Service Manual
Vacuum Cleaner
Model : RC-805
DAEWOO ELECTRONICS CO., LTD.
OVERSEAS SERVICE DEPT.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC-805 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo RC-805

Summary of Contents for Daewoo RC-805

  • Page 1 Service Manual Vacuum Cleaner Model : RC-805 DAEWOO ELECTRONICS CO., LTD. OVERSEAS SERVICE DEPT.

  • Page 2: Table Of Contents

    CONTENTS 1. SPECIFICATIONS 2. DESCRIPTIONS 3. DIAGRAM 4. CAUSE OF TROUBLE AND COUNTERMEASURE 5. DISASSEMBLING AND TREATMENT 6. EXPLODED VIEW AND PARTS LIST...

  • Page 3: Descriptions

    2. DESCRIPTIONS 2-1. ASSEMBLY A DUST METER B HOSE HANDLE * AIR CONTROL VALVE (MODEL : RC-805, RC-805B) * POWER CONTROL (MODEL : RC-805H) C CORD REWIND BUTTON D POWER CORD E ON/OFF BUTTON F CLEANING TOOLS * CREVICE TOOL...
  • Page 4 2-2. MODEL RC-805 CLOSE OPEN PIPE HOLDER HOSE DUST HANGER COVER HOSE HOSE HANGER HOOK WIDE SUCTION BRUSH HANDLE CREVICE TOOL GROOVE BUTTON DUSTING BRUSH ROTATE...
  • Page 5 2-3. MODEL RC-805B CLOSE OPEN PIPE HOLDER HOSE DUST HANGER COVER HOSE HANGER HOSE HOOK WIDE SUCTION BRUSH HANDLE GROOVE CREVICE TOOL POWER CONTROL KNOB BUTTON DUSTING BRUSH ROTATE...
  • Page 6 2-4. MODEL RC-805H POWER CONTROL HIGH STOP PIPE HOLDER HOSE DUST HANGER COVER HOSE WIDE SUCTION BRUSH HANDLE CREVICE TOOL GROOVE BUTTON DUSTING BRUSH ROTATE...

  • Page 7: Diagram

    3. DIAGRAM 3-1. WIRING DIAGRAM 1) MODEL RC-805 THERMO STAT MOTOR CORD REEL P.C.B 2) MODEL RC-805B THERMO STAT MOTOR CORD REEL P.C.B SLIDE VOLUME...
  • Page 8 3) MODEL RC-805H THERMOSTAT SLIDE VOLUME MOTOR CORD REEL P.C.B...

  • Page 9: Circuit Diagram

    3-2. CIRCUIT DIAGRAM 1) MODEL RC-805 POWER SWITCH THERMOSTAT PART NAME SPEC. POWER SWITCH AC 250V, 7A THERMOSTAT N85˚C AC 230V/50Hz COIL MOTOR MOTOR VH112CA020 474K COIL 1mH, 8A 2) MODEL RC-805B MOTOR COIL COIL PART NAME SPEC. YELLOW R1, R2...

  • Page 10: Cause Of Trouble And Countermeasure

    4. CAUSE OF TROUBLE AND COUNTERMEASURE TROUBLE CAUSE COUNTERMEASURE FILTER BAG (PAPER OR CLOTH) CHANGE IT WITH NEW IS FULL WITH DUST REMOVE OBSTACLE OR SUCTION POWER IS WEAK CLOGGING OR TEAR IN HOSE REPLACE THE HOSE REPLACE THE MOTOR DEFECTIVE MOTOR (SEE 5-2) BREAKING IN POWER CORD...
  • Page 11 TROUBLE CAUSE COUNTERMEASURE BROKEN REEL SPRING OF REPLACE IT CORD REEL (SEE 5-3) POWER CORD IS NOT WOUND UP POWER CORD BROKE AWAY REPAIR FROM THE BOBBIN (SEE 5-3) ¡ CAUTION - BE CAREFUL WHEN BREAKING UP THE CORD REEL. THE REEL SPRING MAY SPRING OUT OF THE SPRING COVER.

  • Page 12: Disassembling And Treatment

    5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY PUSH PUSH PULL PULL PUSH PUSH 1) SEPARATE THE CORD REWIND BUTTON ¤ AND THE SWITCH BUTTON ¤Ł FROM THE BODY COVER ¤Ø . 2) OPEN THE DUST COVER ¤Œ AND UNSCREW THE 4 SCREW ¤º THEN LIFT THE COVER ASSEMBLY (¤...

  • Page 13: Motor Assembly

    5-2. MOTOR ASSEMBLY LEAD SLIT PROJECTION SLIT (GUIDE AIR ASSEMBLY) (CASE MOTOR REAR ASSEMBLY) LEAD MOTOR ASSEMBLY CORD REEL ASSEMBLY SLIT BODY ABSORBER VIBRATION 1) TAKE THE MOTOR ASSEMBLY OUT OF THE BODY. 2) UNSCREW THE 4 SCREW ¤ . 3) CHECK THE MOTOR ¤Œ(WHETHER THE MOTOR IS BURNT OUT OR NOT).

