FIREPLACE INSERT ENCLOSURE INSTALLATION INSTRUCTIONS ENCLOSURE MODEL 90566400 FOR INSERT MODEL 5660NA ENCLOSURE MODEL 90566000 FOR INSERT MODEL 5660 STANDARD KEEP THESE INSTRUCTIONS FOR FUTURE USE These products have been tested and listed to the standards UL127-2009 and ULC-S610-M87 Morsø US LLC 1011 Hwy.
Installing the Fireplace Insert Enclosure PRODUCT SAFETY THESE FIREPLACE INSERT ENCLOSURES ARE A LISTED COMPONENT FOR AND ARE INTENDED FOR USE WITH THE MORSØ MODELS 5660 STANDARD AND 5660NA WOOD- BURNING FIREPLACE INSERTS ONLY. DO NOT USE OTHER PRODUCTS NOT SPECIFIED OR LISTED FOR USE WITH THESE ENCLOSURES.
Page 3
However, many installation options are possible. If an exterior chimney is necessary for your The Model 90566000 or Model 90566400 Fireplace Insert Enclosure may be elevated off the floor to Insert Model 5660 STANDARD or 5660NA allow the to be placed higher up on the wall.
Installing the Fireplace Insert Enclosure CHIMNEY REQUIREMENTS For proper draft and best performance, the chimney should extend at least 15’ (4.6m) and not more than 35’ (10.6m) above the level of the MORSØ Model 5660 STANDARD or Model 5660NA hearth. The chimney must be properly installed and supported in accordance with the chimney manufac- turer’s instructions.
Installing the Fireplace Insert Enclosure COMBUSTIBLE FRAMING The Morsø Fireplace Insert Enclosure is designed with spacers on the side and back surfaces that prevent the enclosure walls from coming in contact with adjacent combustible materials that are used for framing around the enclosure. In addition, the top of the enclosure includes a standoff that prohibits the header for the combustible construction above the enclosure from being installed too close the heat from the Insert, enclosure top and chimney.
ELECTRICAL CONNECTIONS If you are installing the Model 5660 NA with the optional blower, you must have electrical power con- nected to the single outlet provided on the side of Enclosure Model 95066400. Refer to the National electrical Code, ANSI/NFPA 70 and other local code requirements. Use a licensed electrician. The electrical specifications are 120 VAC, 60Hz, less than 1 amp.
Page 7
FIG. 2 Framing Front View FIG. 3 Framing Side View A = 67” (1702mm) B = 39 3/4” (1010mm) C = 25 1/2” (648mm) Minimum Note: These dimension are for both Model 90566000 and Model 90566400 Enclosures FIG. 4 Framing Plan View...
Page 8
Installing the Fireplace Insert Enclosure MINIMUM CLEARANCES TO ADJACENT COMBUSTIBLE MATERIALS Combustible / Non-Combustible Material Limits E = 39 3/4” (1010mm) F = 67” (1702mm) G = 28 3/4” (730mm) J = 29 1/4” (742mm) Model 5660 Model 5660NA Ceiling 21 3/8”...
Installing the Fireplace Insert Enclosure HEARTH REQUIREMENTS When using the Insert in the Fireplace Insert Enclosure, the L = 39 3/4” (1010mm) Min. hearth protection requirements are different than when in- M = 16” (405 mm) Min. USA stalling the Insert in an existing masonry fireplace. The en- N = 8”...
Page 10
Installing the Fireplace Insert Enclosure CUSTOMIZING THE FINISHED APPEARANCE The facing of the Fireplace Insert Enclosure may be finished to give a variety of different aesthetic appearances. However, only non-combustible materials may be applied to the face inside the speci- fied limits for combustible materials.
Page 11
Installing the Insert into the Enclosure Prepare the Insert Refer to the Morsø Installation and Operating Instructions for either Model 5660 NA Standard or 5669 NA with New Blower for instructions on how to prepare the insert for installation. Follow the Blower Installation instructions on page 14 if you are installing the Insert with the optional blower.
