Dialling a call
1 From clock face, tap and hold the
screen for 2 seconds to show the
dial page:
2 Tap the phone number and then
tap Alternatively, tap to
access your Phone book.
To see previously dialled calls, tap
are entered.
Answering a call
• When the call alert sounds, tap Answer in the lower
left corner of the screen or press the lower button.
Alternatively, to reject the call, tap Reject in the lower
right corner.

Voice activation

• From the clock face, press and hold the lower button,
and then say either "CALL xyz" or "FIND xyz", where
xyz is a Phone book contact name.
Ending a call
• Press the upper button or tap Option in the lower left
corner & then tap End.
sWaP Signature
&
In-call options
During a call you can access a number of features by
tapping Option:
• Hold - Place the call on hold*
• End - End the current call
• Volume ctrl - Adjust speaker volume
• Phone Book - Access your Phone Book
when no numbers
• New Call - Dial a new number*
• Message - Access your messages
• Sound Recorder - Record the call
• Mute - Switch off the microphone
• DTMF - Switch keypad tones on/off
• Connect Lost BT Headset -
Attempt to reconnect with the headset
In the call screen, you can also:
• Tap to re-display the numeric keypad.
• Tap H-Free to activate the loudspeaker.
Tap H-Held to return to quiet mode.
Network support required.
*
Active user guide
Call history
Your sWaP watch maintains records of all incoming,
outgoing and missed calls as well as text message
quantities and data usage. You can use these records
to make calls, populate your Phone book and/or keep
track of your call charges.
1 From the clock face, tap Menu or press the lower
button.
(twice, if necessary) to view the Call history
2 Tap
options:
• Missed Calls
• Dialed Calls
• Received Calls
• Delete Call Log
• Call Time
• SMS Counter
• GPRS Counter
Select the required item to view a list of related options
or details.