  • Page 14: Cord Reel Assembly

    5-3. CORD REEL ASSEMBLY VIEW A ROLLER BRAKE DAEWOO RC-805 125V 12A / 250V 10A 105 C CORD Not for Hard Usage. (LEVER ASSEMBLING)
  • Page 15 1) TAKE THE CORD REEL OUT OF THE BODY. 2) UNSCREW THE SCREW § AND SEPARATE THE BOBBIN ¤ı FROM THE BRACKET ¤ AND CHECK THE CONTACTS BETWEEN THE Y TYPE TERMINALS (¤ , ¤ ) AND THE RING TYPE TERMINALS (¤ , ¤æ...
  • Page 16 5-4. HOSE ASSEMBLY (RC-805H) HOLE 12 11 1) UNSCREW THE 2 SCREWS §łAND CHECK WHETHER THE KNOB § IS BROKEN OR NOT. 2) CHECK THE SLIDE VOLUME § . 3) CHECK THE CONNECTIONS THE TERMINALS AND THE WIRES. 4) UNSCREW THE SCREW ¤ AND CHECK THE CONNECTIONS (¤Ø , ¤ ). 5) CHECK THE CONTACTS BETWEEN THE TERMINAL §...
  • Page 17 5-5. WIDE SUCTION BRUSH 1) TO SEPARATE THE COVER ¤æFROM THE BODY ¤ , UNSCREW THE 4 SCREWS ¤Œ . 2) TO SEPARATE THE PIPE ¤ FROM THE NECK ¤ , TAKE THE HOOKS ¤ OUT OF THE PIPE ¤ BY USING AN AWL.

