UNAVi X1 Owner's Manual

Oem-integrated navigation system
Hide thumbs
Table of Contents

Advertisement

Quick Links

OEM-integrated Navigation System
UNAVI X1,X2
Owner's Manual
Published by E-sense Technology inc.
Copyright ©2011 by E-sense Technology inc.
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X1 and is the answer not in the manual?

Questions and answers

Summary of Contents for UNAVi X1

  • Page 1 OEM-integrated Navigation System UNAVI X1,X2 Owner’s Manual Published by E-sense Technology inc. Copyright ©2011 by E-sense Technology inc. All rights reserved.

  • Page 2: Table Of Contents

    Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading this instruction, keep this manual in a safe place for future reference. NOTICE UNAVI has a built-in user manual in an E-book format. Select “Owner’s Manual” icon. INTRO COMPONENTS...
  • Page 3 The user of this product is solely responsible for observing safe driving practices. Do not operate your UNAVI system while driving. Park the vehicle first. Do not use the navigation system or entertainment features if it presents a risk to you or any...

  • Page 4: Intro

    1. INTRO << Disclaimer >> For your safety, please do not operate this unit while driving. Be sure the vehicle is at a complete stop and parked in a legal manner when the driver is operating this unit. >> This navigation system should not be used in place of the driver`s own judgment. Any route suggested made by this navigation system does not take into account, traffic conditions, speed limits, road conditions, constructions, and etc.
  • Page 5 1. INTRO << Disclaimer >> Do not use the navigation system to route you to emergency services. The database does not contain a complete listing of locations of emergency service providers such as police, fire stations, hospitals and clinics. Please use your judgment and your ability to ask for directions in these situations.
  • Page 6 1. INTRO << Disclaimer >> Minimize the amount of time spent viewing the screen while driving. >> Do not cover up product with a towel or cloth-like material (Increased internal temperature may cause product malfunction or lead to fire hazard). >>...
  • Page 7 1. INTRO << Disclaimer >> During installation, please make sure the vent holes are not obstructed as it may lead to product malfunction. >> The MUTE function will only work with the system’s built-in speaker. It can take up to 3 seconds for the sound to reappear after MUTE is turned off.
  • Page 8 >> Any other trademarksand commercial names belong to and are the property of their respective owners. >> UNAVI and any of its distributors are not responsivle for any accidents pertaining to the misuse of this product during inappropriate times. >> The trademark and the UNAVI® logo are owned by the E-sense technology Inc.
  • Page 9 2. COMPONENTS << Components FRONT Control Box SD Card slot Reset USB host BACK ② ① ① Main cable connector ② Control box connector...

  • Page 10: Components

    2. COMPONENTS << Components UNAVI External Speaker Control Box SD Card Reader Control Box Cable GPS Antenna Main Cable SD card...

  • Page 11: Navigation

    3. NAVIGATION << Using The Navigation Under the Main Menu, please click on the NAVIGATION icon (For detailed navigation usage instructions, please refer to the navigation user manual) [Steps] Navigation menu > Select Destination...

  • Page 12: Clock

    4. CLOCK << Clock Press on the desired menu icon to access Tap screen to return to the main menu. the application program...
  • Page 13 5. MUSIC << Music Press on the desired menu icon to access the application program...
  • Page 14 5. MUSIC << Music MUTE : Mutes and unmutes the built-in speaker only. EXIT : Exits user from the current application. DELETE ALL : Removes all files from the playlist.(Actual file does not get deleted) DELETE FILE : Removes selected file(s) from the playlist.(Actual file does not get deleted) ADD FILE : Add file(s) to the palylist...
  • Page 15 5. MUSIC << Music Default Repeat Once Repeat All Shuffle Shuffle Repeat Forward Play/Pause Stop Backward /Next /Previous...

  • Page 16: Music

    5. MUSIC << Creating A File List 1. Click ADD 2. Double click on any discovered storage devices.
  • Page 17 5. MUSIC << Creating A File List 3. Double click the folder to display the files you 4. Select the file(s) you wish to add to the File List. wish to play.
  • Page 18 5. MUSIC << Creating A File List 5. Click ADD LIST to generate previously 6. Click EXIT. selected files.
  • Page 19 5. MUSIC << Creating A File List 1. SELECT ALL -Selects all files in the list. 2. SELECT CANCEL -Deselects file(s). 3. SELECT RRVERSE -Unselected file(s) are selected. 4. ADD LIST -Adds selected file(s) to the playlist.
  • Page 20 5. MUSIC << Creating A File List ROOT/ -Redirects user to the root directory. FOLDER -Redirects user to the upper directory /folder File Number - Displays the current number of selected files out of the total number of files in the list.

  • Page 21: Image

    6. IMAGE << Image Press on the desired menu icon to access the application program...
  • Page 22 6. IMAGE << Image SLIDE ON : Turns the slideshow feature On and OFF. SLIDE START : Begins slideshow. EXIT : Exits user form the current application. DELETE ALL : Removes all files from the playlist.(Actual file does not get deleted) DELETE FILE : Removes selected file(s) from the playlist.(Actual file does not get deleted)
  • Page 23 7. VIDEO << Video Press on the desired menu icon to access Some video files cannot be played due to codec compativility the application program issues and may cause system error. Movie player will not work with Navigation due to safety concerns and to maintatin operating system stability.
  • Page 24 7. VIDEO << Video MUTE : Mutes and unmutes the built-in speaker only. EXIT : Exits user form the current application. DELETE ALL : Removes all files from the playlist(Actual file does not get deleted) DELETE FILE : Removes selected file(s) from the playlist(Actual file does not get deleted) ADD FILE : Add file(s) to the palylist...

