Diamond Systems Tritan Assembly Instructions Manual

Enclosure for poseidon with data acquisition
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This document describes how to assemble a Trriton enclosure with a Diamond Systems Poseidon EPIC SBC with
data acquisition.
The Triton Enclosure will hold the Poseidon SBC, the Poseidon Panel I/O Board, an optional
hard disk drive and up to 3 PC/104-Plus expansion boards.
1.
Attach Spacers to Base Plate ................................................................................................4
2.
Remove Poseidon Standoffs .................................................................................................4
3.
Install IDE Flashdisk or IDE Cable (Optional)........................................................................4
4.
Attach Poseidon Board to Base Plate....................................................................................5
5.
Attach Panel I/O Board to the Poseidon SBC........................................................................6
6.
7.
Attach Dual Serial Cable for COM3 and COM4.....................................................................7
8.
Attach Triton Power Button....................................................................................................8
9.
Install Data Acquisition Cables ..............................................................................................9
10. Install Power Supply (Optional) .............................................................................................9
11. Install Hard Drive (Optional) ................................................................................................10
12. Install the Triton U-Frame Body...........................................................................................11
13. Install the Cooling Fan (optional) .........................................................................................11
14. Attach Top Plate ..................................................................................................................11
Triton Assembly Instructions
Assembly Instructions
Triton Enclosure for Poseidon
With Data Acquisition
November, 2007
V0.9
DSC Document #7521002
Diamond Systems Corp.
(650) 810-2500
www.diamondsystems.com
Quick List of Assembly Steps
Revision 0.9 November 2007
Page 1 of 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tritan and is the answer not in the manual?

Questions and answers

Related Manuals for Diamond Systems Tritan

Summary of Contents for Diamond Systems Tritan

  • Page 1: Table Of Contents

    Diamond Systems Corp. (650) 810-2500 www.diamondsystems.com This document describes how to assemble a Trriton enclosure with a Diamond Systems Poseidon EPIC SBC with data acquisition. The Triton Enclosure will hold the Poseidon SBC, the Poseidon Panel I/O Board, an optional hard disk drive and up to 3 PC/104-Plus expansion boards.
  • Page 2 Triton Enclosure Kit Contents The Triton Enclosure Kit comes with all the elements necessary to build a complete functional computer system based on the Poseidon EPIC Single Board Computer. The only additional item required is the Poseidon board itself. The Kit includes: ITEM DSC PART NO.
  • Page 3 Triton Hardware Kit The Triton Hardware Kit contains all the components for assembling boards to the Triton Enclosure Base Plate and for assembling the enclosure. This hardware kit includes the following items: DSC PART NO. DESCRIPTION 6810061 FHMS, Phillips, 6-32 UNC x 1/4", Stl/Zn (RoHS) (sheet metal assembly) 6843014 FF spacer, 4-40 x 14mm, (RoHS) ALUM hex 6810046...

  • Page 4: Attach Spacers To Base Plate

    Assembly Steps Before assembling the system, be sure that the Poseidon SBC board is configured properly. Refer to the Poseidon User Manual or FastStart Guide for configuration options. Attach Spacers to Base Plate Install qty. 8 14mm F/F hex spacers to the base plate with 8 of the 4-40 x 1.4 Philips flat head screws. The screws are inserted through the bottom (painted) side of the front panel into one female end of the spacers.

  • Page 5: Attach Poseidon Board To Base Plate

    Flashdisk module with hardware Hardware mounted onto flashdisk module First attach one screw through the top of the flashdisk and fasten the washer and spacer on the other side. Note the position of the washer and spacer in the right photograph above. Both the washer and spacer are required to maintain the proper mounting distance.

  • Page 6: Attach Panel I/O Board To The Poseidon Sbc

    If you are using any additional PC/104 or PC/104-Plus expansion cards in your system, screw four 0.6” PC/104 standoffs provided with your expansion PC/104 card (or in the Diamond Systems MTG-104 provided with the Poseidon Development Kit) through the top of the Poseidon board into the four standoffs under the four PC/104 mounting holes in the middle of the Poseidon board (See photo).

  • Page 7: Attach Triton Enclosure Face Plate To Poseidon Panel I/O Board Assembly

    Side view of Poseidon SBC mounted on base plate with panel I/O board installed Attach Triton Enclosure Face Plate to Poseidon Panel I/O Board Assembly Attach the Triton Enclosure face plate to the Poseidon SBC – Panel I/O Board – Base Plate Assembly. If necessary remove the 8 securing hardware jack screws from the four Dsub connectors on the Panel I/O board (the two DB9 serial connectors, the DB9 female power input connector and the DB15 female VGA connector.

  • Page 8: Attach Triton Power Button

    the COM3 connector. The DB9 connector with the red pin 1 indicator wire goes into the COM3 opening. Secure the connectors in place by reattaching the four jack screws onto the two DB9 connectors. Connect the 2x10 2mm connector at the other end of the Dual Serial Cable to connector CN3 on the Poseidon Panel I/O Board. DSC cable #6981081 installed in the face plate and connected to CN3 of the panel I/O board Attach Triton Power Button Attach the Triton Power Button to the face plate by inserting the 2x6 2mm connector on the Triton Power Button...

  • Page 9: Install Data Acquisition Cables

    Install Data Acquisition Cables Install the data acquisition cables. First, install the Triton Analog I/O Cable (DSC#6982020). Attach the Centronics 50 pin connector to the face plate by placing the connector through the face plate opening labeled Analog I/O with the red pin 1 wire facing toward the right hand edge of the system (looking from the front of the face plate).

  • Page 10: Install Hard Drive (Optional)

    Jupiter-MM power supply Jupiter-MM power supply attached to Poseidon Install Hard Drive (Optional) If you are installing a hard drive into the system, install it to the Triton U-Frame using mounting hardware provided with your disk drive. You might want to install the 44-pin IDE cable from Step 3 before attaching the HDD to the enclosure body.

  • Page 11: Install The Triton U-Frame Body

    Install the Cooling Fan (optional) Place the cooling fan on the inside left side of the U-frame so that the fan manufacturer name and model # are visible to the inside and the power cable is at the top of the fan. Insert the four ¾” #4 flat head screws through the U-frame from the painted side through the four fan mounting holes.
