Summary of Contents for AOC CT500G
- Page 1 CT500G User’s Manual...
- Page 2 Thank you very much for choosing the AOC Color Monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for you future reference.
- Page 3 *Check if the PC System is Plug & Play compatible *Check if the Video Card is Plug & Play compatible *Check if the D-15 plug pin of Video Cable is bent *Make sure the AOC Monitor Drivers are installed (AOC Monitor...
- Page 4 Figure 1 Installing and Removing the Swivel Base Figure 2 Connecting Cables AC Inlet Figure 3 External Control Knob EXTERNAL CONTROLS Switch: Power On/Off Switch Menu Contrast Brightness. Exit Figure 4 The OSD Message 800 X 600...
- Page 5 INSTALLATION INSTRUCTIONS SWIVEL BASE To attach the swivel base to the monitor, do the following: Carefully turn the monitor on its side or upside down. (see figure 1) Locate the cavities at the bottom front of the monitor. ...
- Page 6 ADJUSTING THE PICTURE (See Figure 3) CONTRAST Adjust the picture contrast. BRIGHTNESS Adjust the picture brightness. H- CENTER Adjust the horizontal position of the picture. H- SIZE Adjust the picture’s horizontal size. V- CENTER Adjust the vertical position of the picture. V- SIZE Adjust the picture’s vertical size.
- Page 7 SPECIFICATION 38.1cm(15"), 90º deflection, 29mm neck, 0.24mm(H), 0.28mm(D) dot pitch Viewable Image Size 35.1cm (13.8"), diagonal Video 0.7Vpp, R, G, B Analog Separate Sync. TTL Level H/V-sync.: Positive/Negative Scanning Frequency: Horizontal 30kHz to 56kHz automatically Vertical 50Hz to 120Hz automatically Max.