  • Page 18: Exploded View And Parts List

    6. EXPLODED VIEW AND PARTS LIST 6-1. CLEANER ASSEMBLY 1) MODEL RC-805 (3620006100) DAEWOO RC-805 125V 12A / 250V 10A 105 C CORD Not for hard Usage.
  • Page 19 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY BODY 3620404800 ASSY ABSORBER VIBRATION 3620106600 CR FOAM FILTER 3621903100 PCB ASSY(FILTER) 3624305300 1MH, 104K, 230V/50HZ ASSY MOTOR 3620006300 ASSY CORD REEL AS 3629504600 ASSY COVER AS 3621413900 ASSY WINDOW DM 3625500600 FE FILM SCREW TAPPING...
  • Page 20 2) MODEL RC-805B (3620006400) PCB ASSY'S HARNESS DAEWOO RC-805 125V 12A / 250V 10A 105 C CORD Not for hard Usage.
  • Page 21 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY BODY 3620404800 ASSY ABSORBER VIBRATION 3620106600 CR FOAM FILTER 3621903100 ASSY MOTOR 3620006300 ASSY CORD REEL AS 3629504700 ASSY COVER AS 3621414100 ASSY WINDOW DM 3625500600 FE FILM SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN BUTTON CR...
  • Page 22 3) MODEL RC-805H (3620006200) DAEWOO RC-805 125V 12A / 250V 10A 105 C CORD Not for hard Usage.
  • Page 23 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY BODY 3620404900 ASSY ABSORBER VIBRATION 3620106600 CR FOAM FILTER 3621903100 PCB POWER CONTROL 3624303510 230V/50HZ ASSY MOTOR 3620006300 ASSY CORD REEL AS 3629504700 ASSY COVER AS 3621413900 ASSY WINDOW DM 3625500600 FE FILM SCREW TAPPING...
  • Page 24 6-2. BODY ASSEMBLY 1) MODEL RC-805, RC-805B (3520404800)
  • Page 25 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY PROTECTOR 3628300600 BODY 3620404100 ABSORBER VIBRATION 3620106600 CR FOAM PACKING CASE 3624000100 CR FOAM ROLLER BACK 3624701800 GRILLE 3622400600 FILTER 3621902500 PP FIBER FILTER 3621902400 ABSORBER SOUND 3620107300 FELT 5t ABSORBER SOUND 3620105600 FELT 5t...
  • Page 26 1) MODEL RC-805H (3620404900)
  • Page 27 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY PROTECTOR 3628300600 BODY 3620404100 ABSORBER VIBRATION 3620106600 CR FOAM PACKING CASE 3624000100 CR FOAM ROLLER BACK 3624701800 GRILLE 3622400600 FILTER 3621902500 PP FIBER FILTER 3621902400 ABSORBER SOUND 3620107300 FELT 5t ABSORBER SOUND 3620105600 FELT 5t...
  • Page 28 6-3. COVER ASSEMBLY 1) MODEL RC-805, RC-805H (3621413900)
  • Page 29 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY COVER DUST 3621411800 DUST METER AS 3629701800 ASSY COVER DM 3621412000 SCREW TAPPING 7121401411 T2S PAN 4X14 COVER BODY 3621412100 ABSORBER VIBRATION 3620102800 CR FAOM PACKING HOLE 3624003700 ABS 1t ABSORBER SOUND 3620106100 FELT 5t...
  • Page 30 2) MODEL RC-805B (3621414100)
  • Page 31 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY COVER DUST 3621411800 DUST METER AS 3629701800 ASSY COVER DM 3621412000 SCREW TAPPING 7121401411 T2S PAN 4X14 COVER BODY 3621412200 ABSORBER VIBRATION 3620102800 CR FAOM PACKING HOLE 3624003700 ABS 1t ABSORBER SOUND 3620107900 FELT 5t...
  • Page 32 6-4. MOTOR ASSEMBLY (3620006300) LEAD SLIT PROJECTION SLIT (GUIDE AIR ASSEMBLY) (CASE MOTOR REAR ASSEMBLY)
  • Page 33 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY SCREW TAPPING 7121401411 T2S PAN 4X14 CASE MOTOR FRONT 3621101900 PACKING MOTOR 3624000900 CR FOAM MOTOR VC 3962511200 230V, 1200W, DMI ABSORBER SOUND 3620105900 PU FAOM 20T GUIDE AIR 3622501300 PC LEXAN 500 MOUNT MOTOR 3627900500...
  • Page 34 6-5. CORD REEL ASSEMBLY 1) MODEL RC-805 (3629504600) VIEW A ROLLER BRAKE DAEWOO RC-805 125V 12A / 250V 10A 105 C CORD Not for Hard Usage. (LEVER ASSEMBLING)
  • Page 35 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY BRACKET CR 3620600900 PC LEXAN 500 LEVER CR 3623701600 PC LEXAN 121 STOPPER CR 4569C35082 FRAME STOPPER 4565A35070 POLY ACETAL SPRING LEVER 3625104300 HSW3 SCREW TAPPING 7122400811 T2S TRS 4X8 MFZN TERMINAL AS 3628706000 Y TER+BK+TAB...
  • Page 36 2) MODEL RC-805B, RC-805H (3629504700) VIEW A ROLLER BRAKE DAEWOO RC-805 125V 12A / 250V 10A 105 C CORD Not for Hard Usage. (LEVER ASSEMBLING)
  • Page 37 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY BRACKET CR 3620600900 PC LEXAN 500 LEVER CR 3623701600 PC LEXAN 121 STOPPER CR 4569C35082 FRAME STOPPER 4565A35070 POLY ACETAL SPRING LEVER 3625104300 HSW3 SCREW TAPPING 7122400811 T2S TRS 4X8 MFZN TERMINAL AS 3628706000 Y TER+BK+TAB...
  • Page 38 6-6. HOSE ASSEMBLY 1) MODEL RC-805, RC-805B (3623204800)
  • Page 39 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY ADAPTER PIPE 3629101000 CLAMP ADAPTER 3621200900 SPRING 3625102900 HSW3 COVER ADAPTER 3621412400 SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN HOSE 3623201120 EVA 1.5M HOLDER HOSE 4569A71021 CUFF HOSE 3626800200 LDPE PIPE HOSE 3624402100 VALVE...
  • Page 40 2) MODEL RC-805H (3623203310) HOLE 12 11...
  • Page 41 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY ADAPTER 3629100310 PC, LEXAN-121 SPRING 3625102900 HSW3 TERMINAL AS 3628705700 TERMINAL+WIRE CLAMP ADAPTER 3621200900 COVER ADAPTER 3621405910 PC, LEXAN-121 SCREW TAPPING 7121300811 T2S PAN 3X8 HOSE 3623204200 PVC-S/SWRS TAPE VINYL 2TU00019BK 19mm BLACK COVER HOSE...
  • Page 42 6-7. WIDE SUCTION BRUSH (3629303100)
  • Page 43 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY BODY BRUSH 3620404300 3628200500 SWRM MFZN ROLLER 3624702100 SCREW TAPPING 7121401411 T2S PAN 4X14 PICKER LITTER 3627000600 A-12N RED WIPER ASSY 3629900300 PCV-S ABSORBER 3620107800 PP FOAM PIPE BRUSH 3624403900 HOOK 3623100100 POLY AMIDES...
  • Page 44 6-8. EXTENSION PIPE ASSEMBLY (3624406800) 215mm PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY PIPE PLASTIC 3624403600 PIPE HOLDER 3623001900 SCREW TAPPING 7121401412 T2S PAN 4X14 MFZN...
  • Page 45 6-9. EXTENSION PIPE ASSEMBLY (3624406900) 215mm PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY PIPE PLASTIC 3624403500 HDPE+SPC T=0.7 PIPE HOLDER 3623001900 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN SPACER 3625000400 EVA FOAM T=1.5...