  • Page 25: Video

    7. VIDEO << Video Default Repeat Once Repeat All Shuffle Shuffle Repeat Forward Play/Pause Stop Backward /Next /Previous...

  • Page 26: Trip (See Also "Bluetooth Phone Pairing")

    8. TRIP << Trip Press on the desired menu icon to access Trip program(also referred to as the Radio screen) the application program...
  • Page 27 8. TRIP << Trip SONATA 1CDP audio SONATA 6CDC audio Tap screen to return to the main menu Tap screen to return to the main menu Radio screen timer control Radio screen timer control (3,5,7 seconds or Always) (3,5,7 seconds or Always) ELANTRA TUCSON Tap screen to return...
  • Page 28 8. TRIP << Trip AZERA OPTIMA Radio screen timer control Radio screen timer control (3,5,7 seconds or Always) (3,5,7 seconds or Always) Tap screen to return Tap screen to return to the main menu to the main menu SPORTAGE Tap screen to return to the main menu Radio screen timer control (3,5,7 seconds or Always)
  • Page 29 8. TRIP << Bluetooth Phone Pairing WARNING Vehicle must be parked to complete the phone pairing process. Not all mobile phones are compatible with the car manufacturer`s Bluetooth system. Please visit the car manufacturer`s website for a list of compatible phones tested to work with their Bluetooth system. 1.

  • Page 30: Aux

    9. AUX << Aux Press on the desired menu icon to access This Mode will allow you to view/play external sources that are connected to the A/V input cable such as a DVD the application program player and game consoles. (Tap screen to return to the main menu)

  • Page 31: Settings

    10. SETTINGS << Settings Press on the desired menu icon to access the application program...
  • Page 32 10. SETTINGS << Start Option TRIP AUTORUN -When turned ON, the system will automatically execute the Trip program. BUILT-IN SPEAKER -When turnde ON, the system will enable sound output through the built-in speakers. PARKING ASSIST LINE -When turned ON, rear-parking assist line will display with the rearview camera activated.
  • Page 33 10. SETTINGS << Screen/Volume SCREEN BRIGHTNESS -Adjusts overall brightness of the LCD screen. DAY/NIGHT MODE AUTO CHAGE -When turned ON, LCD will auto-adjust the display settings. BUILT-IN SPEAKER VOLUME -Adjusts volume level of the system sound output. TOUCH ADJUSTMENT -Backlight OFF: Press to turn backlight ON/OFF -Calibrate: Press to calibrate touch screen sensitivity.
  • Page 34 10. SETTINGS << Program Displays current program version infomation Boot Update -Executes the startup splash screen update. Program Update -Executes software program update. Trip Update -Executes Trip program update.
  • Page 35 10. SETTINGS << Customizing The Splash Screen To change the boot image(or splash screen logo) at startup, select and prepare an image file with the following format: Image Size : 800x480 Image Format : 24-bit BMP Filename & Extension: “intro.bmp”...
  • Page 36 10. SETTINGS << Customizing The Splash Screen Drag and drop the selected image(BMP) file to the main directory of the SD_CARD.
  • Page 37 10. SETTINGS << How To Change The Intro Image Insert the SD card into the SD card reader and start Upon completion of the update, system will reboot up the system. automatically and will chage the boot image. From the main menu, go to “SETTING” > Press “PROGRAM”...

  • Page 38: Update

    1) Remove SD Card from the control box (usually located inside the glove compartment). 2) Visit www.unavi-usa.com to download and decompress the designated update file. 3) Once the update file has been decompressed and extracted, an UPDATE folder and UpdateProgram.exe file will appear.

  • Page 39: Additional Information

    << Specification Rated power source : DC 12V General Storage temperature range : -20℃ to 60℃ Screen size : 7.0 inch wide (UNAVI X1) Display 8.0 inch wide (UNAVI X2) Resolution : 800 x 480 pixels Signal : L1 Frequency(1575.42MHz)

  • Page 40: Troubleshooting

    << Troubleshooting To set time 1. There is no need to set up the clock manually as UNAVI is linked to the GPS signal. 2. Check to see there is GPS signal reception 3. Re-install program to resolve possible program errors 4.
  • Page 41 2. Download the latest map update as the existing map data may be outdated. If the above measures do not resolve your trouble shooting questions, please contact your local UNAVI distributor or visit us on the web at www.unavi-usa.com.

  • Page 42: Problems During Operation

    In many cases, the reason why the USB flash drive doesn't work is because it is in a manufacturer-based format that is not compatible with the UNAVI system. If possible, it is recommended to use a commonly known brand USB flash drive with at least 16 GB of memory.
  • Page 44 E-SENSE TECHNOLOGY INC. 265-28, YANGJAE-DONG, SEOCHO-GU, SEOUL, 137-130, KOREA UNAVI USA INC. www.unavi-usa.com 21136 S. WILMINGTON AVE #200, CARSON, CA 90810, U.S.A...
