Celerity FOG-TXCB User Manual

Fiber optic gateway (fog)
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

•fiber optic gateway
control box
Product Overview
Celerity Fiber Optic Gateway (FOG) products are designed for high performance, dependability
and convenient installation in professional AV applications. The FOG-TXCB (transmitter) and
FOG-RXCB (receiver) control boxes support HDMI, RS232, IR, USB HID (USB v1.1) and Ethernet
10/100BASE-T connections up to 1000 feet over Celerity fiber optic cable without the need for
field terminations.
Slim and compact at slightly more then .5" thin, the FOG-TXCB and FOG-RXCB are easily installed
in equipment racks, structured wiring panels, conference room furnishings, and telecommunication
centers via detachable mounting flanges. Discreet mounting behind AV equipment and high
definition flat panel displays is easily accomplished by the slim profile of FOG-TXCB and FOG-
RXCB.
FOG-TXCB and FOG-RXCB work in pairs and may be interchanged with other Celerity Fiber Optic
Gateway products such as FOG-TXWP and FOG-RXWP for further system design and installation
flexibility.
Connection is made between the FOG-TXCB and FOG-RXCB with a Celerity Fiber Optic Gateway
cable available in lengths from 35' to 1000' (12.2m to 305m) which connect to the FOG control
boxes via a secure, mini digital connector. FOG-TXCB and FOG-RXCB are sold separately.
Included Items
Fiber Optic Transmitter (TX)
1 each:
FOG-TXCB
USB power cable (1.5m)
USB-AC power adapter (5V/1A)
IR emitter cable with 3.5mm plug (TS, 5V)
IR receiver cable with 3.5mm plug (TRS, 5V)
USB to USB cable (1.5m)

User guide

Fiber Optic Receiver (RX)
1 each:
FOG-RXCB
USB power cable (1.5m)
USB-AC power adapter (5V/1A)
IR emitter cable with 3.5mm plug (TS, 5V)
IR receiver cable with 3.5mm plug (TRS, 5V)
User guide
User Guide
09/2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOG-TXCB and is the answer not in the manual?

Questions and answers

Related Manuals for Celerity FOG-TXCB

Summary of Contents for Celerity FOG-TXCB

  • Page 1: User Guide

    10/100BASE-T connections up to 1000 feet over Celerity fiber optic cable without the need for field terminations. Slim and compact at slightly more then .5” thin, the FOG-TXCB and FOG-RXCB are easily installed in equipment racks, structured wiring panels, conference room furnishings, and telecommunication centers via detachable mounting flanges.

  • Page 2: Specifications

    User Guide 09/2014 Specifications Function FOG-TXCB FOG-RXCB Transmitter Receiver Celerity fiber optic cable input Celerity mini digital Celerity fiber optic cable output Celerity mini digital Celerity fiber optic cable distance up to 1000 ft up to 1000 ft HDMI input...
  • Page 3 Detachable Connectors. LED Display Indicators On the top surface of the FOG-TXCB and FOG-RXCB are blue and orange LEDs which will illuminate when the cables are correctly connected. The LED for the Fiber Optic Cable connection will illuminate with the cables connected in the proper direction and the FOG-CB are powered.
  • Page 4 Lit when powered (blue) RS232 Power FOG-TXCB will be placed at source (TX) equipment, FOG-RXCB will be placed at receiving (RX) equipment RS232, and Ethernet are bidirectional and may be connected in the best way to fit a particular application...

  • Page 5: Making Connections

    RXCB will be emitted for the purpose of controlling a component with an IR remote (place the emitter over a component’ s IR window). Connect an IR receiver (included) to IR RX port (port 4). The IR receiver will send IR information from the FOG-TXCB to the FOG -RXCB for the purpose of controlling a component attached to the FOG-TXCB.
  • Page 6 The following is the recommended pin-out diagram for creating a RS232-RJ45 cable for use with the Fiber Optic Gateway. You may also use a 3rd party cable or one already in your possession. Celerity FOG RS232 ports only support Ground, Transmit Data and Receive Data connections as highlighted in the diagram below.

  • Page 7: Fcc Warning

    Celerity Technologies warrants this product against defects in material or workmanship for a period of 12 months from the original date of purchase. Celerity Technologies will, at its sole option, (i) repair the product using new or refurbished parts, or (ii) replace the product with a new or refurbished product.
  • Page 8 celeritytek.com 16 Technology Dr. Suite 142 Irvine, CA 92618...
