This set is used for remote control (turn on/off) by means of any devices for long
distance. It uses the RS485 wire interface. The CD06-Rx receiver possesses six transmitters in
it, of the current load up to 4A each. The NO (normally open) contact points are directed to
the term block and the NC (normally closed) ones are directed to the transmitter. It is
possible to control outlets in the receiver by means of the CD06-Tx transmitter or the PTZ
keyboard. Devices possess the signalling system, by means of LED diodes, which shows the
state of inlets in the transmitter and the state of outlets in the receiver.
The CD06 set is composed of:
• The CD06-Tx transmitter
• The CD06-Rx receiver
• Instruction manual
• Guarantee card
Technical data:
CHARACTERISTICS
The number of ID addresses
The addressing scope
Supply voltage
Current intake (max.):
Type and number of outlets, inlets
The maximum current load of outlets
The type of outlets
Wire interface
The transmission protocol type
The transmission type
The RS485 transmission speed
The work mode
The temperature scope of work
Dimensions (mm)
Co-operation
The recommended radio module
The work scopes: wire RS485 (with
UTP cat. 5)
Radio work mode with the CD04
module
Optional external covering
CD06
Transmitter and receiver
THE CD06-Rx RECEIVER
8
from ID 100 to ID 107
10-14V DC
320mA
6 potential-free, independently
controlled outlets of the NO (normally
open) and NC (normally closed) type
4A
Term block – screw-type 2.5 kw
RS485
PELCO-D
8N1
2400bps and 9600bps
Bistable and Astable
0 to +55 °C with the external covering
-20 to +55 °C
78x107x28
with the PTZ keyboard (PELCO-D) ;
with the CD06-Tx transmitter
CD04
1000m
6 or 14 km
Type: CDH-Rx
tightness class: IP56
CAMSAT
www.camsat.com
THE CD06-Tx TRANSMITTER
8
from ID 100 to ID 107
10-14V DC
150mA
6 independently controlled inlets
-
Term block – screw-type 2.5 kw
RS485
PELCO-D
8N1
2400bps and 9600bps
Bistable and Astable
0 to +55 °C with the external
covering -20 to +55 °C
69x80x28
with the CD06-Rx receiver
CD04
1000m
6 or 14 km
Type: CDH-Tx
tightness class:IP66
Advertisement
Summary of Contents for Camsat CD06
- Page 1 NC (normally closed) ones are directed to the transmitter. It is possible to control outlets in the receiver by means of the CD06-Tx transmitter or the PTZ keyboard. Devices possess the signalling system, by means of LED diodes, which shows the state of inlets in the transmitter and the state of outlets in the receiver.
- Page 2 • communication can function by means of wire or radio interface (with CD04 modules) • the CD06-Rx receiver can be controlled by means of the CD06-Tx transmitter or by means of the PTZ keyboard; • the receiver can be set to two work modes: bistable and astable (the receiver can be divided and half of outlets will work in the bistable mode and the other half in the astable mode) •...
- Page 3 (see point “Configuration of the CD06 set”). The LED indicators and transmitters in the receiver will be set in accordance with the last changes.
- Page 4 Permitted connections of several CD06 sets One-way transmission: a) 1 transmitter controlling maximum 32 receivers of the same address b) maximum 32 transmitters controlling 32 receivers of the same ID address* c) maximum 8 transmitters controlling 8 receivers of different ID addresses*...
- Page 5 It can be realised by changing the PIN8 state or by disconnecting the device from the power supply and connecting it once again. Things to keep in mind while designing networks with CD06 devices in order to avoid errors in their functioning: •...
- Page 6 General terms and conditions of a warranty Camsat company gives a warranty of 24 months for transmission sets of the following series: TCO 5807, CAM 5816, CDS 5021, CD04, CD06, CDS-5IP 1. In case of detecting incorrect work of a device, before giving the device to the service, it is necessary to make sure that everything was done in accordance with the instruction manual.
