
Page 26 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 27 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 28 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 29 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 30: Front Panel
RTS 2nd Generation SERVO AMPLIFIER 4.3 Front Panel RTS V2 Battery (Rack) RTS V2 Battery (wall-mounted) PVD 3487 GB 03/2004...
Page 31 RTS 2nd Generation SERVO AMPLIFIER RTS V2 10 E (Rack) RTS V2 12 E (Rack) PVD 3487 GB 03/2004...
Page 32 RTS 2nd Generation SERVO AMPLIFIER RTS V2 12 E (wall-mounted) RTS V2 12 A / 130V (wall-mounted) 1PH and 3PH PVD 3487 GB 03/2004...
Page 33 RTS 2nd Generation SERVO AMPLIFIER RTS V2 16 A / 190 V (wall-mounted) PVD 3487 GB 03/2004...
Page 34 RTS 2nd Generation SERVO AMPLIFIER RTS V2 20 A / 130 V (wall-mounted) PVD 3487 GB 03/2004...
Page 35: Terminal Blocks X1, X2 And X3
RTS 2nd Generation SERVO AMPLIFIER 4.4 Terminal blocks X1, X2 AND X3 Torque value : terminal block X1, 0.4 Nm terminal blocks X2 and X3, 0.8 Nm. Terminal block X1 front panel connection Recommended cable cross-section : 0.5 mm² - - 1.5 mm²...
Page 36 RTS 2nd Generation SERVO AMPLIFIER TERMINAL DESCRIPTION N° NAME TERMINAL BLOCK X1 I RED Analogue reduction current. Reduction may be controlled either by voltage or by resistor between 7 and 8. This input may be used for example when the servo motor is against a mechanical abutment.
Page 37 13, faults are cleared and the axis is ready again (if fault has been corrected). Switching the RTS off and then back on has the same effect as RESET. Logic 0 V, to be connected to terminals 10, 11 and 12 via control contacts.
Page 38: Terminal Block X2 Connection
Permissible current : 0.5 A READY Permissible voltage : 220 V ac 4.6 Terminal block X3 connection Recommended cable cross-section : RTS 3/10 : 1.5 mm²; RTS 10/20, 12/24, 16/32, 20/40 : 2.5 mm² TERMINAL DESCRIPTION N° NAME TERMINAL BLOCK X3...
Page 39: Accessories
The extra choke is connected between the RTS and the servo motor, as near as possible to the RTS. It must be used when the servo motor choke is less than the values in the table on page 7. It should also be used when the RTS and servo motor are more than 50 m apart (or 25 m where shielded cable is used).
Page 40: Transformer
RTS 2nd Generation SERVO AMPLIFIER Recommended combinations : RTS 3/10-40M single-phase RTS 10/20-60 single-phase SF020231 12A-2x0.25 mH or three-phase drawing FELX 303434 (p.42). RTS 12/24-130T three-phase RTS 20/40-130T three-phase SF02023 25A-1.5 mH drawing FELX 302804 (p.41). RTS 16/32-190T three-phase SF02022 16A-2.5 mH drawing FELX 302804 (p.41).
Page 41 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 42 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 43 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 44 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 45 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 46 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 47 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 48 RTS 2nd Generation SERVO AMPLIFIER PVD 3487 GB 03/2004...
Page 49: Led Displays
RTS 2nd Generation SERVO AMPLIFIER 5. LED DISPLAYS LED displays are possible only if the supply voltage is present. The "Ready" relay, in this case, must not be incorporated in the auto-hold of the power supply. : energised - axis OK POWER ON : no power on axis.
Page 50: Servo Amplifier Adaptation
RTS 2nd Generation SERVO AMPLIFIER 6. SERVO AMPLIFIER ADAPTATION Selector switch positions * Selector S1 * Position Speed control. Speed feedback is used. Usual case. * Position Current control. Speed control is unused. X1/4-X1/5 input becomes a current reference. * Selector S2...
Page 51: Commissioning
RTS 2nd Generation SERVO AMPLIFIER 7. COMMISSIONING - Check the connection of the following items : - transformer - relay system, especially the emergency stop - motor and any smoothing choke - tachometer system - ground circuit - Speed and current inhibited (X1/10 and X1/11 not connected), Connect the power to the servo amplifier.
Page 52: Speed Loop Rapid Adjustment
RTS 2nd Generation SERVO AMPLIFIER 7.1 Speed loop rapid adjustment * Offset adjustment Once ambient temperature is stabilised, adjust zero speed to the mid-position with the "SPEED OFFSET" potentiometer on the front panel. * Speed adjustment "SPEED ADJUST" potentiometer produces fine calibration of speed for a given reference.
Page 53: Complete Speed Loop Adjustment
RTS 2nd Generation SERVO AMPLIFIER 7.2 Complete speed loop adjustment Systematically applicable when J charge ≥ 10 J motors Caution As servo amplifiers factory based parametersprovided by the customer, this setting does not usuallyrequire adjustment. Before adjusting the speed loop, all the adjustable parameters must be fixed (current limits, speed scale setting, speed limits).
Page 54 RTS 2nd Generation SERVO AMPLIFIER FIG 2 In some cases, gain limitation is due to resonance: the motor starts to whistle or vibrate at high frequencies (> 100 Hz). A -1 filter must be included at a frequency 3 to 4...
Page 55: Diagnostic Helpi
RTS 2nd Generation SERVO AMPLIFIER 7.3 Diagnostic helpI ENERGISING "POWER ON" off "POWER ON" flashes « POWER ON » on Check which LED on side of Measure voltage at terminals U, V, W card Voltage present voltage Check fuse Check fuses, main...
Page 56: Calibration
RTS 2nd Generation SERVO AMPLIFIER 7.4 Calibration CAUTION : Servo amplifiers are factory set and the information in sections 7.4.1 - 7.4.11 are for reference only. The components below are stud mounted and used to calibrate the servo amplifier for the corresponding motor.
Page 57 RTS 2nd Generation SERVO AMPLIFIER TACHOMETER SYSTEM EMF RATED SPEED PVD 3487 GB 03/2004...
Page 58: Tachometric Generator Voltage Calibration (R104)
RTS 2nd Generation SERVO AMPLIFIER Symbols used rated speed of application for 10 V reference speed Ilim = maximum pulse current of motor Imax = maximum pulse current of servo amplifier maximum rated current of motor gradient of tachometric generator in V per thousands of rpm...
Page 59: Rated Speed Selection (R105)
RTS 2nd Generation SERVO AMPLIFIER 7.4.2 Rated speed selection (R105) C102 Resistor R105 calibrates the useful speed of the R105 R102 U - RI application. For a speed reference of ± 10 V, the 39 K speed corresponding in rpm to the servo motor will...
Page 60: Pulse Current Adjustment (R113)
RTS 2nd Generation SERVO AMPLIFIER 7.4.3 Pulse current adjustment (R113) R113 modifies the maximum current authorised by the servo amplifier. The standard pulse current is twice the value of the permanent current. It may be set either internally by using R113 or by using current reduction input X1/7 "Ired".
Page 61: Time Constant Adjustment I = F(T) (R109)
RTS 2nd Generation SERVO AMPLIFIER 7.4.5 Time constant adjustment I = f(t) (R109) CAUTION : For safety reasons the values of resistors R109 and R103 must not be altered without authorisation from PARVEX - Warranty may be affected. The system time constant is factory set so the...
Page 62: Adjustment Of Current Limitation Curve Versus Speed I F(N) (R131 - 132)
RTS 2nd Generation SERVO AMPLIFIER 7.4.7 Adjustment of current limitation curve versus speed I F(n) (R131 - 132) + 15 V 10 K R 132 Réduction Current R 131 reduction de I - 15 V Resistor R131 is used to select the zero current point on the speed current diagram.
Page 63: Calibration Of Function U - Ri (R133 - R134)
RTS 2nd Generation SERVO AMPLIFIER R132 values % of maximum current Ns - Nr 27.4 k Ω 47.5 k Ω 100 k Ω 82.5 k Ω 121 k Ω Ω Ω Ω Ω Ω 1000 12.1 k 22.1 k 33.2 k 47.5 k...
Page 64: Tripping Limit Calibration (R135)
760/ K 32 R RTS 20/40 - 130 540/ K 64 R e.g. RX 120 L servo motor with RTS 3/10-40 = 11.5 V/1000 rpm R 133 = 15 kΩ R = 2.5 Ω R 134 = 100 kΩ 1) with RR6606C : R133(kΩ)=192/ K ;...
Page 65: Dc Voltage Calibration (Rb)
RTS 12/24 - 48 RTS 12/24 - 24 ∞ RTS 16/32 - 190 (1) Remark : The RTS servo amplifier may be used with supply voltages different from the standard values. e.g. RTS 10/20-40 with 32 V supply RTS 16/32-140 with 110 V supply Please ask for details.
